Canon IMAGERUNNER 7095 PRINTER Manuale utente

Production Solutions

Document Handling Accessories

Canon Production-Class Finishing Accessories—

Bound To Increase Your Productivity

Document production is not complete until the output is

finished, meaning that completely collated sets are bound

and ready for immediate distribution.

Canon invites you to learn more about how the

imageR NNER 7105/7095/7095 Printer/7086 devices,

when properly equipped with advanced finishing accessories,

can meet your needs for professional document publishing.

The capabilities of these production-class imageR NNER

accessories now provide—in-house—what was previously

available to you only through outsourcing. Speak to your

authorized Canon sales representative to find out how you

can enhance the productivity and competitiveness of your

business with imageR NNER finishing solutions.

As your documents and applications become

more complex, Canon production imageR NNER®

devices can grow with you to deliver professional

document finishing solutions in-house.

Challenge Your System

Versatility E pectations

The imageR NNER 7105, imageR NNER 7095, imageR NNER 7095 Printer, and

imageR NNER 7086 devices are modular, allowing you to mix and match the paper

supply and advanced finishing accessories you need to meet your diverse publishing

requirements and drive productivity to new levels.

•Cassette-AB1

•Tab Feeding Attachment-A1

•Document T ay-L1

•Punche Unit-V1*

•Stacke Dolly-A1

•Punch Tools

•Finishe Option Powe

Supply Unit-R1

* The Professional Puncher-A1 cannot be installe simultaneously

with the Perfect Bin er-A1. The Professional Puncher-A1 an the

Puncher Unit-V1 can be installe simultaneously.

Check with your local Authorize Canon Dealer for availability.

Note: Some accessories require a itional equipment or may be

prerequisites for other options. Check with your local Authorize

Canon Dealer for etails.

The imageRUNNER 7095 shown with optional accessories.

The Professional Puncher-A1*

offers a number of optional

hole-punch tools to ready

documents for advanced

binding applications.

The standard Duplexing Automatic

Document Feeder makes quick work

of complex originals.

Add the Paper Deck-W1

or Paper Deck-X1 to

raise system paper

capacity to a maximum

of 7,650 sheets.

The Paper Folding

Unit-D1 -folds 11" x 17"

pages into document

sets with a finished

8-1/2" x 11" size.

The Finisher-V1 or Saddle

Finisher-V2 provides the

collating, stapling, saddle-

stitching, and optional punch-

ing flexibility required for busy

production environments.

Install the Document Insertion Unit-C1

on top of the Finisher Units to feed

booklet covers into job streams.

Add the Perfect Binder-A1* to produce

perfectly bound and trimmed books

with wraparound covers.

Attach the Booklet

Trimmer-C1 to the Saddle

Finisher-V2 to trim the

open end of booklets.

The High-Capacity Stacker-A1 s

neatly stacks sheets for long

periods of unattended opera-

tion. Includes a removable dolly.

OTHER DOC MENT HANDLING ACCESSORIES

Easily replace punch tools

as needed

Professional Puncher-A1

Up tp six paper

sources can be used

Paper Deck-W1

Create professional

hole-punched output

PROFESSIONAL P NCHER-A1

Excellent for print-for-pay and in-plant environments that

require maximum hole-punching versatility, the Professional

Puncher-A1 supports a variety of advanced in-line punching

selections. Simply insert one of the available punch tools to

enable in-line hole-punching for 8-1/2" x 11" pages, up to 80

lb. Cover. The precise alignment of holes on every page deliv-

ers punched manuals and workbooks with flush pages that

are easy to turn. Produce sets ready for off-line Plastic Comb,

Twin Loop, Color Coil, Velo, Loose-Leaf, or Proclick Binding

and quickly switch patterns to meet the ever-changing needs

of your production environment. The ProClick®Pronto™along

with the Professional Puncher-A1 forms a total finishing solu-

tion and seamless workflow for printing, collating, punching,

and binding.

PAPER DECK-W1 AND PAPER DECK-X1

Raise system paper capacity to a maximum of 7,650 sheets for

uninterrupted operation. Choose the optional Paper Deck-W1

to add 3,500 sheets of letter-sized paper, or the versatile

Paper Deck-X1 to add 3,500 sheets of letter, legal, or 11" x 17"

stocks to meet any high-volume job. Both options support

media weights between 17 lb. Bond to 110 lb. Index.

Paper Deck-X1

ProClick®Pronto™

Delivery of perfect-bound output

HIGH-CAPACITY STACKER-A1

Stack up to 5,000 sheets in the optional High-Capacity

Stacker-A1for long periods of unattended operation.

