Broil King BSG343N Manuale utente

1. ORIENTATE THE DIVIDER AS

SHOWN WITH THE NOTCH

TOWARDS THE REAR AND

PLACE OVER THE MOUNTING

PINS.

3. PLACE THE RACK SIDE RODS

OVER THE PINS IN THE SIDES

OF THE GRILL AS SHOWN IN

THE CUT-OUT VIEW. NOTE

THAT THE BENT END OF THE

SIDE ROD IS TOWARDS THE

REAR.

QUICK START GUIDE

INSTALLATION OF DIVIDERS, VAPORIZERS, AND WARMING RACK

2. ORIENTATE THE VAPORIZER

AS SHOWN AND PLACE OVER

THE MOUNTING PINS.

1. PUSH IN ON THE CONTROL KNOB AND TURN

SLIGHTLY COUNTERCLOCKWISE WHILE KEEPING

THE KNOB PUSHED IN.

2. CONTINUE TO TURN COUNTERCLOCKWISE

WHILE PUSHING IN ON THE KNOB. APPROX-

IMATELY IN THE POSITION SHOWN YOU WILL

FEEL A SLIGHT RESISTANCE AND YOU WILL

HEAR GAS BEGIN TO FLOW. MAINTAIN THIS

POSITION FOR 2 OR 3 SECONDS.

3. AFTER THE GAS HAS BEEN FLOWING FOR 2 TO 3

SECONDS, TURN THE KNOB COUNTERCLOCKWISE

WHILE PUSHING IN UNTIL THE KNOB HAS BEEN

TURNED A FULL 1/4 TURN. THE PIEZO SHOULD HAVE

IGNITED AND LIT THE BURNER. ONCE THE BURNER

HAS BEEN LIT, RELEASE THE KNOB. BE SURE THE

KNOB HAS BEEN TURNED TO THE POSITION SHOWN,

OR THE GAS WILL NOT CONTINUE TO FLOW.

QUICK START GUIDE

LIGHTING INSTRUCTIONS FOR FRONT AND REAR BURNERS

4. IF THE BURNER FAILS TO IGNITE, WAIT FOR 10

SECONDS, RETURN THE KNOB TO ITS ORIGINAL

POSITION AND BEGIN AGAIN AT STEP 1.
