Basic Guide

Describes the summary of

this product.

Advanced Guide

Describes the detailed

function of this product.

Troubleshooting

Page 1 of 1086 pagesCanon MX350 series On-screen Manual

How to Use This Manual

Printing This Manual

MP-4334-V1.00

Advanced Guide

Contents

Overview of the Machine

Main Components

How to Navigate Menus on the LCD

Preparing for Faxing

Confirming the Telephone Line Connection

Specifying the Basic Settings for Faxing

Setting the Receive Mode

Faxing

Sending Faxes

Using Various Sending Functions

Receiving Faxes

Using Various Receiving Functions

Using Useful Fax Functions

Printing from a Memory Card

Printing Photos Saved on the Memory Card /

USB Flash Drive

Using Various Functions

Inserting the Memory Card

Inserting the USB Flash Drive

Copying

Making Copies

Using Various Copy Functions

Scanning

Saving Scanned Data to the Computer

Using Various Scan Functions

Printing from Your Computer

Printing Photos (Easy-PhotoPrint EX)

Printing Documents

Other Usages

Printing the Template Forms such as Notebook

Paper

Printing Photos Directly from Your Digital

Camera or Mobile Phone

Machine Settings

Useful Software Applications

Loading Paper / Originals

Loading Paper

Loading Originals

Routine Maintenance

When Printing Becomes Faint or Colors Are

Incorrect

Replacing a FINE Cartridge

Cleaning the Paper Feed Roller

Appendix

Legal Limitations on Use of Your Product and

Use of Images

Tips on How to Use Your Machine

Page 2 of 1086 pagesMX350 series Basic Guide

Advanced Guide Troubleshooting

Contents > Overview of the Machine

Overview of the Machine

This section shows the component names of the machine and describes the basic operations you need

to know before using it.

Main Components

Front View

Rear View

Inside View

Operation Panel

How to Navigate Menus on the LCD

Basic Operation in Each Mode

Basic Operation on the Settings Screen

Other Operations

Page top

Page 3 of 1086 pagesOvervie of the Machine

Advanced Guide Troubleshooting

Contents > Overview of the Machine > Main Components

Main Components

Front View

Rear View

Inside View

Operation Panel

Front View

(1) ADF (Auto Document Feeder)

Load a document to copy, scan, or fax. The documents loaded in the Document Tray are scanned

automatically one sheet at a time.

See Loading Documents in the ADF.

(2) Document Feeder Cover

Open when clearing jammed documents.

(3) Document Guides

Adjust these guides to match the width of document in the ADF.

(4) Document Tray

Open to load a document in the ADF. You can load two or more sheets of document of the same size and

thickness. Load the document with the side you want to scan facing up.

(5) Document Output Slot

Documents scanned from the ADF are delivered here.

(6) Paper Support

Supports paper loaded in the Rear Tray. Open it to load paper.

(7) Rear Tray

Load various sizes or types of paper which you can use on the machine. Two or more sheets of the same

size and type of paper can be loaded at the same time, and fed automatically one sheet at a time.

See Loading Paper .

(8) Paper Guides

Slide to align with both sides of the paper stack.

Page 4 of 1086 pagesMain Components

(9) Document Cover

Open to load an original on the Platen Glass.

(10) Wi-Fi lamp

Lights or flashes blue to indicate the wireless LAN status.

Lights: Wireless LAN active is selected.

Flashes: Printing or scanning over wireless LAN. Also flashes while searching for wireless LAN access

point during setup and when connecting to the access point.

(11) Paper Output Tray

Opens automatically when printing or copying starts and printed paper is ejected.

(12) Operation Panel

Use to change the settings of the machine or to operate it.

See Operation Panel.

(13) Scanning Unit Detection Button

Locks the Scanning Unit (Cover) while the Document Cover is open. This button is pressed down when the

Document Cover is closed, so that you can open the Scanning Unit (Cover). (You do not need to touch this

button.)

For information on the Scanning Unit (Cover), see Scanning Unit (Cover) .

(14) Direct Print Port

Connect a PictBridge compliant device such as a digital camera or the optional Bluetooth Unit BU-30* to print

directly.

See Printing Photos Directly from Your Digital Camera or Mobile Phone .

You can also insert a USB flash drive to this port.

See Inserting the USB Flash Drive.

* The Bluetooth Unit is not available in some countries or regions depending on the local laws and

regulations. For details, contact the service center.

