Large Format

Print Solutions

CAD & GIS

For Computer Aided Design and Geographical Information Systems

LFP SOLUTIONS

Canon Large Format Printers for CAD or GIS.

Render the finest lines and the most precise

graphics with Canon’s superb range of Large

Format Printers for Technical Environments.

Whether you’re rendering complex 3D CAD

drawings, creating large-scale photo realistic

visuals of your designs, or mapping complex

geographic data, Canon’s Large Format Printers

provide the precision prints and deadline-beating

performance you need.

Where precision

is paramount.

Big benefits with Canon

We’ve been helping companies involved

in the CAD and GIS market for years.

Canon’s iPF610 and iPF710 printers

feature innovations specifically engineered

to generate the results you demand. Canon’s

5-colour reactive ink technology is created

to enable you to generate prints with

smooth curves, fine lines, small text and

the most detailed graphs. And Canon's FINE

technology for bubble-jet printers and L-COA

image processing technology ensure prints

at deadline-beating speeds.

iPF610 iPF710

The range

For true print flexibility, Canon offers the imagePROGRAF iPF610 and imagePROGRAF iPF710

giving you the choice of 24” (A1) and 36” (A0) large format print capabilities. Each device is

simple to operate with full support for CAD applications with HPGL/2 and HP RTL compatibility,

ensuring a seamless introduction into your CAD or GIS environment.

•Mechanical CAD

•Architecture

•Engineering

•Construction

Technical perfection for:

Canon’s Large Format Print Solutions for CAD & GIS

•Electronic Design

Automation (EDA)

•Geographical Information

Systems (GIS)

LFP SOLUTIONS

Print big with precision

Accurate printing

Canon’s 5-colour dye/pigment reactive ink

system gives the results you need using a wide

colour gamut. Fine lines, small text and highly

detailed graphics are produced with incredible

accuracy and sharpness. 1200 dpi rendering

and a minimum line width of 0.02mm is

consistently achieved with an ink placement

precision of just ± 0.1%.

Productive printing

Quality and speed sit side-by-side with the

iPF610/iPF710. You can produce A1 print on

the iPF610 in just 33 seconds and A0 prints on

the iPF710 in a mere 56 seconds.

Simple to operate

Device operation is simple thanks to a large

LCD panel which provides clear menu-driven

controls for all functions. A thoughtfully

designed fan system ensures the quietest of

operation.

Flexible media handling

A huge variety of media options are available

providing added diversity to your final output.

A 4-way paper feed, consisting roll, cassette,

and 2 Manual feeds is offered with the iPF610.

The iPF710 offers 3-way feeding via a roll and

2 manual feeds.

Potential media misalignment is virtually

eradicated thanks to Auto-skew correction

which automatically adjusts for any skew in

orientation and feeds the paper correctly.

There’s no room for error in the type of work you do. That’s why you need a

Large Format Printer that’s designed specifically to produce the finest lines,

smoothest curves and most striking graphical representations attainable.

CAD & GIS

Canon’s Large Format Print Solutions for Production

Economical and reliable

As you would expect from Canon, reliable

performance is a given and for added peace

of mind our imagePROGRAF printers come

with 1 years print head warranty.

A new feature for the CAD models is the

Economy printing mode designed specifically

for printing quick, low cost draft prints for

checking the layout etc before final print. The

ink consumption is reduced by approximately

50% when compared to conventional draft

mode and although the print will be slightly

lighter coloured it does enable the end-user

to produce a much cheaper layout draft.

The mode is available in Plain paper / Draft

mode (colour mode: Colour, Monochrome,

Colour (CAD), Monochrome (BK ink) and

Monochrome Bitmap) and is added as a

checkbox in the settings menu.

For all your CAD/GIS applications

The iPF610/iPF710 supports the common

languages used in your market for seamless

integration with the way you work. HP-GL/2

and HP/RTL are supported, and an HDI driver is

also included for Windows applications.

Architects, engineers and construction

firms can produce plans in exceptional detail

with precise line rendering - whether during

the initial selling, design or production phases

of a project.

Mechanical CAD engineers can create

photorealistic visualisations of their plans in

applications such as AutoCAD, Mechanical

Desktop or Pro/Engineer and bring them to life

quickly with exceptional quality on media up

to 36”.

