Canon Color imageCLASS MF8350Cdn Guida di sicurezza

Read this guide first.

Please read this guide before operating this

product.

The remarks for important safety

instructions are described in "Basic

Operation Guide." Read the guide also.

After you finish reading this guide, store it in

a safe place for future reference.

Starter Guide

1 Preface

2 Installing the Machine

P. 4

Configuring and

Connecting the Fax

P. 11

Appendix

P. A - 1

Connecting to a Computer

and Installing the Drivers

P. 15

0-2

Setting Up the Machine to Suit Your Needs

Determine which machine functions (Copy, Print, Fax, PC Fax, Scan, Remote UI) you intend to use, and make settings

according to the flowchart below.

Copy Fax

Settings from

a Computer

Scan*

PC Fax

Scan

PC Fax

Required Operations

Preparing the Toner Cartridges P. 5

Loading Paper P. 6

Connecting the Power Cord P. 8

Registering the Sender Information P. 11

Fax Settings

Settings are now complete.

Carrying the Machine to the Installation Site and Removing the Packing Materials P. 4

Selecting the Receive Mode P. 12

Connecting a Telephone Line P. 13

Turning the Power ON and

Specifying the Initial Settings Language Settings Date and Time

Settings Color Correction P. 8

Settings for paper sizes and paper types are required after turning the power ON.

P. 10

Remote

Network

Connection

USB

Connection

Settings in a Computer

Installing the Software P. 1 6

Connecting a USB Cable P. 19

Connecting to a Network P. 15

Installing the Software P. 18

For Windows

Connecting a USB Cable P. 21

Connecting to a Network P. 15

Installing the Software P. 21

For Macintosh

: available : not available

Copy Print 2-sided

Printing

Fax

(PC Fax) USB Scan Network Scan

(Windows)

Network Scan

(Macintosh) Remote UI ADF

(1-sided)

ADF

(2-sided)

MF8350Cdn

Available Features

* Network scan can be performed only on Windows.

Checking the Supplied Accessories

1. Confirm that all the supplied

accessories are contained in the box.

If an item is missing or damaged, please contact our Canon

Authorized Service Facilities or the Canon Customer Care

Center.

The machine unit

The following parts are already

installed.

Paper cassette

Toner cartridges

•

Power cord

User Software CD-ROM

Limited Warranty Notice

Telephone cable

Speed dial label

Starter Guide (This manual) Basic Operation Guide

Legal dust cover

Supplied Toner Cartridges

The average yield of the included toner cartridges is as follows.

Average yield of K (Black) toner cartridge 1,200 sheets

Average yield of Composite C (Cyan), M (Magenta), and Y (Yellow) toner cartridges 1,400 sheets

The average yield is on the basis of "ISO/IEC 19798"* when printing A4 size paper with the default print density setting.

"ISO/IEC 19798" is the global standard relating to "Method for the determination of toner cartridge yield for color printers and multi-function devices that contain printer

components" issued by ISO (International Organization for Standardization).

For purchasing replacement toner cartridges, see "About replacement toner cartridges" in the e-Manual.

About the LAN cable

The machine does not come with a LAN cable

or a hub. Have cables or a hub ready as needed.

Use a Category 5 or higher twisted pair cable.

If you want to connect the machine to a 100BASE-TX

Ethernet network, all the devices to be connected to the

LAN must support 100BASE-TX.

•

Registration Card

Preface

Installing the Machine

Configuring and Connecting the Fax

Connecting to a Computer and

Installing the Drivers

Appendix

User Software CD-ROM

About the Drivers and Software

The drivers and software included in the CD-ROM supplied with this machine are as follows.

MF Drivers

Printer driver You can print from an application using the machine by installing the printer driver on your

computer. You can process print data at high speed by compressing the print data using the

computer's processing capabilities.

Fax driver If you install the fax driver on your computer, you can select “Print”from an application, select

the Canon fax driver as a printer, and specify the output destination and options. The fax driver

converts the data into an image that conforms to standard fax protocols so that the data can

be printed or saved using the recipient’s fax machine.

Scanner driver You can use the machine as a scanner if you install the scanner driver on your computer.

Network Scan Utility This software is required for using the scan functions via a network. This software is installed

with the scanner driver.

MF Toolbox

MF Toolbox MF Toolbox is a program which allows you to easily open an image scanned by the scanner in

an application, attach the scanned image to an e-mail, and store the scanned image in a hard

disk.

