Bushnell ImageView 118213 Manuale utente

Model#: 118213

LIT. #: 98-0795/07-06

1.3 Megapixel

118213 QVC Imageview-1LIM.indd 1 8/17/06 10:19:03 PM

118213 QVC Imageview-1LIM.indd 2 8/17/06 10:19:03 PM

Congratulations on your purchase of the Bushnell ImageView®binocular! The

Bushnell ImageView binocular takes the technology of digital photography

and combines it with a high-quality compact binocular. This allows you

to observe sporting events, wildlife, scenic vistas or anything you would

normally use a binocular for, and then save the image in a built-in attached

digital camera. You can then download these images to your computer and e-

mail them to your friends and family, print off the picture using the included

software or save them in a photo album for future use. Before using the

product, please read the instructions contained in this manual and take time

to familiarize yourself with the different parts and features of the product.

118213 QVC Imageview-1LIM.indd 3 8/17/06 10:19:03 PM

CAMERA OPERATION INSTRUCTIONS

BUTTON DESCRIPTIONS

The MODE button has three functions:

1. Power on: Press and hold the button until the

camera turns on. When the camera is connected

to a PC via the USB cable provided, the camera

will power on automatically.

2. Power off: While the camera is on, press and

hold the button until the camera turns off. If

the camera has not been used or if a button has

not been pressed for over 2 minutes, the camera

will automatically power off to save battery life.

If the camera is connected via USB, it will not

power off except when the PC power is off.

3. Mode change: press the button rapidly to change modes.

B. The SNAP button has two functions:

1. Take a picture: press this button to take a picture when the camera is

on. (But not in the PC mode or mode change.)

2. Select: in “Mode Change” press this button to confirm the function.

Mode Snap

118213 QVC Imageview-1LIM.indd 4 8/17/06 10:19:03 PM

LCD DISPLAY

1. High Resolution Mode = 1280x1024 Pixels

2. Low Resolution Mode = 640x480 Pixels

3. Select the timer to take a delayed picture. This gives you

approximately a 10-second delay.

4. This mode allows you to take short movie clips, saved as “.avi” files.

5. Select different resolution mode.

6. Deletes all the pictures in the memory.

7. Deletes the last picture taken.

8. SD mark appears when an SD card is inserted.

9. USB mark appears when USB cord is connected between the camera and the PC.

10. Battery mark keeps track of the battery life left.

11. a. Picture Number — This area will show the number of pictures in the memory.

b. SET — select HQ (high quality)/LQ (low quality) mode, STO (Mass Storage)/ PCC (PC

Cam) mode, 50Hz/60Hz frequency

c. FUL — When the memory is full , the display will show “FUL”.

OPERATION GUIDE

1. The camera is powered by two AAA alkaline (included), lithium or NiMh batteries .

2. Insert the batteries into the battery compartment. Insert an SD card ("upside down" with metal

contacts facing up) in the slot if greater storage is desired . You may use SD cards up to 512 MB.

3. Press and hold the MODE button until the camera turns on.

4. Press SNAP to take a picture, or press the MODE button quickly to change mode settings as described

above. The camera is set at infinity and will not be focused on an object closer than approx. 49 feet.

118213 QVC Imageview-1LIM.indd 5 8/17/06 10:19:04 PM

5. The mode setting operation is a cycle loop, so press the MODE button to switch to another mode.

The loop order of the different modes is shown here:

6. To change settings, toggle through the different modes by pressing the MODE button. When a

mode is selected, the indicator symbol on the LCD will appear. You can then select that mode by

pressing the SNAP button.

7. When in “Normal” mode, press SNAP to take a picture.

Press SNAP->

8. Pressing the MODE button will cause the camera to enter “Mode Change”.

9. To select “Self-Timer” mode, press MODE and the self timer mark appears. Press SNAP and the

capture will be done after 10 seconds. The camera exits self timer mode automatically after the

capture is done and the self timer mark disappears on the LCD at the same time.

Press MODE-> press SNAP to capture.

118213 QVC Imageview-1LIM.indd 6 8/17/06 10:19:04 PM

10.“Low Resolution” Mode will cause your pictures to be of a lower resolution, but allows you to store

many more pictures in the camera’s memory. The default setting is Hi resolution. To change the

resolution, press the MODE button until the “mode” icon appears. Press the SNAP button and

“Lo” will appear. The camera is changed from high resolution to low resolution. Repeat these steps

to return to the high resolution setting.

