BT Verve 450 Manuale utente

Userfriendly

Guide

Duet 450 Clock Telephone

At a glance

Lift flap

Contents

At a glance 2

Introduction 4

Installing your Duet 450 5

Clock Telephone

Using the Telephone 8

Using the clock 11

Technical information 12

Index 14

In this user guide, we’ve

included helpful tips and

useful notes.

Hints and tips

boxes

Introduction

Your Duet 450 Clock Telephone is

designed for ease of use and made to

the high standards set by BT

We thank you for

making the right

choice and expect

that your machine

will give you many

years of quality

service.

Please read

the instructions

carefully before

use, and keep this

User Guide for

future reference.

Date of purchase:

Place of purchase:

Serial number:

(on base of answering

machine)

Purchase price:

(for warranty purposes,

proof of purchase is

required, so please keep

your receipt)

For your records

The emergency services

can be contacted in the

UK by dialling 999. You

may also dial 112, which

is valid in any country

that is a member of the

European Community.

You may not be able to

make an emergency call

in certain situations:

• If the telephone line is

disconnected.

• If there is a fault on the

line from your phone or

on the network.

If your Duet 450 Clock

Telephone is connected to

a switchboard, you may

have to dial an access

number before 999 or 112

to contact the emergency

services.

Emergency calls

Installing your

Duet 450

Clock Telephone

IMPORTANT

Check that your Duet 450 Clock

Telephone is complete. When you

unpack you must have:

Telephone Handset

with attached

line cord.

Clock Telephone base with attached

mains power cable and

3-pin plug

✓

A Backup battery will

ensure your clock

settings are retained in

the event of a mains

power failure. Your

telephone will function

as normal even when

the mains power is off.

Loosen the screw on

the battery

compartment door.

Connect and insert a

9 volt battery (not

included).

Install backup

battery

Replace the cover.

Tighten the screw on

the battery

compartment door.

Situate your Duet 450

Clock Telephone close

enough to a phone and

mains socket so that

the cables will reach.

Do not stand it on

carpets or other

similar surfaces that

generate fibres.

Do not cover or

enclose the machine;

allow a free flow of air

to its surfaces.

Situating your

phone

Your Duet 450 Clock

Telephone is only

designed to be operated

in a normal office or

domestic environment.

It should not be used in

bathrooms or near water.

Warning If you do not have a

modern style socket,

call Freefone

0800 800 150

and ask for a BT

engineer to come and

fit the correct socket.

This is a chargeable

service.

Check your

telephone wall

socket

Plug the telephone

cord into wall

socket

Set the

ringer volume

Plug the attached 3

pin plug into the

mains power

socket

Your Duet 450 is

now ready for use

The ringer volume

switch is located on

the side of the handset.

There are three

settings:

A loud ring; your Duet

450 is preset to this

position.

LOW

A quiet ring.

OFF

no ring

OFF LO HI

Using the

Telephone

Storing and dialling

numbers

Your Duet 450 Clock

Telephone has three

one-touch memory

buttons M1, M2 or M3.

You can store a further

10 telephone numbers

in the two-touch

Quickdial memory.

Each stored number

can be up to 16 digits

long.

Lift the handset.

Press the STORE button.

Dial the number you

want to store using the

keypad.

Press the STORE button.

Press the memory

button (M1, M2 or M3)

under which you want

to store the number.

Replace the handset.

The number is stored.

Lift the handset.

Press the one-touch

memory button

(M1, M2 or M3) you

want to dial.

The number is dialled

automatically.

To store a phone

number in the one-

touch memory

Lift the handset.

Press the STORE button.

Dial the number you

want to store using the

keypad.

Press the STORE button.

Press the keypad

button (0-9) under

which you want to

store the number.

Replace the handset.

The number is stored.

To dial a number

stored in the one-

touch memory

To store phone

numbers in the

Quickdial memory

STORE

One touch memory label

Use the label by the M1, M2

and M3 button to keep a

record of the stored numbers.

Lift the handset.

Dial the first 16 digits

by pressing the M1,

M2, M3 or Quickdial

button under which

the second part of the

number is stored.

The whole number is

stored automatically.

Lift the handset.

Press the REDIAL

button.

The last number

called is redialled

automatically.

Some switchboards

can take a short time

to pick up an outside

line. You can insert a

pause as required to

allow for this delay.

Press the REDIAL

button at the required

point when storing a

number. The pause is

stored in the memory.

When dialling

normally, pressing the

REDIAL button will

enter a pause in the

number

Lift the handset.

Press the QUICKDIAL

button.

Press the 0-9location

under which the number

you require is stored.

The phone number is

dialled automatically.

Telephone numbers

longer than 16 digits

can be stored by

entering the first 16

digits in one memory

location, then storing

the remaining digits

under a second

memory location.

To redial a number

To dial numbers

longer than 16

digits To store a pause

To dial a number

stored in the

Quickdial memory

QUICKDIAL

Storing numbers

longer than 16

digits

REDIAL

If your Duet 450 Clock

Telephone is

connected to a

switchboard, the R

button enables you to

use the switchboards

special features.

Please contact your

communications

manager or

switchboard supplier

for further details.

The Rbutton is also

used in connection

with BT Select

Services. For more

information contact

BT Free on 152 for

residential customers

or 154 for business

customers 8am-6pm,

Monday to Friday.

The secrecy button

allows you to talk to

someone whilst on a

call, without the

person at the other

end of the line hearing

your conversation.

During a call, press

and hold down the

SECRECY button. Your

caller will not be able

to hear you.

Release the SECRECY

button to talk to your

caller again.

Using the R (Recall)

button

Please note:

If you are using the R

button as part of a stored

number, it must be

followed by a pause. See

‘To store a pause’

Using the Secrecy

button

SECRECY
