Set-Up Sheet

Thank you for purchasing Canon imageCLASS MF5530.

To get your machine ready for use, please follow the instructions in this sheet before referring to any other documentation.

Unpack the machine and its components.

Check that you have the following:

●Machine ●Cartridge

●Power cord

●USB cable

●imageCLASS MF5500 Series User Software CD (MF5550/MF5530 Main Menu, NewSoft

Presto! PageManager, ScanSoft Omnipage SE, Software Guide)

●Documentation (Set-Up Sheet, Basic Guide, Registration Card, Limited Warranty Note,

Limited Warranty Note for Cartridge X25)

●Cassette extension ●Extension cover

Remove the shipping materials and install the cassette.

1Place the machine on a flat surface.

2Remove all shipping tapes from the exterior of the machine.

3Open the document feeder tray.

4Pull out the paper cassette completely. 5Attach the cassette extension to the cassette.

6Attach the extension cover on the back of

the machine.

7Insert the paper cassette back into the

machine.

Install the cartridge.

4Pull open the front cover by the indentations

on both sides of the machine.

1Remove the cartridge from the bag. Keep the

bag in a safe place for future use.

2Gently rock the cartridge several times to

evenly distribute the toner inside.

3Hold the cartridge on a flat stable surface with

one hand, and break the tab ➀and pull out

the seal ➁completely with the other hand.

Instructions

Arrow Mark

5Hold the cartridge so that the instructions are

facing up, and insert it in the machine

horizontally as far as it will go.

6Close the front cover of the machine.

Connect the power cord.

1Plug the power cord into the rear socket ➀.Then connect the other end of the cord

to the wall outlet ➁.

IMPORTANT

●Use of a power cord with ferrite cores (included) is required to comply with class limits in Subpart B of Part 15 of the FCC

Rules.

2When you connect the machine, the following messages should appear in the LCD.

IMPORTANT

●For important safety instructions on installation and handling of the machine, see p.xiii of the Basic Guide.

NOTE

●Make sure the correct paper size is specified in the machine. For details, see p. 2-7 of the Basic Guide.

Approx. 7 seconds

3Load the paper into the cassette. Make sure

the paper stack sits below the hooks.

5Even out the edges of the paper stack.

Make sure the height of the paper stack does

not exceed the limit marks .

6Insert the paper cassette back into the

machine as far as it will go.

Load paper.

Pull out the paper cassette completely.

2Pinch and slide the rear paper end guide to

match the size of paper.

Hooks

4Pinch and slide the side paper end guides to

match the size of paper.

Hook

NOTE

●If you do not completely insert the cassette into the machine, paper jams may occur.

Install the software and connect the machine to your computer.

IMPORTANT

●Do not connect the USB cable before installing the software. If you connect the USB cable before installing the software

and the Found New Hardware Wizard screen appears, click [Cancel].

NOTE

●The instructions below are for Windows XP. For Windows 98/Me/2000, see the Software Guide.

●For Windows 2000/XP, log on as Administrator to install the software.

1Turn on your computer.

2Quit any open applications, including virus checking software.

3Insert the imageCLASS MF5500 Series User Software CD into the CD-ROM drive.

4When the Canon MF5550/MF5530 Main Menu screen appears, click [Install Software].

●If the Main Menu screen is not displayed, on the Windows desktop, click [Start] ➝[My Computer].

Open the CD-ROM icon, then double-click [setup (setup.exe)].

5When the Canon Multi-function Printers InstallShield Wizard screen appears, click

[Next >] and follow the instructions on the screen.

6When the installation is complete, click [Finish] to close the InstallShield Wizard.

7When prompted to connect the USB cable, click [OK]. Make sure the machine’s power

is turned on, and connect the cable to the USB port on the back of the machine.

Then connect the other end of the cable to the USB port on your computer.

8Click [Exit] to close the MF5550/MF5530 Main Menu. Remove the imageCLASS

MF5500 Series User Software CD from the CD-ROM drive and store it in a safe place.

Part no. FA7-5197 (010)

Canon and imageCLASS are trademarks of Canon Inc.

All other products and brand names are registered

trademarks or trademarks of their respective owners.

Specifications subject to change without notice.

PRINTED IN CHINA

Congratulations! You have now completed setting up your

machine.

Where to go from here...

Once you have completed all steps in this sheet, see the Basic Guide for basic operations

of all functions of your machine.

For information on the accompanying software, see the Software Guide (included in the

CD-ROM).

NOTE

●Remember to register your machine to ensure product support. The serial number is located on the back of the

machine.
