BURY EasyTouch Manuale utente

BURY EasyTouch

Index

Introductory information 2

1. General 2

2. Security guidelines 3

Installation of the system 6

3. Scope of supply 6

4. Instructions on battery 8

5. Positioning and mounting 9

First steps 12

6. Using the hands-free car kit for the first time 12

7. Establishing a

Bluetooth

connection 13

Operating guidelines 15

8. Accepting, making, ending calls 15

9. Other operating options 19

Further Information 22

10. Service 22

11. Appropriate use of this system 23

12. Approvals and declaration of conformity 24

2Introductory information

1. General

Dear customer,

Congratulations on purchasing a BURY hands-free car kit. You have chosen a high quality product

that is extremely easy to use.

Please read the operating manual carefully so that you can fully enjoy your BURY hands-free car kit.

If you have any further questions concerning installation or operation of your car kit, please contact

your dealer. He will be happy to give you reliable advice.

You can also contact our hotline. Our phone and fax numbers are listed in the chapter Service at

the end of the operating instructions.

Have a good trip!

2. Security guidelines

Installation - who and where

The installation of this system can be carried out by yourself but

please observe any installation requirements issued by the

automotive manufacturer. During the installation, park the car at a

place where the road traffic is not impaired.

Power supply

This hands-free car kit is designed for use in vehicles independent

of the available power supply, whether 12 or 24 volts. The system‘s

battery can, however, be charged from both power networks via the

cigarette lighter plug (car and HGV). The supply voltage is

appropriately adjusted.

Exclusion of Liability:

Please comply with the laws and regulations concerning the

e-certification and the use and installation of electronic systems in

vehicles which are particular to your country. If you do not know

these, please inform yourself of them appropriately. In case of

doubt, only charge the battery of the hands-free car kit using the

car cigarette lighter plug when the vehicle is stationary. Please do

not hesitate to call our hotline if you have any questions concerning

these matters.

Introductory information

Position, volume

Install the components of the device in the vehicle so that your field

of vision is not impaired and the components are not mounted in the

impact zone of the passenger compartment or in the airbag inflation

zones.

Intended use

We shall not be liable for damages or malfunctions due to improper

use of the hands-free system. Therefore, do not expose the device

to moisture, extreme temperatures or shocks and carefully follow

the procedure described in the installation and operating

guidelines.

Use while driving

Operate the system only when the situation allows it and when you

do not endanger, harm, constrain, or annoy other road users. The

volume of the device has to be set in a way that exterior noise is still

audible.

Faults

Do not commission the device if you detect or assume a defect. In

this case, contact a Bury specialised dealer or our hotline. Improper

repair efforts can be dangerous for you. Therefore, only skilled

personnel may perform inspections.

Important:

The driver is ultimately responsible for the safe opera-X

tion and control of their vehicle at all times. You should

never use a hand held phone, including sending or rea-

ding text or picture messages, while driving.

Research indicates that there is a risk to safety whenX

the driver of a motor vehicle is distracted and using a

mobile phone while driving can be a distraction.

The manufacturer strongly recommends that you useX

a hands-free solution for making telephone calls whilst

driving.

6Installation of the system

3. Scope of supply

The hands-free car kit (HFCK) is supplied with various components depending on the sales region.

However, the operating instructions apply to all variants.

Description of the components:

1) Hands-free car kit

2) Sun visor clip

3) Mini USB / USB cable

4) 12V/24V Cigarette lighter plug

5) Detailed operating instructions are available in the internet

6) Printed quick user guide

Note:

If certain components are added or omitted you will receive the corresponding infor-X

mation on a separate enclosure.

The BURY EasyTouch hands-free car kit has touch keys, an integrated battery, an on-off switch on

the right side, a mini USB port on the right side, a locking device for the sun visor clip and an

integrated, pull-out microphone.

Installation of the system

4. Instructions on battery

The hands-free car kit (HFCK) has an integrated rechargeable battery which remains activated for

approx. 350 hours when fully loaded. The battery guarantees up to 7 hours of hands-free talking

without the need for recharging. These values may differ depending on the settings and the use of

the hands-free car kit.

Please avoid charging the battery inside the vehicle in direct sunlight and the high interior

temperatures which can rapidly be reached in parked vehicles. In such cases, please remove the

HFCK and place it either in the door glove pocket or the glove box.

Please comply with the following temperature levels:

- Storage between -20 and +60 degrees Celsius

- Charging between 0 and +45 degrees Celsius

- Use between -20 and +60 degrees Celsius

If you do not comply with these temperature levels then the battery can get damaged and then it

is possible that the HFCK will fail to work.

Mounting on the sun visor

Depending on how you would like to attach the HFCK to the sun visor in the vehicle, you must slide

the sun visor clip onto the locking device on either side. Press the fastener on the locking device to

completely slide in the sun visor clip. The clip snaps into place with a click sound, as long as it has

been correctly slid into place.

Variant A:

Push the sun visor clip upwards and away from you onto the sun visor.

5. Positioning and mounting

Installation of the system

Variant B:

Push the sun visor clip downwards and towards you onto the sun visor.

Pulling out the microphone

Now pull out the integrated microphone from the hands-free car kit for optimal speech input.
