CAMBRIONIX SS15 Manuale utente

User Manual

SS15

2023-01

SS15 Página 1 de 38

1. Table of Contents

1. Table of Contents 1

2. Your SS15 at a glance 3

2.1. Key Features 3

3. Safety 4

3.1. Signal word panel 4

3.2. Safety alert symbol 5

3.3. Pictograms 5

3.4. Product modification 5

3.5. Power supply 6

3.6. Storage and Installation 7

4. Getting Started 8

4.1. Opening your product 8

4.2. What's Included 8

4.3. Conexión a la red eléctrica 9

4.4. Conexión al host 9

4.5. Charging 9

4.6. Cables 10

4.7. Registration 10

4.8. Help and Support 10

5. Using your SS15 11

5.1. Using without connecting to host 11

5.2. Using when connected to host 11

5.2.1 Connecting the Hub to a host computer 11

5.2.2 Charging 11

5.2.3 Data Transfer 12

5.2.4 Protocolo e interfaz de comunicación 12

5.3. Scalability 14

5.4. Manage Ports & Your SS15 15

5.4.1 Port Modes 15

5.4.2 Switching port modes 15

5.4.3 Charging Profiles 16

5.4.4 Firmware 16

5.5. Software 18

5.5.1 Installing Software 18

5.5.2 LiveViewer 19

SS15 Página 2 de 38

5.5.3 Cambrionix API 20

5.5.4 Updating Software 20

5.5.5 Removing Software 21

5.5.6 Command Line Instructions (CLI) 22

5.6. Cleaning your SS15 23

6. Product Specifications 24

6.1. Requisitos de la alimentación entrante 24

6.2. Potencia de salida 24

6.3. Valores de riel de bandera de error 24

6.4. Especificaciones físicas 24

6.5. Información empaquetada 25

6.6. Consumibles y realización de pedidos 25

6.7. Power Supply 26

7. Troubleshooting 28

7.1. Initial troubleshooting tips 28

7.2. Logging through LiveViewer 28

7.3. Fallo de hardware 28

7.4. Device connection. 29

7.5. Hub connection issues 30

7.6. No GUI 31

7.7. Software troubleshooting 32

8. Disposal 33

9. Returns and Damaged Products 34

9.1. What do I do if my order arrives and something the product is

faulty or is physically damaged? 34

9.2. What happens after I have requested a Return? 34

10. Compliance and Standards 35

SS15 Página 3 de 38

2. Your SS15 at a glance

The SS15has been designed primarily for desktop use, being highly compact and quiet. It

provides 10W of charging power to each of its 15 x USB 3.2 Gen 1 Tipo-A ports, allowing mobile

devices to be charged quickly, safely and reliably. All ports can be controlled using Cambrionix

software to enable charging and data transfer while monitoring important port and device

information.

The SS15 can charge attached USB devices without using a local computer, and our intelligent

charging algorithm allows almost any device to be charged at its optimum rate (up to 2,1A). The

firmware can be updated to enable new charging profiles, ensuring the SS15 can charge the

latest devices. It is ready to charge out-of-the-box and sync devices when attached to a host

computer.

When a local (host) computer is connected, the host can control the operation of the ports

using available software. Device charging and synchronisation can be monitored through

Cambrionix’s LiveViewer App, the Application Programming Interface (API) or Command Line

Interface (CLI). Cambrionix’s free monitoring and control software can be downloaded from

www.cambrionix.com/software

2.1. Key Features

Up To

5Gbps

per Port

Up To

2,1A

per Port

Up To

Devices

Transfer Data Seamlessly Power Scalability

Each high-speed port can

transfer data up to 5Gbps

Each port can charge devices

up to 2,1A (10W)

Up to 85 devices can be

connected at once using

multiple hubs

SS15 Página 4 de 38

3. Safety

This user manual is for informational purposes only, it contains information for the start-up and

operation of this product. Note: the contents and the product described are subject to change

without notice. To avoid injuries and damage, observe the safety instructions in the user

manual.

This manual has been arranged to follow IEC/ICEE 82079-1 standard. This is to facilitate the

easier understanding and location of information relating to the SS15. Any errors or omissions

can be reported using our support ticket system (seeHelp and Support). This way, any issues

can be collected and fixed.

Understanding and observing the instructions in this user manual are prerequisites for

hazard-free use and safety during operation. This user manual cannot cover all possible

applications. If you would like additional information or if problems arise that are not

sufficiently addressed in this manual, please ask your distributor or contact us directly using

the means preferred, which are located on the back cover of this manual.