GIS specialists can render complex 'what-if'

scenarios using maps, seismic analysis data

or images from satellites. Even with the huge

file sizes generated, the iPF610/iPF710 can

effortlessly handle your requirements with

accurate, predictable colour and exceptional

line rendering.

LFP SOLUTIONS

CAD & GIS

Focussed on your business

to make a big difference

Reactive ink technology

Canon’s iPF610/iPF710 features a 5-colour

dye/pigment reactive ink system designed

specifically for CAD and GIS applications.

This unique formulation improves ink adhesion

to the media and minimises

colour “bleeding”. When black ink intersects

with a coloured area (for example, words

printed on a coloured background), the black

and cyan inks induce a chemical reaction that

prevents black from bleeding into the colours.

This means clearer text, smoother curves and

sharp fine lines – even on uncoated technical

papers. Using reactive inks also improves

scratch and marker resistance so prints are

far more durable than those printed with

conventional dye inks.

Smooth graduations across all

media

The iPF610/iPF710 utilises two types of black

ink for the best possible results on all types

of media. For photo-type media, a black ink

(BK) is used and for high contrast prints on

matt paper, a matt black (MBK) is used.

This process ensures smooth graduations

across every media type and is highly efficient

as the relevant ink is automatically selected

for each media type.

The innovative features included within the iPF610/iPF710 have been designed

to help you bring your best work to light. Look forward to exceptional accuracy,

print after print consistency and highly productive performance.

2,650 nozzles x 6 lines Full colour 4pl, Total: 15,360 nozzles

Colour Ink Matte black Ink Chemical reaction Minimal diffusion

5 colours

Single Head

(MBK x 2 lines)

MBK 5,120 nozzles

Each of other colours: 2,560 Reactive

CYMMBK MBK BK

Dye

5-colour dye and pigment reactive ink system

Print with FINE technology

To deliver faithful image expression, ink

droplets must be extremely small and

precisely distributed. When droplets become

microscopic however, image quality is affected

by problems such as uneven droplet size and

placement on the paper. Conventional printing

systems compensate by making multiple

passes for each line but this adds significantly

to print times.

Canon’s FINE (Full Photolithograph Inkjet

Nozzle Engineering) overcomes this

problem without needing to make multiple

passes, producing bi-directional printing at

incredible speeds. An innovated ink-nozzle

manufacturing method results in precisely

uniform droplets and outstanding photo-quality

print performance.

L-COA for unbeatable productivity

Providing the optimal balance between high

productivity and high quality is Canon’s Large

Format Printer Common Architecture (L-COA).

L-COA helps your iPF610/iPF710 carry out the

most complex print jobs - where files can often

exceed 200MB – with ease.

Canon’s FINE technology uses ink bubbles

that are formed at the top of the nozzle to

separate and eject the ink.

Innovations that

help you win

new business.

LFP SOLUTIONS

CAD & GIS

The best way to see the bigger picture

Overview

Extensive media compatibility

for a diversity of applications

Fast production speeds

ensure you can deliver prints

quickly whenever needed

1200 x 1200 dpi and 4pl

with minimum line width

of 0.02mm

Wide colour gamut

with media-dependent

black and matt black inks

for the best results

5 colour dye/pigment

reactive ink technology

for the sharpest lines, smoothest curves

and most accurate graphs

Auto Skew Correction

for trouble-free printing

Large LCD control panel

makes operation

quick and simple

Bring your most complex designs, plans, charts and maps

to life in exceptional detail with Canon’s specialist CAD&GIS

Large Format Printers.

iPF710

Full support

for CAD applications and HPGL/2

and HP RTL compatibility

Economy Printing Mode

iPF610

Borderless

printing (up to 36”)

Canon Media & Ink

Media matters

More choice and better quality for you and

your customers comes courtesy of Canon’s

exclusive range of specialist media. Designed

for Large Format Printing applications we offer

40 high quality specialist options for Proofing,

CAD&GIS, Fine Art, Photography and Production

sectors.

Using Canon media ensures your design

and print workflow process is undertaken

with products designed to work in harmony

for the highest possible performance levels.

The entire Canon media range is also supported

with ICC profiles and preset printer settings for

quick, predictable and trouble-free operation.

For CAD & GIS applications there are specialist

media's available with various roll widths.

Quality results with Canon inks

We’re constantly looking to fine-tune the

quality of our inks and thereby the quality

of your prints. That’s why we’ve selected a

specialist formulation of pigment and dye

ink that has been designed to give the finest

results possible for the applications you use.

