Brother LT2-B847 MKII Manuale utente

LT2−B847 Mark II 1/4

2000.7

LT2−B847Mark II

Twin Needle Drop Feed Lock Stitcher

with Thread Trimmer

Specifications −1

Application Forthinmaterials

Max.speed 4,000rpm

Max..stitchlength 4mm

Needlebarstroke 33.4mm

Threadtake-upstroke 49.9mm

Presserbarlifter 7mm

Heightof

presserfoot Kneelifter 13mm(Withthreadwiper:10mm)

Heightoffeeddog 1mm

Needle DP×5#9−#14

Hook Horizontalrotaryhook(verticalaxis)

−400

Threadtrimmer Scissorstype(Solenoid)

Threadwiper Solenoidtype

Quickreverse Solenoidtype

LT2−B847 Mark II 2/4

2000.7

B847 Mark II (For Standard)

For normal

*In case of using over 1−1/2" (38.1mm) gauge parts, it is necessary to make special machining on the arm-bed.

The specification with amaximum stitch width of 77 mm is available.

Please consult your Brother representative concerning delivery date and price.

*The ¡symbol is a presser foot assembly with finger guard.

Needlegauge Needleclamp

assy Needleplate Feeddog Presserfootassy

(−1) (−1) (−1)

(inch)

(mm)

Forlightmaterials

Fornewsynthetic

fiber Forlight

materials

Fornewsynthetic

fiber Forlight

materials Fornew

syntheticfiber

S07393−001

1/8(3.2) 158794−101 S07686−001 S07696−001

S38544−001

S07395−001

3/16 (4.8) 158791−101 S07688−001 S36842−001 S07698−001 S36838−001 S38542−001 ¡S36839−001

S07397−001

1/4(6.4) 158792−101 S07689−001 S36841−001 S07699−001 S36835−001

S38543−001

¡S36836−001

1/2

(12.7)

158797−101 S07693−001 S07703−001 S07684−101 ¡

3/4(19.1)

158806−101

S07996−001

S07998−001

S07889−101

20mm

S00937−001

S13479−001

S07998−001

S13480−101

7/8

(22.2)

158807−101 S07997−001 S37011−001 S07999−001 S07999−001 S07894−101 ¡S37012−001

Needleplate Presserfootassy

Needleclampassy (−1)

Forlightmaterials Fornewsyntheticfiber Fornewsyntheticfiber

Feeddog Presserfootassy

(-1)

Forlightmaterials Fornewsyntheticfiber (−1)

Forlightmaterials

LT2−B847 Mark II 3/4

2000.7

B847 Mark II (For Standard)

For shirt fronts

*The ¡symbol is a presser foot assembly with finger guard.

Needlegauge Needleclampassy Needleplate Feeddog Presserfootassy

(−1) (−1) (−1)

mm Forlightmaterials Forlightmaterials Forlightmaterials

18mm S14352−001 S14354−001 S14357−001 S14355−101 ¡

20mm S00937−001 S13479−001 S14360−001 S14358−101 ¡

22mm 158807−001 S07997−001 S14363−001 S14361−101 ¡

24mm S14364−001 S14366−001 S14369−001 S14367−101 ¡

26mm S14370−001 S14372−001 S14375−001 S14373−101 ¡

28mm S14376−001 S14378−001 S14381−001 S14379−101 ¡

30mm S16651−001 S16653−001 S16656−001 S16654−101 ¡

Needleplate Feeddog Presserfootassy

Needleclampassy (−1)

Forlightmaterials (−1)

Forlightmaterials

LT2−B847 Mark II 4/4

2000.7

B847 Mark II (For Thread trimmer)

For normal

*The thread trimming fixed knife (part No. S07527−001) and the installation screw (part No. 148539−101) are not provided with the

needle plate, so they must be ordered separately if required.

*In case of using over 1−1/2" (38.1mm) gauge parts, it is necessary to make special machining on the arm-bed.

The specification with amaximum stitchwidth of 77 mm is available.

Please consult your Brother representative concerning delivery date and price.

*The ¡symbol is a presser foot assembly with finger guard.

Needlegauge Needleclamp

assy Needleplate Feeddog Presserfootassy

(−1)

(inch)

(mm)

Forlightmaterials Fornewsynthetic

fiber Forlight

materials Fornew

syntheticfiber

Forlightmaterials Fornew

syntheticfiber

S07393−001

1/8(3.2) 158794−101 S07401−001 S07409−001 S38544−001 ¡

S07395−001

3/16 (4.8) 158791−101 S07403−001 S36844−001 S07410−001 S36843−001 S38542−001 ¡S36839−001

S07397−001

1/4(6.4) 158792−101 S07405−001 S36847−001 S07411−001 S36846−001 S38543−001 ¡S36836−001

5/16 (7.9) 158793−101 S07676−001 S07680−001 S07682−001

3/8(9.5) 158798−101 S13621−001 S13623−001 S13624−001

1/2(12.7) 158797−101 S07678−001 S07681−001 S07684−101 ¡

3/4(19.1) 158806−101 S07886−001 S07888−001 S07889−101 ¡

7/8(22.2) 158807−101 S07891−001 S37014−001 S07893−001 S07893−001 S07894−101 ¡S37012−001

1(25.4) 158805−101 S15088−001 S15090−001 S15091−101 ¡

1−1/4(38.1) 158799−001 S20914−001 S20916−001 S20917−101 ¡

Needleplate Presserfootassy

Needleclampassy (−1)

Forlightmaterials Fornewsyntheticfiber Fornewsyntheticfiber

Feeddog Presserfootassy

(−1)

Forlightmaterials Fornewsyntheticfiber (−1)

Forlightmaterials
