Buffalo TeraStation Manuale utente
4 post rack mounting bracket (inner) ............
2
4 post rack mounting bracket (outer) ............
2
2 post rack mounting bracket ........................
2
hand screw..................
6
M4 screw.....................
4
M5 screw.....................
4
inch screw...................
4
cage nut......................
4
Attach brackets cto the TeraStation with screws
e.
Attach the TeraStation to the rack with screws f
or g.
Installation is now complete.
a
b
c
d
e
f
g
h
c
c
Phillips screwdriver.
e
e
fg
or f g
or
35010999 ver.02 1-01
Rack Installation
Rack Installation
TeraStation
12
Installation
1
A B
IncludedParts
2-A Round Holes (2 post)
Aretheholesinyourrackroundorsquare?
Next Page
Phillipsscrewdriver.
e
Phillipsscrewdriver.
②
②
①
①
Secure with hand
screw d.
cutouts
mounting hole
15.875mm
15.875mm
①①
②
cutout
mountinghole
15.875mm
②
b
b
d
a
a
d
d
dc
ce
for gfor g
d
d
Installation
2-B Square Holes
1
Attach the outer rack mounting brackets bto the
back side of the rack and secure them with hand
screws d.
2
Slide the inner rack mounting brackets a into
brackets bfrom the front, then secure them with
hand screws d.
3
Slide the TeraStation into the rack until it clicks into
place. Secure with hand screws d.
1
Insert 4 cage nuts hinto mounting holes in the
rack.
2
Attach brackets cto the TeraStation with screws e.
3
Attach the TeraStation to the rack with screws f or
g.
Hint: Hook one tab of
each cage nut, then use a
flat-head screwdriver to
insert the other tab.
4 post rack
2 post rack
Back
Front
Back
Front
Front
Back
Installation is complete. Installation is complete.
