BCE 4012IM
CD-ReWritable Drive
User’s Manual
CLASS 1 LASER PRODUCT
APPAREIL A LASER DE CLASSE 1
LASER KLASSE 1
LUOKAN 1 LASERLAITE
PRODUIT LASER
CATEGORIE 1
DANGER INVISIBLE LASER RADIATION WHEN OPEN AVOID DIRECT EXPOSURE TO BEAM
VORSICHT INSICHTBARE LASERSTRAHLUNG WENN ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETSEN
ATTENTION RADIATION DU FAISCEAU LASER INVISIBLE EN CAS D’OUVERTURE. EVITER TOUTE EXPOSITION
AUX RAYONS.
Copyright Statement
It is a criminal offence, under applicable copyright laws, to make unauthorised copies of
copyright-protected material, including computer programs, films, broadcasts and sound
recordings. This equipment should not be used for such purposes.
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interference that may
cause undesired operation.
FCC Warning Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can emit radio frequency energy and, if not installed or used
in accordance with the instructions, may cause interference to radio communications.
However, television reception interference can be determined by turning the equipment off
and on. The user is encouraged to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment into an outlet different from that to which the receiver is
connected
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FOR EUROPE
“The drive is in conformity with the EMC directive and low-voltage directive.”
Table of Contents
INTRODUCTION 1
SYSTEM REQUIREMENTS 1
PACKAGE CONTENTS 2
INSTALLATION 3
HOST INTERFACE CONNECTIONS 3
HARDWARE INSTALLATION 4
DRIVER INSTALLATION 6
Windows Environment 6
DOS Mode 6
SOFTWARE INSTALLATION 6
Windows Environment 6
CONNECTION & OPERATION 7
FRONT PANEL 7
REAR VIEW 8
TECHNICAL DATA 10
TROUBLESHOOTING 13
BCE 4012IM CD-ReWritable Drive
1
INTRODUCTION
BCE 4012IM is a half-height CD-ReWritable drive of standard IDE
interface. It supports maximum 40x speed writing ability on CD-R discs,
12x speed on CD-RW discs and 48x speed reading performance. The
drive backs up all writing modes and different CD formats and it
automatically recognizes the media placed in the drive, whether a CD, a
CD-R or a CD-RW. With the bundled CD-RW mastering software, BCE
4012IM is an ideal model for creating customized audio and data CDs,
and for archiving or distributing big files to achieve data interchange and
backup. Here are some important features of BCE 4012IM CD-
ReWritable drive:
♦ 8X, 16X, 20X, 24X, 32X and 40X writing speed on CD-R media
♦ 4X, 8X, 10X and 12X writing speed on CD-RW media
♦ Adopts Buffer Underrun Prevention technology
♦ Supports MultiRead function
♦ Supports writing modes of TAO, DAO, SAO and packet writing
♦ Large internal buffer: 2MB
♦ Advanced dust-sealed design
♦ Low power consumption
♦ Firmware upgrade possibility via Flash Memory
System Requirements
For IBM compatible PCs, the system requirements recommended
are as follows:
♦ PC sufficient to run Windows 95/98/ME or WindowsNT/2000/XP
♦ Pentium II 300MHz above with at least 64MB of memory
BCE 4012IM CD-ReWritable Drive
♦ Fast and sufficient hard disk space (minimum 150MB for
installation, 1GB or more is recommended.)
♦ IDE host interface supporting ATAPI MMC command
♦ Operating system: Microsoft Windows 95/98/ME or Windows
NT/2000/XP
Package Contents
♦ BCE 4012IM CD-ReWritable drive
♦ Audio cable
♦ Data cable
♦ Application software disc (optional)
♦ CD-RW blank disc (optional)
2
BCE 4012IM CD-ReWritable Drive
INSTALLATION
Host Interface Connections
Most current mainboard models have two IDE ports (primary and
secondary) which can connect two IDE cables. Two IDE cables
allow you to connect up to four devices, but it is recommended that
you separate IDE ports for your hard drive and your CD-ReWritable
drive. This will ensure that your hard drive’s performance and speed
won’t be affected by having the CD-RW drive on the same cable.
If you connect only one device on the cable, you can set the jumper
as “master” or “slave”.
If you connect two devices (e.g. CD-ROM & CD-RW) on the same
cable, set different jumper for each device (CD-ROM as “master”,
CD-RW as “slave” and vice versa.) The same rule goes for the
connection of having your hard disk and one other device on the
same cable.
MASTER
CSEL
SLAVE
JUMPER
3
BCE 4012IM CD-ReWritable Drive
4
You may consider one of the two ways recommended below to
connect your drive.
♦ To get the most stable performance for the CD-RW drive to write:
Primary IDE Master: Hard Disk
Primary IDE Slave: CD-ROM Drive
Secondary IDE Master: CD-RW drive
♦ For best hard disk performance:
Primary IDE Master: Hard Disk
Secondary IDE Master: CD-ROM drive
Secondary IDE Salve: CD-RW drive
Hardware Installation
1. Turn off the power to the computer system and all peripheral
devices.
2. Disconnect all cables and connectors from the back of your
computer, then remove the cover from the computer.
3. Insert the CD-ReWritable drive into one of the vacant 5.25" drive
bays and secure it with screws to your PC.
In order to prevent interference between the CD-ReWritable drive and the
computer, please make sure to mount the drive using all four mounting
screws.
4. Connect the 40-pin IDE cable from one of the IDE ports on the
mainboard to the 40-pin connector of your CD-ReWritable drive.
Also, connect the power supply cable to the back of the CD-
ReWritable drive.
BCE 4012IM CD-ReWritable Drive
The red-edge of the IDE Cable must be connected to Pin 1 on the CD-
ReWritable drive.
5. If you have a sound card that can be connected to this CD-
ReWritable drive, you can connect the drive (as Audio-out) and the
sound card (as Audio-in) with a 4-pin audio cable. (See figure above.)
If your mainboad is integrated with built-in sound system, plug the 4-
pin audio cable into the CD-IN connector on the mainboard as
Audio-in.
6. Reinstall the cover of your computer, and reconnect the power
supply.
5
BCE 4012IM CD-ReWritable Drive
6
Driver Installation
Windows Environment
BCE 4012IM is a PnP device, and Windows 95/98/ME and Windows
NT/2000/XP can automatically detect the drive and load the
appropriate driver. If Windows cannot detect the drive, you can
operate manually:
1. Click the Control Panel Icon in My Computer and then click
Add New Hardware. The Add New Hardware window appears.
2. The program will automatically search for your new drive and
load the appropriate driver.
DOS Mode
If you need the device driver for DOS, please access the following
web sites to download:
Taiwan – http://www.btc.com.tw
U.S.A. – http://www.btcusa.com
Europe – http://www.btceurope.nl
Software Installation
The bundled mastering software gives you the complete solution for
making audio/data CDs right from your desktop. It allows you to copy
files from your computer to a recordable compact disc. In addition,
the audio CDs you create can be played in your home or car CD
player. For the CD-RW media, you can write and erase data on the
CD as you do with a floppy disk.
Windows Environment
(1) Run install.exe or setup.exe
or
(2) Refer to the manual in the software disc.
