Cable matters 202041 Manuale utente

www.cablematters.com

USB 3.0 to SATA III

2.5” SDD/HDD Adapter Cable

Model 202041

User Manual

Table of Contents

1. INTRODUCTION.................................................................... 1

1.1 Introduction

1.2 Copyright and Trademarks

1.3 FCC Compliance Statement

2. PRODUCT OVERVIEW

2.1 Package Contents

2.2 Product Description ........................................................................2

2.3 Product Features

2.4 System Requirements

3. CONNECTION INSTRUCTIONS

3.1 Connecting the Cable Adapter .......................................................3

3.2 Disconnecting the Cable Adapter...................................................4

3.3 Formatting an SSD in Windows OS

3.4 Formatting an SSD in macOS ........................................................5

3.5 Troubleshooting Notes

4. TECHNICAL SPECIFICATIONS ........................................... 6

5. WARRANTY AND SUPPORT

5.1 Customer Support and Contact Information

5.2 Warranty Information

5.3 Limitations of Liability

www.cablematters.com

USB 3.0 to SATA SSD/HHD Adapter

1. Introduction

1.1 Introduction

Thank you for your purchase from Cable Matters® Inc., the ‘Reliable Connectivity’ company. This

User Manual provides an overview of the features and installation of your new

USB 3.0 to SATA 2.5” SSD/HDD Adapter Cable

Please read these instructions carefully before connecting, operating or configuring this product.

Please keep this manual for future reference. Contact [email protected] for questions or

product support.

1.2 Copyright and Trademarks

Specifications are subject to change without notice. Cable Matters is a registered trademark or

respective owners.

1.3 FCC Compliance Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: 1) This device must not cause harmful interference, and 2) this device must accept

any interference received, including interference that may cause undesired operation.

2. PRODUCT OVERVIEW

2.1 Package Contents

1 x USB 3.0 to SATA Cable Adapter

1 x User Manual

www.cablematters.com

USB 3.0 to SATA SSD/HHD Adapter

2.2 Product Description

The Cable Matters® USB 3.0 to 2.5” SATA SSD/HDD Adapter with UASP

support is a convenient way to connect a SATA 2.5 inch SSD/HDD to a

computer with USB 3.0. Increase your file storage or recover data from

another computer with this cable.

2.3 Product Features

• Connect a SATA 2.5” SSD/HDD to a computer with a USB port

• Portable adapter is easy to store or carry in a laptop bag

• No tools, enclosures, or external drivers required

• Back-up files, recover data, or upgrade a laptop hard drive

• No external power needed with USB power for most applications

• Optional Micro-USB port to boost power to an SSD

• (Micro-USB power cable sold separately)

• Enjoy faster SATA transfer speeds than a regular external hard drive

• Ultra fast data transfer with support for UASP enabled equipment

• Connect a 3 foot USB 3.0 extension cable for more flexibility

• Backwards compatible with USB 2.0 ports (at a lower transfer speed)

2.4 System Requirements

Computer USB 3.0 or 2.0 port for adapter cable

USB 3.0/2.0 computer port or wall charger to

connect optional Micro-USB power

Supported OS Windows XP/Vista/7/8/8.1/10,

Mac OS 10.4 and up, Linux

SSD/HDD 2.5 inch SATA SSD/HDD

(3.5 inch drives are NOT supported)

www.cablematters.com

USB 3.0 to SATA SSD/HHD Adapter

3. CONNECTION AND OPERATION

3.1 Connecting the Cable Adapter

Note: Review the documentation of your SSD/HDD for

proper handling of the drive and formatting instructions

1. Connect the SSD to the SATA connector of the adapter with

the Cable Matters logo side facing up

2. Connect the USB connector to a USB port on the computer

3. Software drivers for the adapter will automatically load

4. If the drive is not recognized or it will not spin:

• Attempt to safely remove or eject the drive

• Unplug the adapter

• Connect a Micro-USB power cable to the Y cable and to power

• Reconnect the SSD and plug in the cable

NOTES: A new SSD must be formatted before use. See below.