PICTURE CAPACITY WITH BUILTIN MEMORY: *May vary due to subject and lighting)

Pixels (resolution) Image quality Maximum Picture Capacity*

1280x1024(Hi) High quality (HQ) Up to 42 pictures

Low quality (LQ) Up to152 pictures

640x480(Lo) High quality (HQ) Up to 74 pictures

Low quality (LQ) Up to 285 pictures

11.When in “Normal” mode press the MODE button 3 times to enter the “AVI” mode.

The icon will appear. Press the SNAP button to start AVI capturing and counting.

The resolution for AVI is 320X240 pixels per frame (@10 fps). The AVI video clips

can last for up to 114 seconds (1 min, 53 sec) but this may vary depending on subject

and scene brightness.

118213 QVC Imageview-1LIM.indd 7 8/17/06 10:19:04 PM

12.To delete all pictures in the camera’s memory, select the “Delete” mode. Press the

SNAP button to confirm. The picture number will then blink. You will hear a tone

that becomes higher as the pictures are deleted. Once complete, the picture number

will reset to possible captured numbers.

13.If “Delete Last” icon appears, the display will show the following: Press SNAP to delete

only the last picture in the camera’s memory. The "total pictures taken" number will

be automatically decreased after deletion is done.

14.When an SD card is inserted into the card slot, the SD mark appears on the LCD.

The captured pictures will be stored in the SD card once the card is inserted. The total

picture capacity now depends on the memory capacity of the SD card.

15. Press the MODE button until SET mode appears on the LCD. Press SNAP to enter

Setting mode. To change the setting of image quality (default setting is High), Storage/

PC Cam (default setting is Storage), 50 Hz/60 Hz frequency (default setting is 60 Hz),

follow the steps below:

a. Select the image quality at HQ (High quality) or LQ (Low quality) by pressing the SNAP button.

Then press the MODE button to confirm and enter the next setting.

118213 QVC Imageview-1LIM.indd 8 8/17/06 10:19:05 PM

b. Select the STO (Mass Storage) or PCC (PC CAM) mode by pressing the SNAP button. Then press

the MODE button to confirm and enter the next setting.

c. Select 50 Hz or 60 Hz settings for the camera output by pressing the SNAP button. Then press the

MODE button to confirm and enter the next setting. The camera’s default mode is the “60” mode,

which matches the power frequency for the United States. To change to the “50” mode, press the

SNAP button until the “60” changes to “50.” Confirm the selection by pressing the SNAP button.

To avoid any flickering on the picture, the correct power frequency (either 50 or 60) for your country

must be selected.

d. Escape the Setting mode by pressing the SNAP button.

16.The battery mark keeps track of the battery life. If the “Battery” indicator is blinking, it is necessary

to replace the batteries soon. If the batteries are allowed to become fully drained before photos can be

downloaded from the internal memory (but not an SD card), the photos may be lost.

118213 QVC Imageview-1LIM.indd 9 8/17/06 10:19:05 PM

DOWNLOADING THE PICTURES TO YOUR COMPUTER:

1. The camera will be recognized as a USB mass storage device (if it is set to "STO" and not "PCC"),

which means no special drivers are required for all operating systems later than Windows 98 (Me,

2000, XP.) Mac OS 9 and OSX are also compatible. If you have a PC running Windows 98,

you must install the driver found on the included CD-ROM BEFORE CONNECTING THE

CAMERA TO YOUR PC.

2. If you have a computer OS as listed above that is USB mass storage compliant, a new disc icon will

appear in Windows Explorer (under “My Computer”) as a new “Removable Disc” after plugging in

the USB cable from the Imageview. Mac users will see the new disc device appear on their desktop.

Clicking on the new disc icon will show the contents, a folder named “DCIM.” The image folder

inside this contains your photos, stored as JPEGs (.jpg file format). They may then be opened,

edited, renamed and saved using any photo or graphics software that accepts .jpg files. If you do not

have software that will open .jpg files, you should install MGI Photosuite (Windows only) from the

included CD-ROM. See “Software Installation” for instructions.

3. After you have copied or opened and saved the photo files to your computers hard drive, you

may disconnect the Imageview camera (NEVER disconnect the camera while files are still being

transferred to your computer.) Before disconnecting, you should “eject” or stop the removable disc

representing the camera to avoid an error message.

118213 QVC Imageview-1LIM.indd 10 8/17/06 10:19:06 PM
