What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Power V2 Sucon Mount Camera Gripper (G-PM-01)
Assembly Manua l
Aluminum Rods
5x Rubber Grippers
3x Ball Tilt Head 2 x Rope Hooks
75mm Bowl
Head
Camera Mounng
Plaorm
2x Ropes
1/4” & 3/8”
Camera Mounng
Bolt Hard Case
2
Sucon cup mounts can be axed to just
about any smooth surface on any vehicle.
Large pin on the side of each unit, sucon
mounts are good to go.
Screw in the Ball Tilt Head on sucon cups.
Adjustable Ball Tilt Heads allow for an
extensive range of lockable posions for
Aluminum Rods.
Gripper Setup
Three adjustable length legs screw into the
adjustable locking ball lt heads at top of the
3 sucon cup mounts.
Tighten the knob of Ball Tilt Head to lock the
rods in a posion.
Screw in camera mounng plaorm to Rods.
NOTE: Three rods are provided for each length - 3”, 6” & 12”. These rods can be linked together in any
combinaon you need to create the perfect setup.
3
Now x both sucon cup with metal loops on
your vehicle.
Aach one end of Rope with metal Hooks to
camera mounng plaorm and another end
to Metal loop of Sucon cup. Tighten the
Rope properly.
Now loosen the four Allen bolts on Camera
plaorm, align 75mm bowl with it.
Re-insert the bolts and ghten with Allen key
properly.
Now mount your Fluid Head (Not Included)
on Bowl Head. And then secure your camera
set up on uid head.
To use Rope Hooks, press lever to loosen the
rope. Remove metal hook from Metal loop of
sucon cups.
4
Aach Rope Hooks to your vehicle, then
aach metal hooks to Rope Hooks and
ghten rope properly to secure your gripper.
You can also aach your camera set up
directly to camera mounng plaorm with
provided screw.
The Camera mounng plaorm of Power Mount Gripper has three leg aachment points that are each
ed with two posive locking ratchet joints, one for lt and one for swivel. Each locking ratchet joint
has a quick turn knurled lock ring for easy adjustment. You can unlock and lock each joint with a slight
twist.
To adjust lt or swivel of each leg, rst make sure lock ring on the appropriate joint is in the UNLOCK
posion, then adjust posion of the leg as per need. And then turn lock ring back in the LOCK direcon
so that the camera won’t shake from joint movement while the vehicle is in moon.
Swivel Adjustments
Tilt Adjustments
5
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
YOUR CAMTREE POWER V2 SUCTION MOUNT CAMERA GRIPPER
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