PRECAUCIÓN

Personal Injury and Damage to the product

lObserve the safety instructions in this user manual

3.1. Signal word panel

Depending on the probability of serious consequences, potential dangers are identified with a

signal word, the corresponding safety colour, and if appropriate, the safety alert symbol.

PRECAUCIÓN

Indicates a potentially hazardous situation that, if not avoided, may result in moderate

or minor (reversible) injury.

PRECAUCIÓN

Indicates a potentially hazardous situation which, if not avoided, may result in damage

to the product and its functions, or to property in its proximity.

SS15 Página 5 de 38

3.2. Safety alert symbol

Use of the safety alert symbol indicates a risk of injury.

Observe all measures that are marked with the safety alert symbol in order to avoid

injury

3.3. Pictograms

Warning Signs

Electrical hazard Fire Hazard

Mandatory action signs

Read operating instructions Mandatory regulation

3.4. Product modification

Cambrionix products are designed and manufactured to meet the requirements of UK and

International safety regulations. Modifications to the product could affect safety and render

the product non-compliant with relevant safety standards, resulting in injury or damage to the

product.

PRECAUCIÓN

An electric shock or personal injury may occur

lDo not modify the product in any way.

lDo not dismantle the product.

SS15 Página 6 de 38

PRECAUCIÓN

Fire, or personal injury may occur

lDo not obstruct air vents on the product.

lDo not cover the product in combustible material.

PRECAUCIÓN

Damage to your product may occur

lDo not bend or compress any part of the product.

3.5. Power supply

This section describes the safety precautions you must follow when using the power supply.

PRECAUCIÓN

An electric shock or personal injury may occur

lDo not use a damaged power cord or plug, or a loose power socket.

lDo not touch the power plug with wet hands.

lDo not allow liquids to come into contact with the unit or power supply.

PRECAUCIÓN

Damage to your product may occur

lDo not short circuit the Power Supply Unit (PSU) supplied with your

product.

lDo not disconnect the power cord while the product is being used.

lDo not bend or pull the power cord with excessive force.

lDo not use a power supply that exceeds the power supply specifications

within this manual

SS15 Página 7 de 38

3.6. Storage and Installation

This section describes safety precautions you must follow when installing and storing your

SS15.

PRECAUCIÓN

An electric shock or personal injury may occur

lDo not place the power cord near heat sources.

lConnect the plug to an earthed socket.

PRECAUCIÓN

Damage to your Cambrionix product may occur

lOperate the product only in an environment where the ambient

temperature is inside the operating temperature range.

lOperate the product only in an environment where the relative humidity is

inside the operating range.

lBe careful not to leave the power cord underneath a heavy object.

PRECAUCIÓN

Overheated power sockets may cause a fire

lDo not overload the power socket that your hub is connected to.

lInsert the power plug all the way into the socket so that it is not loose.

SS15 Página 8 de 38

4. Getting Started

This manual provides a reference for end-users installing for the first time and using their hub

after that. As well as a guide for product safety-related information.

The SS15 is intended to be used in an indoor static environment in which the environment falls

within the tested specifications to provide charge, sync and management functionality. Please

see the physical specifications section of this manual for information on the environment

specifications.

4.1. Opening your product

When you have received your product, please check the packing slip to ensure all contents and

quantities are correct before opening. This is to avoid retesting and repackaging any items that

are not required.

When opening the packaging, use a suitable method to open the box i.e, do not use a knife. This

is to ensure the product is not damaged.

PRECAUCIÓN

Personal Injury and Damage to the product

lThere will be a sticker on the hub advising you to read the User manual before use.

This will need to be removed before use as it may be covering host ports, vents

etc.

4.2. What's Included

lUSB 3.2 Gen 1 Tipo-A Cable (to provide communication between the host system and

hub)

lSS15 Hub

l2m Mains power cable (Country specified on order including fuse for the UKplugs)

lPower Supply Unit

Parte Descripción número de parte

USB 3.2 Gen 1 Tipo-A updater cable 200344

Unidad de fuente de alimentación 200421

SS15 Página 9 de 38

Parte Descripción número de parte

Reino Unido cable de alimentación 200144

Cable de alimentación de EE. UU. 200327

Cable de alimentación de la UE 200329

Cable de alimentación australiano 200337

Cable de alimentación IND 200341

4.3. Conexión a la red eléctrica

Connect the Power Supply Unit (PSU) to the hub using the DIN de 4 pines plug. Conecte el cable

de alimentación a la fuente de alimentación. Siempre cumpliendo las normas de seguridad

locales, conecte el cable de alimentación a la toma de corriente de 100 – 250VCA y encienda el

hub utilizando el pequeño interruptor de alimentación adyacente al conector de entrada de

alimentación del hub. Cuando el dispositivo está encendido, se iluminará un LED rojo junto a la

entrada de alimentación. El hub ya está listo para cargar los dispositivos conectados.