Precision alignment and offset stacking capabilities ready

document sets for off-line finishing. The removable rolling

dolly makes it effortless to transport large quantities to

packing and shipping desks or to other off-line finishing

devices. A convenient top exit tray offers a 1,000-sheet

capacity for non-collated output. Additional dollies are

available to support non-stop document production.

Perfect Binder-A1

Document Insertion Unit

High-Capacity tacker-A1

Removable Dolly

Perfect-bound book output

PERFECT BINDER-A1

Produce perfectly bound and trimmed books with wraparound

covers in-line, without manual intervention. The optional

Perfect Binder-A1 with Document Insertion nit uses hot glue

technology to attach heavyweight covers to 10- to 200-sheet

books. Automatic three-way trimming delivers a professional

product that rivals offset printing and off-line production equip-

ment. Pull media from the 50-sheet Bypass, the 550-sheet

Paper Cassettes, the optional 3,500-sheet Paper Deck-X1, or

insert pre-printed covers through the post-process Document

Insertion nit. Dual 200-sheet trays sit atop the Perfect Binder-

A1 to feed book covers into job streams. By inserting pre-printed

covers post-process, they’re not exposed to the heat of the fusing

unit, thereby preserving image quality.

addle Finisher-V2

100-sheet stapling

Finisher-V1

Two- or three-hole punching

FINISHER-V1/SADDLE FINISHER-V2 WITH OPTIONAL

P NCHING, FOLDING, AND TRIMMING

Corner or double staple sets of up to 100 letter-sized pages

(50-sheet stapling for letter-R, legal, and ledger sets) and

stack up to 5,000 sheets with the optional Finisher-V1 or

Saddle Finisher-V2.

Both Finishers provide an upper 3,000-sheet offset tray and

a lower 2,000-sheet offset tray for non-stop collating with

cascade loading and may be equipped with precision two-

and three-hole punching through the internal Puncher nit-V1

option (not shown). The optional Document Insertion nit-C1

can be installed on top of either Finisher to enable the feeding

of heavyweight or pre-printed covers. Like the Document

Insertion nit found on the Perfect Binder-A1, it offers dual

200-sheet trays to collate covers into job streams after fusing

to preserve the image quality of pre-printed pages. And, either

Finisher may be configured with the optional Paper Folding

nit-D1 to Z-fold 11" x 17" pull-out pages, such as financial

spreadsheets or large graphic illustrations, into document

sets with a finished 8-1/2" x 11" size.

The Saddle Finisher-V2 matches all the specifications of

the Finisher-V1 and adds booklet-making capabilities (up

to 80 imaged pages). For even greater productivity, add the

Booklet Trimmer-C1. This option attaches to the Saddle

Finisher-V2 to trim the open end of booklet sets for a flush,

professional edge. After trimming, the booklets are delivered

to an output tray via a conveyor belt for easy retrieval.

Produce Professionally

Finished Documents

Paper Folding Unit-D1

Booklet Trimmer-C1

Document Insertion Unit-C1

1-800-OK-CANON

www.usa.canon.com

Canon U.S.A., Inc.

One Canon Plaza

Lake Success, NY 11042

As an ENERGY STAR®Partner, Canon U.S.A., Inc. has determined that the

imageRUNNER 7105/7095/7086 devices meet the ENERGY STAR guidelines for

energy efficiency. ENERGY STAR and the ENERGY STAR mark are registered U.S.

marks. Pronto is a trademark and ProClick is a registered trademark of General

Binding Corporation. CANON and IMAGERUNNER are registered trademarks of

Canon Inc. in the United States and may also e registered trademarks or trade-

marks in other countries. IMAGEANYWARE is a trademark of Canon.

Specifications and availa ility su ject to change without notice.

0113W535

0609R-ACCESS-PDF-IH

Device Dimensions and Power Requirements Chart

Note: Specifications subject to change.

* When Finisher is equippe with Paper Fol ing Unit-D1 an /or Document Insertion Unit-C1.

** When Finisher is equippe with Professional Puncher-A1, Booklet Trimmer-C1, High-Capacity Stacker-A1, an /or Perfect Bin er-A1.

Main Unit 58" x 47-7/8" x 30-7/8" 7105/7095: 617 lb. (280kg)

(1474mm x 1216mm x 783mm) 7086: 595 lb. (270kg)

7095 Printer: 551 lb. (250kg)

Paper Deck-W1 22-1/2" x 12-3/4" x 23" 90.4 lb.

