Canon EOS 7D Mark II (G) Manuale utente

EOS 7D Mark II (G)

INSTRUCTION

MANUAL

COPY

The EOS 7D Mark II (G) is a digital single-lens reflex camera featuring a

fine-detail CMOS sensor with approx. 20.2 effective megapixels, Dual

DIGIC 6, approx. 100% viewfinder coverage, high-precision and high-

speed 65-point AF (Cross-type AF point: Max. 65 points), approx. 10.0

fps continuous shooting, Live View shooting, Full High-Definition (Full

HD) movie shooting, Dual Pixel CMOS AF, and GPS function.

Before Starting to Shoot, Be Sure to Read the Following

To avoid botched pictures and accidents, first read the “Safety

Warnings” (p.526-528) and “Handling Precautions” (p.20-21).

Refer to This Manual While Using the Camera to Further

Familiarize Yourself with the Camera

While reading this manual, take a few test shots and see how they

come out. You can then better understand the camera.

Testing the Camera Before Use and Liability

After shooting, play images back and check whether they have been

properly recorded. If the camera or memory card is faulty and the

images cannot be recorded or downloaded to a computer, Canon

cannot be held liable for any loss or inconvenience caused.

Copyrights

images of people and certain subjects for anything but private

enjoyment. Also be aware that certain public performances, exhibitions,

etc., may prohibit photography even for private enjoyment.

Introduction

COPY

Before starting, check that all the following items are included with your

camera. If anything is missing, contact your dealer.

* Battery Charger LC-E6 or LC-E6E is provided. (The LC-E6E comes with a

power cord.)

The Instruction Manual and CD-ROMs provided are listed on the next page.

If you purchased a Lens Kit, check that the lenses are included.

Depending on the Lens Kit type, a lens instruction manual may also be

included.

Be careful not to lose any of the above items.

Item Check List

Battery Pack

LP-E6N

(with protective cover)

Battery Charger

LC-E6/LC-E6E*

Interface Cable

IFC-150U II

Camera

(with body cap)

Wide Strap

Eyecup Eg

Cable

protector

In this manual, “CF card” refers to CompactFlash cards and “SD

card” refers to SD/SDHC/SDXC cards. “Card” refers to all memory

cards used to record images or movies.

*The camera does not come with a card for recording images/

movies. Please purchase it separately.

Connecting to Peripheral Devices

When connecting the camera to a computer or printer, use the provided

interface cable or one from Canon. When connecting an interface cable, also

use the provided cable protector (p.34).

COPY

The instruction manual consists of a booklet, leaflets, and electronic

manuals (PDF files on the CD-ROM).

Camera Instruction Manual CD-ROM

Contains the following manuals in PDF format:

• Camera Instruction Manual (Detailed version)

• Quick Reference Guide

Instructions for viewing the Camera Instruction Manual

CD-ROM are on pages 532-533.

Software CD-ROM (EOS DIGITAL Solution Disk)

Contains various software. For more information and

installation procedures of the software, see pages 536-

538.

Software Instruction Manual CD-ROM

Contains software manuals in PDF format. Instructions for

viewing the Software Instruction Manual CD-ROM are on

page 539.

Instruction Manual and CD-ROMs

Camera Basic

Instruction Manual Quick Reference Guide

GPS Cautions

COPY

The camera can use the following cards regardless of capacity: If the

card is new or was previously formatted by another camera or

computer, it is recommended that you format the card with this

camera (p.67).

CF (CompactFlash) cards

* Type I, UDMA mode 7-compatible.

SD/SDHC*/SDXC* memory cards

* UHS-I cards supported.

When shooting movies, use a large-capacity card with a fast reading/

writing speed as shown in the table.

If you use a slow-writing card when shooting movies, the movie may

not be recorded properly. Also, if you play back a movie on a card

with a slow reading speed, the movie may not play back properly.

If you want to shoot still photos while shooting a movie, you will need

an even faster card.