Se deben realizar inspecciones periódicas de los cables de alimentación y de cualquier cable

USB para detectar cualquier signo de daño. Si encuentra algún daño, reemplace el cable dañado

antes de seguir usándolo.

4.4. Conexión al host

Once the power is connected, connect the SS15 to your host system using a USB 3.2 Gen 1 Tipo-

A cable. El uso de un cable de host incorrecto puede dar lugar a que el hub y todos los puertos

posteriores no sean reconocidos por su host.

Please note that USB specifications require a minimum 100 mA charge current to be delivered

during data transfer. As indicated in above, if the attached device has a BC1.2 compliant CDP

port, the device can draw up to 2,1A while transferring data.

4.5. Charging

Your SS15 will allow your device to charge at the maximum rate possible up to 2,1A. The way

that charging takes place is the SS15 will provide the device with a capability to charge and the

devices USB charging controller will determine the maximum amount of charge it wants to

draw down.

Altri manuali per SS15

Indice

Altri manuali CAMBRIONIX Interruttore

CAMBRIONIX

CAMBRIONIX SyncPad54 Manuale utente

CAMBRIONIX

CAMBRIONIX PP8S Manuale utente

CAMBRIONIX

CAMBRIONIX MultiCharger14-2.4A Manuale utente

CAMBRIONIX

CAMBRIONIX PowerPad15C Manuale utente

CAMBRIONIX

CAMBRIONIX U16S Manuale utente

CAMBRIONIX

CAMBRIONIX ThunderSync3-C10 Manuale utente

CAMBRIONIX

CAMBRIONIX PowerPad15s Manuale utente

CAMBRIONIX

CAMBRIONIX PP8S Manuale utente

CAMBRIONIX

CAMBRIONIX PD-Sync4 Manuale utente

CAMBRIONIX

CAMBRIONIX PD-Sync4 Manuale utente

CAMBRIONIX

CAMBRIONIX SyncPad54 Manuale utente

CAMBRIONIX

CAMBRIONIX SS15 Manuale utente

CAMBRIONIX

CAMBRIONIX SuperSync15 Manuale utente

CAMBRIONIX

CAMBRIONIX TS3-C10 Manuale utente

CAMBRIONIX

CAMBRIONIX PowerPad8S Manuale utente

CAMBRIONIX

CAMBRIONIX PP8S Manuale utente

CAMBRIONIX

CAMBRIONIX MC14-2.4A Manuale utente

CAMBRIONIX

CAMBRIONIX TS3-C10 Manuale utente

CAMBRIONIX

CAMBRIONIX SS15 Manuale utente

CAMBRIONIX

CAMBRIONIX ThunderSync3-16 Manuale utente

CAMBRIONIX

CAMBRIONIX PowerPad15s Manuale utente

CAMBRIONIX

CAMBRIONIX TS3-C10 Manuale utente

CAMBRIONIX

CAMBRIONIX ThunderSync2-16 Manuale utente

CAMBRIONIX

CAMBRIONIX ThunderSync3-16 Manuale utente

Manuali Interruttore popolari di altre marche

URC

URC Total Control MFS-8 Manuale utente

Azbil

Azbil HPQ-D11 Manuale utente

Sony

Sony DFS-900M Manuale utente

SICK

SICK i17S Manuale utente

F&F

F&F SZR-277 Manuale utente

Shure

Shure UAMS/BK Manuale utente

Dräger

Dräger X-zone Switch Off Manuale utente

Asco

Asco Joucomatic 349 Series Manuale utente

BT Mini Hub Manuale utente

D-Link

D-Link DES-1226G Manuale utente

Johnson Controls

Johnson Controls FS80-C Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuale utente

MicroNet

MicroNet SP1200A Manuale utente

Ruijie

Ruijie RG-PF2920 Series Manuale di installazione e funzionamento

Altinex

Altinex DA1914SX Manuale utente

MiLAN

MiLAN MIL-SM2401M Manuale utente

RJM

RJM MASTERMIND PBC/6X Manuale utente

Atlas

Atlas MMK-KVM8 Manuale utente