(570mm x 323mm x 583mm) (41kg)

Paper Deck-X1 22-5/8" x 23-3/8" x 24-1/2" 101 lb.

(574.5mm x 593mm x 621mm (46kg)

High-Capacity tacker-A1 48-9/10" x 33-9/10" x 30-1/5" 440 lb.

(1240mm x 860mm x 765mm) (200kg)

Perfect Binder-A1 53-1/2" x 36-1/4" x 31-1/8" 696 lb.

(1360mm x 920mm x 791mm) (316kg)

Finisher-V1 46-1/2" x 31-1/2" x 31-1/4" 278 lb.

(1180mm x 800mm x 792mm) (126kg)

addle Finisher-V2 46-1/2" x 31-1/2" x 31-1/4" 392 lb.

(1180mm x 800mm x 792mm) (178kg)

Document 8-3/8" x 24-5/8" x 26-1/4" 37.5 lb.

Insertion Unit-C1 (213mm x 625mm x 667mm) (17kg)

Paper Folding Unit-D1 41" x 7-1/8" x 31" 97 lb.

(1040mm x 179mm x 786mm) (44kg)

Booklet Trimmer-C1 41" x 62-1/10" x 30-2/5" 335 lb.

(1040mm x 1575mm x 770mm) (152kg)

Professional 38-1/2" x 12" x 28-1/2" 170 lb.

Puncher-A1 (978mm x 305mm x 723mm) (77kg)

From Finisher-V1 or

addle Finisher-V2

Directly From Main Unit

Product/Accessory Name Dimensions (H x W x D) Weight Power

208V, 60Hz, 12A

120V, 10A

208V, 15A

Directly From Main Unit*

208V, 60Hz, 12A**

Altri manuali per IMAGERUNNER 7095 PRINTER

Questo manuale è adatto per i seguenti modelli

Altri manuali Canon Stampante tutto in uno

Canon

Canon MG6600 Series Manuale utente

Canon

Canon Pro-1000 series Guida all'installazione

Canon

Canon imageRUNNER ADVANCE C3530i II Manuale operativo

Canon

Canon PIXMA MP500 Manuale di istruzioni

Canon

Canon ImagePress 1125P Manuale utente

Canon

Canon MX475 Guida all'installazione

Canon

Canon Color imageCLASS MF8170c Manuale utente

Canon

Canon Oce VarioPrint DP Line Manuale utente

Canon

Canon MultiPASS L60 Guida di sicurezza

Canon

Canon PIXMA MX860 series Manuale utente

Canon

Canon PIXMA MG5320 Series Manuale utente

Canon

Canon imageRUNNER 2230 Manuale utente

Canon

Canon imageRUNNER 8500 Manuale utente

Canon

Canon ImageRunner iR8500 Series Istruzioni per la costruzione

Canon

Canon imageRUNNER ADVANCE C2230 Manuale utente

Canon

Canon PIXMA MX700 Series Manuale utente

Canon

Canon PIXMA MP140 Series Manuale utente

Canon

Canon C5000 - MultiPASS Color Inkjet Printer Manuale utente

Canon

Canon imageCLASS D1120 Manuale utente

Canon

Canon ImageCLASS MF3240 Series Guida all'installazione

Canon

Canon PIXMA MP190 Manuale utente

Canon

Canon ImageCLASS MF4270 Guida di sicurezza

Canon

Canon mg6400 series Guida all'installazione

Canon

Canon MF635Cx Series Manuale utente

Manuali Stampante tutto in uno popolari di altre marche

Triumph Adler

Triumph Adler DC 2016 Manuale

Epson

Epson WorkForce WF-2510 Guida utente

Epson

Epson Stylus Scan 2000 Manuale di installazione e funzionamento

Epson

Epson PictureMate Snap PM 240 Manuale di istruzioni

Konica Minolta

Konica Minolta bizhub C35 Manuale utente

Brother

Brother MFC-J430w Manuale utente

Konica Minolta

Konica Minolta BIZHUB 558 Manuale utente

Lexmark

Lexmark MX710 Series Manuale

Brother

Brother MFC-9760 Manuale utente

Lexmark

Lexmark XC8155 Manuale utente

Lexmark

Lexmark X642E Manuale utente

Sharp

Sharp MX-2310U Guida

Aficio

Aficio 200 Manuale utente

Ricoh

Ricoh Pro C900 Manuale utente

Lexmark

Lexmark X925 Manuale utente

Brother

Brother Business Smart MFC-J4510dw Manuale utente

Epson

Epson Stylus CX8400 Series Manuale utente

Oce

Oce VarioLink 5022 Manuale utente
