PROJECT RUNWAY
™LIMITED EDITION
INNOV-ÍS 85e
SEWING
Built-in stitches, buttonhole styles and fonts
• 80 built-in sewing stitches, including 10 one-step auto-size
buttonhole styles and one sewing lettering font.
Solidly constructed chassis
• Helps reduce vibration and noise while sewing and adds to
portability of machine.
Built-in needle threading system
•At the press of a lever, the thread is pushed through the eye of
the needle.
Easy stitch selection via 10-digit pad and large back-lit
LCD display
•Select desired stitch pattern with a simple touch on the digital pad
and view the stitch length and width information in the large back-lit
LCD display.
Lightweight portable machine with included hard cover
• Transport and protect your sewing machine with ease.
Ability to combine stitches for greater creativity
•Combine stitches into favorite patterns, repeat patterns and create
mirror images of stitches.
3 memory pockets
• Save your favorite stitch in one of the memory pockets for future use.
Super wide stitch selection
• More variety with each stitch, select up to 7mm in stitch width.
Included wide table for larger projects and quilting
Ignite Your Passion for Fashion
Overview
Images are for illustrative purposes only. ©2013 Brother International Corporation. All rights reserved. Brother Industries, Ltd., Nagoya, Japan.
The Innov-ís 85e showcases the latest
sewing and quilting technology in a
portable size and at a very reasonable
price. This lightweight machine is packed
full of features, which is great for beginner
and experienced seamstresses alike. Make
a fashion statement, and let the enhanced
Innov-ís 85e be your voice! With its
diverse selection of decorative stitches,
buttonhole styles, alphanumeric characters
and custom stitch capability, you’re not
just sewing...you,re creating “personal
couture” with enough style and panache
to satisfy the most demanding critic: you.
HADSS85EPRW
Basic Features
LCD Display Size (Horizontal x Vertical) Inches 2.0 x 0.7
Display (Number of Colors) Monochrome
Stitch Select 10 Key
Screensaver —
Opening Screen —
On-Screen Help —
Built-in Languages —
On-Screen Editing —
Lighting 1 LED
Thread Tension Manual
Needle Threading System Easy
Easy Bobbin Winding •
Adjustable Bobbin Winding Speed •
Thread Sensor —
Thread Sensor On/Off —
Automatic Thread Cutter —
Quick-Set™ Bobbin •
Full USB —
Computer Connectivity with Update Capability —
Mouse Capability by USB —
Media Type —
InnovEye®Technology —
Sewing Features
Bed Area (Depth x Width) Inches 5.9 x 9.8
Work Space (Height x Width) Inches 4.1 x 6.2
Maximum Sewing Speed (Stitches Per Minute) 850
Knee Lifter —
Feed Dog 7
Back to Beginning Key —
Standard Presser Feet Included 7
Built-in Sewing Stitches (Includes Buttonhole Styles) 80
Buttonhole Styles 10 One-step
Built-in Sewing Lettering Fonts 1
Stitch Width 7mm
Stitch Length 5mm
My Custom Stitch™ Feature —
Side Feeding —
Start/Stop Button •
Speed Controller •
Twin Needle Setting Key •
Needle Position Key (Up/Down) •
Quilting Features
Automatic Height Adjuster™ AHA®Feature —
Presser Foot Pressure Adjustment —
Presser Foot Leveling •
Automatic Presser Foot Lifter —
Pivot Function —
Drop Feed/Free-Motion •
Free-Motion Quilting Foot —
Built-in Quilting Stitches —
Included Quilting Feet —
Included Wide Table —
All specifications subject to change without prior notice.
KEY: • Feature Included —Feature Not Included
INNOV-ÍS 85e
Included Accessories
• Buttonhole Foot
• Overcasting Foot
• Monogramming Foot
• Zipper Foot
• Zigzag Foot
• Blind Stitch Foot
• Button Fitting Foot
• Easy Reference Stitch Pattern Plate and On-Board Holder
• Wide Table
• Hard Cover
• Additional Accessories Included In Box
Recommended Optional Accessories*
• Adjustable Zipper and Piping Foot (SA161)
• Candlewicking Foot (SA193)
• Adjustable Bias Binder Foot (SA198)
• Scissor Kit (SASCISSKIT)
• Additional Optional Accessories Available For Purchase
To compare this model with others like it, try our
It’s Sew Easy product finder.
For more information, visit www.brother-usa.com
or call 1-800-4-A-BROTHER
*Additional purchase required.