Warning

Do not connect any equipment other than PictBridge compliant devices, the optional

Bluetooth Unit BU-30, and USB flash drives to the Direct Print Port of the machine. This

may cause fire, electric shock, or damage to the machine.

Important

Do not touch the metal casing.

Do not use the USB cable longer than around 10 feet / 3 meters to connect any PictBridge

compliant device to the machine since it may affect the operation of other peripheral

devices.

(15) Platen Glass

Load an original to copy, scan, or fax.

Page 5 of 1086 pagesMain Components

Rear View

(16) External Device Jack

Connect an external device such as telephone, answering machine, or modem of a computer.

Important

Do not touch the metal casing.

Note

Remove the Telephone connector cap to connect the external device.

(17) Telephone Line Jack

Connect the telephone line.

Caution

To avoid an electric shock, do not touch the metal casing.

(18) Wired LAN Connector

Plug in the LAN cable to connect the machine to a LAN.

Important

Do not touch the metal casing.

Note

Remove the LAN connector cap before connecting the LAN cable.

(19) USB Port

Plug in the USB cable to connect the machine with a computer.

Important

Do not touch the metal casing.

Do not plug in or unplug the USB cable while the machine is printing or scanning originals

with the computer.

(20) Power Cord Connector

Plug in the supplied power cord.

Page 6 of 1086 pagesMain Components

Inside View

(21) Ink Cartridge Locking Covers

Lock the FINE Cartridges into place.

(22) FINE Cartridge Holder

Install the FINE Cartridges.

The Color FINE Cartridge should be installed into the left slot ( ) and the Black FINE Cartridge should be

installed into the right slot ( ).

(23) FINE Cartridges (Ink Cartridges)

A replaceable cartridge that is integrated with Print Head and ink tank.

Note

For details on installing the FINE Cartridges, refer to the printed manual: Getting Started.

(24) Scanning Unit (Cover)

Scans originals. Open it to replace the FINE Cartridges or remove jammed paper inside the machine. When

opening the Scanning Unit (Cover), lift it with the Document Cover closed.

(25) Access lamp

Lights or flashes to indicate the memory card status.

See Inserting the Memory Card.

(26) Card Slot

Insert a memory card.

See Inserting the Memory Card.

(27) Card Slot Cover

Open to insert a memory card.

See Inserting the Memory Card.

(28) Scanning Unit Support

Holds the Scanning Unit (Cover) being opened.

Important

The area (A) indicated in the figure below may be splattered with ink. It does not affect the

performance of the machine.

Do not touch the area (A). The machine may not print properly if you touch it.

Page 7 of 1086 pagesMain Components

Operation Panel

(1) ON button

Turns the power on or off. Before turning on the power, make sure that the Document Cover is closed.

Important

Disconnecting the power plug

When disconnecting the power plug after turning off the power, be sure to confirm that all

lamps on the Operation Panel are turned off. If the power plug is disconnected from the

wall outlet while any lamp on the Operation Panel is lit or flashing, the machine may

become unable to print properly since the Print Head is not protected.

If the power plug is disconnected, the date/time settings will be reset and all documents

stored in memory will be lost. Send or print a necessary document, or save it on a memory

card or USB flash drive before disconnecting the power plug.

Note

The machine cannot receive faxes when the power is turned off.

The power cannot be turned off while the machine is sending or receiving a fax, or when

there are unsent faxes in the machine's memory.

(2) In Use/Memory lamp

Flashes when sending or receiving faxes, and lights when there are documents saved in the machine's

memory.

(3) COPY button

Switches the machine to the copy mode.

See Basic Operation in Each Mode.

(4) FAX button

Switches the machine to the fax mode.

See Basic Operation in Each Mode.

(5) LCD (Liquid Crystal Display)

Displays messages, menu items, and the operational status. You can also preview photos on the LCD

before printing.

Note

Page 8 of 1086 pagesMain Components

The LCD will turn off if the machine is not operated for about 5 minutes. To restore the

display, press any button except the ON button or perform the print operation. The display

will be also restored when receiving faxes.

(6) , , , and buttons (Scroll Wheel)

Used to select a menu or setting item. The or button is also used to enter characters.

See Basic Operation in Each Mode.

(7) OK button

Finalizes the selection of a menu or setting item.

Resolves an error when printing is in progress or resumes the machine's normal operation after removing

jammed paper or to eject documents remaining in the ADF.