To check the card’s reading/writing speed, refer to the card

manufacturer’s Web site.

Compatible Cards

Cards that Can Record Movies

Movie Recording Size (p.330) CF Card: Recording Formats

MOV MP4

ALL-I (For editing) 30 MB/sec. or faster

IPB (Standard) L: 8 7 30 MB/sec. or faster

Other than above 10 MB/sec. or faster

IPB (Light) -10 MB/sec. or faster

Movie Recording Size (p.330) SD Card: Recording Formats

MOV MP4

ALL-I (For editing) 20 MB/sec. or faster

IPB (Standard) L: 8 7 20 MB/sec. or faster

Other than above 6 MB/sec. or faster

IPB (Light) -4 MB/sec. or faster

COPY

Quick Start Guide

1Insert the battery (p.40).

To charge the battery, see page 38.

2Insert the card (p.41).

The camera-front side slot is

for a CF card, and the

camera-back side slot is for

an SD card.

* Shooting is possible with either a CF card or an SD card in the camera.

3Attach the lens (p.50).

Align the lens’s white or red mount

index with the camera’s index of the

same color.

4Set the lens’s focus mode

switch to <f> (p.50).

5Set the power switch to <1>

(p.45).

White index Red index

COPY

Quick Start Guide

6While holding down the center

of the Mode Dial, set it to <A>

(Scene Intelligent Auto) (p.29).

All the necessary camera settings

will be set automatically.

7Focus on the subject (p.55).

Look through the viewfinder and

aim the viewfinder center over the

subject.

Press the shutter button halfway,

and the camera will focus on the

subject.

If necessary, the built-in flash will be

raised.

8Take the picture (p.55).

Press the shutter button completely

to take the picture.

9Review the picture.

The image just captured will be

displayed for 2 sec. on the LCD

monitor.

To display the image again, press

the <x> button (p.354).

To shoot while looking at the LCD monitor, see “Live View

Shooting” (p.285).

To view the images captured so far, see “Image Playback” (p.354).

To delete an image, see “Erasing Images” (p.392).

COPY

Icons in this Manual

<6> : Indicates the Main Dial.

<5> : Indicates the Quick Control Dial.

<p> : Indicates the AF area selection lever.

<9> : Indicates the Multi-controller.

<0> : Indicates the Setting button.

0/9/7/8: Indicates that the corresponding function

remains active for 4 sec., 6 sec., 10 sec., or 16

sec. respectively after you let go of the button.

* In this manual, the icons and markings indicating the camera’s buttons, dials,

and settings correspond to the icons and markings on the camera and on the

LCD monitor.

3: Indicates a function that can be changed by pressing the

<M> button to change its settings.

M: When shown on the upper right of a page, it indicates that

the function is available only in the <d>, <s>, <f>,

<a>, or <F> mode.

(p.**) : Reference page numbers for more information.

: Warning to prevent shooting problems.

: Supplemental information.

: Tips or advice for better shooting.

: Troubleshooting advice.

Basic Assumptions

All operations explained in this manual assume that the power switch

is set to <1> and the <R> switch is set to the left (Multi

function lock released) (p.45, 59).

It is assumed that all the menu settings, Custom Functions, etc. are

set to their defaults.

The illustrations in this manual show the camera attached with the

EF-S18-135mm f/3.5-5.6 IS STM lens as an example.

Conventions Used in this Manual

COPY

For first-time DSLR users, Chapters 1 and 2 explain the camera’s

basic operations and shooting procedures.