Additional Software Programs

Presto! PageManager This is software for managing scanned images.

: available : not available

Windows 2000/XP Windows Vista/7 Windows Server 2003/Server 2008 Mac OS X (version 10.4.9 or later)

Printer driver (Only for network connection)

Fax driver 2pt(Only for network connection)

Scanner driver (Only for USB connection)

Network Scan Utility

MF Toolbox (OnlyforUSBconnection)(Only for USB connection)

Presto! PageManager

Supported Operating Systems

About the Supplied Manuals

Read this manual first.

This manual describes the settings for

the machine and software installation.

Be sure to read this manual before

using the machine.

Starter Guide

Basic Operation Guide

e-Manual

Read this manual next.

This manual describes the basic

machine operations.

Read the desired chapter

to suit your needs.

The e-Manual is categorized by subject to

find desired information easily.

Determining the Installation Site

Front View

Paper

cassette Feeder cover

Feeder

Rear cover

in. (mm)

(100)

52 1/4 (1327)

26 3/4 (679)

37 1/2 (951)

33 1/2 (851)

Preface

Installing the Machine

Configuring and Connecting the Fax

Connecting to a Computer and Installing the Drivers

Appendix

•

Before Using the Machine

Document and Paper Handling

Copying

Printing from a Computer

Registering Destinations in the

Address Book

Using the Fax Functions

•

Basic Operation

Copy

Fax*

Print*

Scan*

Network Settings

Security

•

Setting and Managing from

Computer

Troubleshooting

Maintenance

Setting Menu List

Specifications

•

Using the Scan Functions

Maintenance

Troubleshooting

Registering/Setting the

Various Functions

Appendix

•

The e-Manual is included in the User Software CD-ROM.*

This manual

Preface

Installing the Machine

Configuring and Connecting the Fax

Connecting to a Computer and

Installing the Drivers

Appendix

If you are using Macintosh, see the following Driver Guides for more details on these functions.

Fax: User Software CD-ROM →[FAX] →[us_eng] →[Documents] →[GUIDE-FAX-US.pdf]

Print: User Software CD-ROM →[CMFP] →[us_eng] →[Documents] →[GUIDE-CMFP-US.pdf]

Scan: User Software CD-ROM →[ScanGear MF] →[us_eng] →[Documents] →[GUIDE-SCAN-US.pdf]

•

2. Remove the packing materials. The packing materials may be changed in form or placement, or may be added or

removed without notice.

1. Carry the machine to the installation site.

Carrying the Machine to the Installation Site

and Removing the Packing Materials

Hold the grips. Carry the machine with two or more people.

Open the rear cover.

Remove by

pulling gently.

Remove the packing materials.

Remove these packing

materials after.

Remove these packing

materials after.

Remove the packing materials.

A loud noise will occur when you open the rear cover or remove

the packing materials with tape.

Although a loud noise occurs when you remove the packing

materials inside the machine, this is not a malfunction.

Preparing the Toner Cartridges

Open the front cover.

1. Open the front cover and pull out the toner cartridge tray.

Press the lever.

Preface

Installing the Machine

Configuring and Connecting the Fax

Connecting to a Computer and

Installing the Drivers

Appendix

Close the rear cover.

Did you remove all the packing materials?

Check!

Tape x9

Packing materials with tape x2

Open the feeder.

Remove the packing

materials with tape. Close the feeder.

Remove the packing materials.

Remove by pulling gently.

Pull out the toner

cartridge tray.

3. Push the toner cartridge tray back in, and then close the front cover.

2. Pull out the sealing tapes on the four toner cartridges.

Did you remove all the

packing materials?

Check!

Sealing tape x4

Remove.

Hold down the

toner cartridge. Pull out the

sealing tape.

Close the front

cover.

Push in the

toner cartridge

tray.

1. Load paper in the paper

cassette.

Loading Paper

Hold the paper cassette with both hands.

Pull out the

paper cassette.

Load the paper.

When loading Legal size paper•

Hold the lock

release lever.

Adjust the length of

the paper cassette.

Make sure that the paper stack does not

exceed the line of the load limit mark.

Check!

Push in the paper cassette.

Hold the lock release lever and

slide the paper guides.

Slide the side paper guides.

Slide the paper guides to the

width of the loaded paper. Slide the paper guides to the

width of the loaded paper.