(8) Numeric buttons

Used to enter numerical values such as the number of copies, as well as fax/telephone numbers and

characters.

(9) Redial/Pause button

Displays the list of numbers dialed with the Numeric buttons to redial the selected number. You can also

use this button to enter pause time between or after numbers when dialing or registering numbers for

example international calls.

(10) Coded Dial button

Displays the coded speed dial list or telephone number search list on the coded speed dial screen. You can

dial a recipient from the list.

(11) Stop button

Cancels operation when print, copy, scan, or fax transmission/reception job is in progress.

(12) Black button

Starts to make black & white copy, scan, fax transmission, etc. This button lights blue when available.

(13) Color button

Starts to make color print, copy, scan, fax transmission, etc. This button lights blue when available.

(14) Hook button

Connects or disconnects the telephone line.

(15) Tone button

Switches to tone dialing temporarily or changes the input mode when entering characters. This button is

also used to dial with the Numeric buttons.

(16) Back button

Returns the LCD to the previous screen.

(17) Function buttons

Used to select an item displayed at the bottom of the LCD.

See Basic Operation in Each Mode.

(18) CARD button

Switches the machine to the card mode.

See Basic Operation in Each Mode.

(19) SCAN button

Switches the machine to the scan mode.

See Basic Operation in Each Mode.

(20) Setup button

Displays the setup menu.

See Basic Operation in Each Mode.

(21) Alarm lamp

Lights or flashes orange when an error occurs, such as paper-out or ink-out.

Note

The machine makes the beep sound when pressing buttons on the Operation Panel.

Page 9 of 1086 pagesMain Components

To change the beep volume, see Machine Settings.

Page top

Page 10 of 1086 pagesMain Components

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Canon Stampante tutto in uno

Canon

Canon PIXMA MP610 Series Manuale utente

Canon

Canon MultiPASS F30 Manuale utente

Canon

Canon iR2200 Series Manuale utente

Canon

Canon imageCLASS X MF1643i II Manuale utente

Canon

Canon IMAGERUNNER ADVANCE C5051 Manuale di istruzioni

Canon

Canon PIXMA MP600 Manuale utente

Canon

Canon TS5140 Manuale utente

Canon

Canon MP980 series Manuale utente

Canon

Canon PIXMA MG3220 series Manuale utente

Canon

Canon Color imageCLASS LBP7660Cdn Manuale utente

Canon

Canon imageRUNNER 1435i Manuale utente

Canon

Canon Pixma MG7100 Series Guida all'installazione

Canon

Canon PIXMA MP620 series Manuale utente

Canon

Canon MF7280 - ImageCLASS B/W Laser Istruzioni di installazione e manutenzione

Canon

Canon LASERBASE MF3110 Manuale utente

Canon

Canon imageCLASS MF4450 Guida di sicurezza

Canon

Canon imageRUNNER 2545i Manuale utente

Canon

Canon IMAGERUNNER 2530 Manuale utente

Canon

Canon imagerunner advance C5550i Guida all'installazione

Canon

Canon MultiPASS C555 Manuale utente

Canon

Canon ImageCLASS MF5730 Manuale

Canon

Canon imageCLASS MF3010 Manuale utente

Canon

Canon PIXMA MP990 Manuale utente

Canon

Canon CFX-B380 IF Manuale utente

Manuali Stampante tutto in uno popolari di altre marche

Triumph Adler

Triumph Adler DC 2016 Manuale

Epson

Epson WorkForce WF-2510 Guida utente

Epson

Epson Stylus Scan 2000 Manuale di installazione e funzionamento

Epson

Epson PictureMate Snap PM 240 Manuale di istruzioni

Konica Minolta

Konica Minolta bizhub C35 Manuale utente

Brother

Brother MFC-J430w Manuale utente

Konica Minolta

Konica Minolta BIZHUB 558 Manuale utente

Lexmark

Lexmark MX710 Series Manuale

Brother

Brother MFC-9760 Manuale utente

Lexmark

Lexmark XC8155 Manuale utente

Lexmark

Lexmark X642E Manuale utente

Sharp

Sharp MX-2310U Guida

Aficio

Aficio 200 Manuale utente

Ricoh

Ricoh Pro C900 Manuale utente

Lexmark

Lexmark X925 Manuale utente

Brother

Brother Business Smart MFC-J4510dw Manuale utente

Epson

Epson Stylus CX8400 Series Manuale utente

Oce

Oce VarioLink 5022 Manuale utente
