Canon PowerShot G1 X Manuale utente

Doc. 000818, Rev. B, www.remoteteality.com

Page 1of 2

REMOTER

EALITY

4 Technology Drive

Westborough, MA 01581

866-898-

1010

Camera

Guide

Canon PowerShot G1/G2/G3/G5

Recommended Camera settings for OneShot360™

Attach the OneShot360 unit, and power the camera on.

•Zoom: Use the Zoom to exactly fill the digital camera LCD viewer screen

with the circular image. Use the zoom lever on the top of the camera,

around the shutter button. If you zoom in too much, you will lose part of

the field of view. If you zoom in too little, you will not get maximum

resolution. Note also that the OneShot image may not be exactly centered

in the LCD screen–this is normal.

•Flash: Make sure the flash is disabled by pressing the flash/index button

(lightning bolt symbol) located above the LCD screen on the upper left of

the back of the camera. Press the button until you see the “flash off” icon

on the LCD.

•ISO setting: RemoteReality recommends using ISO sensitivity of 100 or

less.

•Focus: To focus your OneShot image, use the Manual Focus function.

Adjust the focal distance until a setting of 3 meters (or 9 ¾ ft.) is displayed

on the LCD screen.

•Aperture: Put your Canon PowerShot camera in aperture priority mode

by turning the top mode dial to Av, the symbol for aperture priority. Adjust

the Omni Selector left/right to an f-stop of 7.1.

•White Balance: Set the white balance by pushing the +/-WB button (to

the right of the LCD screen) twice. Then select AWB for Auto White

Balance, which is fine for most shots.

NOTE: You can use shutter priority mode, as long as you use a shutter speed

that would give you the desired f# of 7.1. Also, make sure you are using a tripod

when shooting with a slow shutter speed.

Press the MENU button and use arrow buttons to:

•Image Size: Under the Resolution menu, set the image size to L

(2272x1704) for best quality.

•Self-timer: Select the self-timer by pressing the self-timer button on top

of the camera.

Doc. 000818, Rev. B, Canon PowerShot G1/G2/G3/G5 www.remoteteality.com

Page 2of 2

REMOTER

EALITY

4 Technology Drive

Westborough, MA 01581

866-898-

1010

Camera

Guide

Recommended Camera Settings for 360Plus

When taking 360x360 images, follow all of the above instructions, and the

additional instructions below.

Because the 360Plus uses 4 images, it is best to make sure that all 4

images have the same exposure. This will ensure the end result will have

a continuous tone and density throughout the image. The best way to do

this is to:

•Look at the aperture and shutter speed settings shown in the LCD

screen. If the values change while shooting the 4 360 images

needed for a 360x360, then the exposure is changing between

shots. Try to make the scene as evenly balanced with the same

type of light as possible. For example, close window shades and

turn on interior lights.

•You can also try pushing the AE lock button (*). This will keep the

exposure setting from changing between shots, but you must push

the AE lock button after each shot so the exposure will lock for all

four shots.

•When processing 360Plus images in the RemoteReality software,

use the Sony DSC-S70 camera setting.