Moving the SSD while it is transferring files can cause damage

SATA 7 + 15 Pin

Connector

IMPORTANT NOTE:

Connect a Micro-USB

power cable BEFORE

connecting the

adapter

www.cablematters.com

USB 3.0 to SATA SSD/HHD Adapter

3.2 Disconnecting the Cable Adapter

Note: Always use the Safe To Remove hardware or Eject function before

unplugging the SSD from the computer to prevent drive damage

Windows OS removal

1) Right-click on the ‘Safely Remove

Hardware and Eject Media’ icon in

the taskbar/notification area

2) Select the device with the SSD name

3) Wait for the notification to appear before disconnecting the cable

MAC OS removal

1) Locate the SSD name from the

Finder Menu and click on the eject

button

2) Wait 5 seconds before disconnecting the cable

3.3 Formatting an SSD/HDD in Windows OS

1. Locate the SSD from the Control Panel >

Administrative Tools > Computer Manage-

ment > Disk Management

2. Right-click on the SSD to open the ‘New

Simple Volume Wizard’ to initialize and format the drive

3. The SSD should be listed as ‘Healthy’ in

the Disk Management window

4. Right-click on the drive to make additional

format changes

5. Use the Safe To Remove hardware function when finished

www.cablematters.com

USB 3.0 to SATA SSD/HHD Adapter

3.4 Formatting an SSD/HDD in macOS

1. Open Disk Utility from the Finder > Go > Utilities

2. Click on the ‘Erase’ tab to format a new drive

3. Click on the Eject button when finished

3.5 Troubleshooting Notes

• Review the documentation of your 2.5” SSD/HDD for proper handling of the drive,

formatting, cloning and other usage instructions

• If the drive is not recognized by your computer or will not spin: Disconnect every-

thing, connect a Micro-USB power cable, and then reconnect the adapter

• Verify that all connections are snug and secure

• Check the Storage controllers and USB controllers under the Device Manager in

Windows. Right-click on any devices with errors and update the driver software

• The transfer speed is limited by the USB port of the host computer

• Always use the Safe To Remove Hardware (Windows) or Eject (Mac)

function before disconnecting the cable

• Check that your computer recognizes the adapter:

WINDOWS: Control Panel > Device Manager > Storage controllers > USB Aached SCSI

(UAS) Mass Storage Device

MAC: Apple Menu > About this Mac > System Report > System Informaon > USB > USB

3.0 SuperSpeed Bus ASM105x

www.cablematters.com

USB 3.0 to SATA SSD/HHD Adapter

4. TECHNICAL SPECIFICATIONS Model 202041

Adapter Connections 1 x USB 3.0 Type A male

1 x SATA (7+15 pin) receptacle

1 x Micro-USB 4” Y-Power Port

Cable Length 19.7 Inches

Hard Disk Drive Support: SATA I, II, III 2.5” SSD/HDD

Max Data Transfer Rate USB 3.0 5 Gbps / UASP 6 Gbps

Chipset ASM105x

OS support Windows, Mac, Linux

Warranty Limited One-Year

5. Warranty and Support

5.1 Customer Support and Contact Information

Cable Matters offers lifetime technical support as an integral part of our

commitment to provide industry leading solutions. Email us with any ques-

tions at support@cablematters.com.

5.2 Warranty Information

This product is backed by a limited one-year warranty. The warranty covers

parts and labor costs only. Cable Matters does not warrant its products

from defects or damages arising from misuse, abuse, or normal wear.

5.3 Limitation of Liability

In no event shall Cable Matters Inc. (including their officers, directors,

employees or agents) be liable for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits,

loss of business, or any pecuniary loss, arising out of, or related to the use

of this product exceeding the actual price paid for the product (as allowed

by state law.

V2 11/2017