If you demand the sharpest lines, the most

accurate visualisations and the most stunningly

detailed graphs, make sure you choose inks

that are designed for the task at hand.

Lines and graphs never

looked better with

Canon Media and Ink.

17”

Roll widths available

LFP SOLUTIONS

24” 36”

CAD & GIS

Software designed to expand

your opportunities

Effortless control

Ultimate control comes courtesy of Canon’s

flexible imagePROGRAF Printer Driver. An “easy

mode” allows you to use Canon’s pre-defined

settings for speed and simplicity of use.

Switch to “advanced mode” however and you

can adjust drying times, colour settings and

manage your own ICC profiles.

Page set-up provides pure flexibility allowing

customised page sizes if required and a

best-fit option for each media is selectable.

Select the watermark feature and you can

protect the rights of your images. For enhanced

workflow, pre-defined settings can be created

using hot folders.

A maintenance facility allows you to adjust the

media feed, do a nozzle check, clean the print

heads, check the queue and carry out other

timesaving procedures.

Precision with HDI Driver

Standard Windows drivers will make raster

representations of print data which can result

in imprecise printing which could have serious

consequences. Canon’s HDI driver however,

makes a Vector representation of the data,

whereby points are defined mathematically.

This ensures lines and curves are represented

with absolute accuracy – essential for use with

CAD applications such as AutoDesk AutoCAD.

When you work with Canon you work with a company that carefully considers

how you run your business. That means people who understand how you

operate, products designed to get the job done and added value software

equipped to maximise your business opportunities.

Questo manuale è adatto per i seguenti modelli

Altri manuali Canon Stampante

Canon

Canon iP5200R - PIXMA Color Inkjet Printer Manuale utente

Canon

Canon iP6600D - PIXMA Color Inkjet Printer Manuale di istruzioni

Canon

Canon g3000 series Guida all'installazione

Canon

Canon PR-C151 Manuale utente

Canon

Canon imageClass LPB7100Cn Manuale utente

Canon

Canon imageCLASS MF6500 Series Manuale utente

Canon

Canon i9100 Series Manuale

Canon

Canon imagePROGRAF W6400 Manuale utente

Canon

Canon imagePRESS C7000VP Series Manuale utente

Canon

Canon MP630 SERIES Manuale utente

Canon

Canon SELPHY CP810 Manuale utente

Canon

Canon 2171B002 Manuale utente

Canon

Canon 3410 Manuale utente

Canon

Canon PIXMA G2410 Series Manuale utente

Canon

Canon PIXMA TS5320 Guida all'installazione

Canon

Canon IR C2100 Manuale di programmazione

Canon

Canon IMAGERUNNER 7095 PRINTER Manuale utente

Canon

Canon imagePROGRAF iPF815 Manuale utente

Canon

Canon iPF760 series Manuale utente

Canon

Canon LBP 2460 - B/W Laser Printer Manuale utente

Canon

Canon Laser Shot LPB3500 Manuale utente

Canon

Canon imagePROGRAF iPF810 Manuale utente

Canon

Canon Ivy CLIQ+ Manuale utente

Canon

Canon iP5000 - PIXMA Color Inkjet Printer Manuale utente

Manuali Stampante popolari di altre marche

Lexmark

Lexmark 1400 Series Manuale

Evolis

Evolis Elypso Manuale utente

Kyocera

Kyocera FS-9530DN Manuale utente

Samsung

Samsung BIXOLON SRP-350plusF Manuale utente

Dell

Dell Color Laser Printer 2130cn Manuale utente

Tektronix

Tektronix Phaser 840 Manuale utente

Epson

Epson ET-7750 Istruzioni operative

Eltron

Eltron P210 Guide Manuale utente

Ricoh

Ricoh MD-P1 Manuale utente

Epson

Epson SC-F7100 series Manuale utente

Epson

Epson Stylus C40UX Manuale utente

IRA3D

IRA3D POETRY4 Manuale utente

Ricoh

Ricoh Aficio AP400 Manuale utente

BIXOLON

BIXOLON SRP-352plusV Manuale utente

Epson

Epson Stylus Photo PX700W Istruzioni per il montaggio

Ricoh

Ricoh SP204SF Manuale utente

Star Micronics

Star Micronics futurePRNT TSP100 Manuale utente

Epson

Epson TM-TM88V-i Manuale per l'uso e la cura