Up to here

Align the edge of the paper stack with the

rear side of the paper cassette. When using envelopes

For details on how to load media,

see "Basic Operation Guide."

Hold the lock release

lever and slide the paper

guides.

Spread the paper guides a

little wider than the actual

paper width.

Hold the lock release lever

and slide the paper guides.

Spread the paper guides a little

wider than the actual paper width.

Preface

Installing the Machine

Configuring and Connecting the Fax

Connecting to a Computer and

Installing the Drivers

Appendix

Set the paper under the hooks.

Load limit mark.

Hooks

When changing the size of the paper to be loaded

Be sure to register the paper size.

→"Setting a Paper Size and Type" (P. 10)

•

When loading Legal size paper

When the paper cassette is inserted with it

extended, the front side of the paper cassette

is not flush with the front surface of the

machine as shown in the figure.

•

Set the Legal dust cover on the

paper cassette.

Connecting the Power Cord

1. Turn ON the power of

the machine.

2. Specify initial settings.

Select with [ ] or [ ],

and then press [OK].

Turning the Power ON and Specifying the Initial

Settings

Make sure that the machine is off. Plug the power plug into the

power socket.

Plug the power

plug into a AC

power outlet.

Press the power switch.

Language

French

Spanish

Portuguese

English

Do not connect the USB cable. Connect the USB cable when installing the software.

Select with [ ] or [ ],

and then press [OK].

Check and press [OK].

Check that tabs/tape

are removed from

toner cartridge.

Select Country/Region

United States (US)

Canada (CA)

Brazil (BR)

Mexico (MX)

Check and press [OK].

Check that paper is

loaded in Drawer 1.

Altri manuali per Color imageCLASS MF8350Cdn

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Canon Stampante tutto in uno

Canon

Canon Color imageCLASS MF8350Cdn Guida di sicurezza

Canon

Canon PIXMA MG5420 Manuale

Canon

Canon MP280 Manuale utente

Canon

Canon 2711B019AB Manuale utente

Canon

Canon imageCLASS MF4100 Series Manuale utente

Canon

Canon imageRUNNER 1435iF Manuale utente

Canon

Canon iR3245 Scheda informativa del prodotto

Canon

Canon MF4010 Series Guida all'installazione

Canon

Canon PIXMA MX340 Series Manuale utente

Canon

Canon MF746Cx Manuale utente

Canon

Canon i-SENSYS MF6180dw Manuale utente

Canon

Canon MP980 series Manuale utente

Canon

Canon iR3245 Istruzioni di installazione e manutenzione

Canon

Canon image Runner 2206iF Manuale utente

Canon

Canon imageRUNNER ADVANCE 8105 Manuale utente

Canon

Canon imageRUNNER ADVANCE 500i Guida utente

Canon

Canon imageCLASS MF4890dw Guida di sicurezza

Canon

Canon LASER CLASS 730i Manuale utente

Canon

Canon PIXMA MG6220 Installing Manuale utente

Canon

Canon iR2020 Series Manuale utente

Canon

Canon imageRUNNER 4570 Manuale utente

Canon

Canon imageCLASS MF4570dn Guida di sicurezza

Canon

Canon PIXMA MX860 series Manuale utente

Canon

Canon MX470 Manuale utente

Manuali Stampante tutto in uno popolari di altre marche

Triumph Adler

Triumph Adler DC 2016 Manuale

Epson

Epson WorkForce WF-2510 Guida utente

Epson

Epson Stylus Scan 2000 Manuale di installazione e funzionamento

Epson

Epson PictureMate Snap PM 240 Manuale di istruzioni

Konica Minolta

Konica Minolta bizhub C35 Manuale utente

Brother

Brother MFC-J430w Manuale utente

Konica Minolta

Konica Minolta BIZHUB 558 Manuale utente

Lexmark

Lexmark MX710 Series Manuale

Brother

Brother MFC-9760 Manuale utente

Lexmark

Lexmark XC8155 Manuale utente

Lexmark

Lexmark X642E Manuale utente

Sharp

Sharp MX-2310U Guida

Aficio

Aficio 200 Manuale utente

Ricoh

Ricoh Pro C900 Manuale utente

Lexmark

Lexmark X925 Manuale utente

Brother

Brother Business Smart MFC-J4510dw Manuale utente

Epson

Epson Stylus CX8400 Series Manuale utente

Oce

Oce VarioLink 5022 Manuale utente
