Brute BSG1221SB Manuale utente
This product can expose you to chemicals including gasoline engine exhaust, which is known to the State of
!
Brute is a registered trademark of Briggs & Stratton
Corporation used under license.
California to cause cancer, and carbon monoxide, which is known to the State of California to cause birth defects or other reproductive
harm. For more information go to
Date of Purchase:
Model Number:
Serial Number:
The emissions control system for this lawn mower is compliant with all standards set by the U.S. Agency.
This manual contains important information regarding safety, operation, and maintenance.
Item Number:
Thank you for purchasing this superior quality lawn mower from Brute®. When operating and
maintaining this product as instructed in this manual, your lawn mower will give you many years of reliable service.
To order parts, receive warranty assistance, or other service inquiries, contact us at:
Save your original sales receipt and record the following information below for service or warranty assistance.
Customer Service
Online: www.midlandpowerinc.com
E-mail: [email protected]
Toll Free: 1-877-528-3772
Description of Product Parts………………………………………………………………………………………………3
Safety Information…………………………………..……………………………………………………………………...
Assembly……………………………………………..……………………………………………………………………..
Adjustment …………………………………………..……………………………………………………………………..1
Operation……………………………………………..……………………………………………………………………..1
Storing and Maintenance…………………………..……………………………………………………………………...1
Troubleshooting……………………………………..……………………………………………………………………...
3
Fig 1
12
4
3
56
7
8
18
9
17 16
12
11
10 14 13 15 19
1. Drive lever (clutch lever)
2. Soft grip
3. Upper handle
4. Brake lever /stop lever
5. Handle knob with square neck bolt
6. Lower handle
7. Grass bag
8. Fuel tank cap
9. Primer
10. Height adjusting handle
11. Rear wheel
12. Engine oil cap
13. Side discharge cover
14. Side discharge chute
15. Deck
16. Spark plug boot
17. Pull start
18. Rear discharge cover
19. Front wheel
4
Carefully remove the machine from its packaging and check that the following parts are complete:
Fig 2
CB
I
HA
EF
D
G
WARNING! If any parts are damaged or missing, do not operate this tool until the missing parts are
replaced. Failure to heed this warning could result in serious personal injury.
WARNING!
NOTE!
A. Main mower deck (with upper handle and lower handle) 1pc
B. Cable clip 1pc
C. Grass bag assembly
D. Side discharge chute 1pc
E. Manual 1pc
F. Knob with bolt M8 2pc（Lower hanle）
G.Knob with bolt M8 2pc（Upper hanle）
H. Spark Plug Wrench 1pc
I. Plastic mulching plug 1pc (inside the mower)
Please read these instructions fully before assembling and operating.
Symbols are used in this manual to attract your attention to possible risks. The safety symbols and the explications which
accompany them must be perfectly understood. The warning themselves do not prevent the risks and cannot be a
substitute for proper methods of avoiding accidents.
WARNING- To reduce the risk of injury,user must read instruction manual.
This symbol, before a safety comment, indicates a precaution, a warning or a danger. Ignoring this
lead to an accident for yourself or for others. To limit the risk of injury, fire, or
electrocution always apply the recommendations indicated.
Keep bystanders away
Beware of sharp blades –remove spark plug before maintenance
Never refuel while the engine is running
Risk of injury. Do not open or remove safety shields while engine is running.
protection, eye protection when operating.
Hot surfaces will burn fingers or palms
Warning! The lawnmower exhaust gas contains toxic substances . Do not run the engine in closed or
poorly ventiated areas.
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check your local authority or retailer for recycling advice.
1. Read the instructions carefully. Be familiar with the controls and the proper use of the equipment.
2. Never allow children or people unfamiliar with these instructions to use the lawnmower. Local regulations can restrict
the age of the operator.
3. Never mow while people, especially children, or pets are nearby.
4. Keep in mind that the operator or user is responsible for accidents or hazards occurring to other people or their property.
1. While mowing, always wear substantial footwear and long trousers. Do not operate the equipment when barefoot or
wearing open sandals.
2. Thoroughly inspect the area where the equipment is to be used and remove all objects which can be thrown by the
machine.
Warning - gasoline is highly flammable.
or when the engine is hot.
creating any source of ignition until vapours have dissipated.
Replace faulty .
Before using, always visually inspect to see that the blades, blade bolts and cutter assembly are not worn or damaged.
Replace worn or damaged blades and bolts in sets to preserve balance.
Operation
1. Do not operate the engine in a confined space where dangerous carbon monoxide fumes can collect.
2. Mow only in daylight or in good artificial light.
6. For wheeled rotary machines, mow across the face of slopes, never up and down.
7. Exercise extreme caution when changing direction on slopes.
8. Do not mow excessively steep slopes.
9. Use extreme caution when reversing or pulling the lawnmower towards you.
when transporting the lawnmower to and from the area to be mowed.
W
8
11. Never operate the lawnmower with defective guards, or without safety devices, for example deflectors and/or grass
catchers, in place.
12. Do not change the engine governor settings or over speed the engine.
13. Disengage all blade and drive clutches before starting the engine.
14. Start the engine or switch on the motor carefully according to instructions and with feet well away from the blade(s).
15. Do not tilt the lawnmower when starting the engine or switching on the motor, except if the lawnmower has to be tilted
for starting. In this case, do not tilt it more than absolutely necessary and lift only the part which is away from the
operator.
16. Do not start the engine when standing in front of the discharge chute.
17. Do not put hands or feet near or under rotating parts. Keep clear of the discharge opening at all times.
18. Never pick up or carry a lawnmower while the engine is running.
19. Stop the engine and disconnect the spark plug wire, make sure that all moving parts have come to a complete stop
and, where a key is fitted remove the key.
Before clearing blockages or unclogging chute.
Before checking, cleaning or working on the lawnmower.
After striking a foreign object. Inspect the lawnmower for damage and make repairs before restarting and
operating the lawnmower.
If lawnmower starts to vibrate abnormally (check immediately).
20. Stop the engine and disconnect the spark plug wire, make sure that all moving parts have come to a complete stop
and, where a key is fitted remove the key.
Whenever you leave the lawnmower.
Before refueling.
21. Reduce the throttle setting during engine shut down and if the engine is provided with a shut-off valve, turn the fuel
off at the conclusion of mowing.
Keep all nuts, bolts and screws tight to be sure the equipment is in safe working condition.
Never store the equipment with gas in the tank inside a building where fumes can reach an open flame or spark.
Allow the engine to cool before storing in any enclosure.
To reduce the fire hazard, keep the engine, , battery compartment and storage area free of
grass, leaves, or excessive grease.
Check the grass catcher frequently for wear or deterioration.
Replace worn or damaged parts for safety.
If the fuel tank has to be drained, this should be done outdoors.
As shown in Fig 3&4
Fasten the lower handle to
The device by using two b s and
two small knobs on each side .
Unfold the upper handle and fix it to lower handle
By using the big knobs and the bots on each side
As shown in Fig 5
Fix the connection cord to the handle
with the cord clip (supplied).
NOTE!
Fig 4
Knobs Bolt
Washer
Fig 3
Fig 5
Knob Bolt
Washer
Clip