Chapters

Introduction 2

Getting Started 37

Basic Shooting 79

Setting the AF and Drive Modes 85

Image Settings 145

GPS Settings 197

Advanced Operations 215

Flash Photography 253

Shooting with the LCD Monitor

(Live View Shooting)

285

Shooting Movies 313

Image Playback 353

Post-Processing Images 397

Sensor Cleaning 405

Printing Images and Transferring Images to a Computer

411

Customizing the Camera 431

Reference 467

Viewing the CD-ROM Instruction Manuals /

Downloading Images to Your Computer 531

COPY

Introduction 2

Item Check List................................................................................. 3

Instruction Manual and CD-ROMs ................................................... 4

Compatible Cards............................................................................. 5

Quick Start Guide............................................................................. 6

Conventions Used in this Manual..................................................... 8

Chapters........................................................................................... 9

Index to Features ........................................................................... 17

Handling Precautions..................................................................... 20

Nomenclature................................................................................. 22

Getting Started 37

Charging the Battery ...................................................................... 38

Installing and Removing the Battery............................................... 40

Installing and Removing the Card.................................................. 41

Turning on the Power..................................................................... 45

Setting the Date, Time, and Zone .................................................. 47

Selecting the Interface Language................................................... 49

Attaching and Detaching a Lens .................................................... 50

Lens Image Stabilizer..................................................................... 53

Basic Operation.............................................................................. 54

QQuick Control for Shooting Functions....................................... 61

3Menu Operations.................................................................. 64

Before You Start............................................................................. 67

Formatting the Card..................................................................... 67

Disabling the Beeper ................................................................... 69

Setting the Power-off Time/Auto Power Off................................. 69

Setting the Image Review Time................................................... 70

Reverting the Camera to the Default Settings............................. 70

Contents

COPY

Altri manuali per EOS 7D Mark II (G)

Indice

Altri manuali Canon Macchina fotografica digitale

Canon

Canon PowerShot G15 Manuale utente

Canon

Canon EOS 4000D Manuale utente

Canon

Canon EOS DIGITAL REBEL XTi Manuale utente

Canon

Canon DentalFoto Manuale utente

Canon

Canon PowerShot SX500 IS Manuale utente

Canon

Canon PowerShot N Manuale del proprietario

Canon

Canon PowerShot A720 IS Manuale utente

Canon

Canon POWERSHOT SD3500IS Manuale utente

Canon

Canon PowerShot A2600 Manuale di servizio

Canon

Canon EOS 7D Mark II (G) Manuale utente

Canon

Canon EOS-1DC Manuale utente

Canon

Canon PowerShot G5 Manuale di istruzioni

Canon

Canon WP-DC46 Manuale utente

Canon

Canon PowerShot ELPH 120 IS Manuale utente

Canon

Canon SC A60 Manuale utente

Canon

Canon EOS 60Da Manuale utente

Canon

Canon Powershot SD40 Manuale utente

Canon

Canon MP480 series Manuale utente

Canon

Canon EOS-1D Mark II Digial Manuale di servizio

Canon

Canon PowerShot ELPH 170 IS IXUS 170 Manuale utente

Canon

Canon EOS 1D Mark III Manuale utente

Canon

Canon PowerShot A3300 IS Manuale utente

Canon

Canon Pixma Pro 9500 Mark II series Manuale utente

Canon

Canon PowerShot TX1 - Digital Camera - Compact Manuale utente

Manuali Macchina fotografica digitale popolari di altre marche

Mercury

Mercury 350K Manuale utente

Pentax

Pentax Optio LS 465 Manuale utente

Sanyo

Sanyo VPC-S1085 Manuale utente

GE SMART A1255 Manuale utente

Point Grey

Point Grey Gazelle Manuale utente

Nikon

Nikon COOLPIX A Manuale utente

Pentax

Pentax P-5 Manuale utente

BlazeVideo

BlazeVideo A280 Manuale utente

Sony

Sony MCA-20 Manuale utente

Sony

Sony Alpha DSLR-A290 Manuale utente

ATIK Cameras

ATIK Cameras One Manuale utente

CohuHD Costar

CohuHD Costar 3930 Series Manuale utente

Leica

Leica M10-R Manuale utente

FujiFilm

FujiFilm FinePix A700 Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

GE J1470S Manuale utente

Sony

Sony A6700 Guida utente

Nikon

Nikon Coolpix 100 Manuale utente
