Canon BJC-85 Manuale utente

USB Cable Users Parallel Cable Users

PC Connection Connect the cable to the computer's parallel port

and tighten the screws.

Then connect the cable to the

printer's parallel port with

the wire clips.

Unpack the Printer

Remove all items from the box.

Connect the Printer to the Computer

2 3 Connect the

AC Adapter

Make sure your computer is turned off.

The printer driver CD-ROM includes:

Microsoft®Windows®printer driver

Macintosh®printer driver

IS-12 Color Scanner Cartridge driver

Online User's Manual

Software applications

Electronic registration

Remove all

shipping tape

and materials

from the unit.

Tape may not be in the exact locations

shown here.

You will need to purchase a parallel cable

for Windows 95/98, Windows NT®, or

Windows CE (must be IEEE 1284-compliant),

or a USB cable for Windows 98 or Mac®OS.

AC Adapter

BC-11e Color BJ Cartridge

BC-10 Black BJ Cartridge

BCI-11 Color Ink Tank (for future use)

BCI-11 Black Ink Tank (for future use)

SB-10 Ink Cartridge Storage Box

BJC-85 Printer

Documentation

Package

Tape

Top Cover

Protective Sheet

Lift the top cover

and remove the

protective sheet.

You can connect the printer to the computer in one of three ways: USB Cable Parallel Cable Wireless IrDA

The interface you use depends on your computer.

Connect the cable to the computer, and then to

the printer.

Connect the cable to the computer, and then

to the printer.

Macintosh Connection

USB Cable

Wireless IrDA Users

If you have a computer with an infrared port for wireless

data transmission, you can set up a cordless connection

with the BJC-85. In order to use the infrared port, make

sure your computer meets the following requirements:

Computer–PC (not compatible with Macintosh)

Operating System–Windows 98, CE 2.1

Infrared Transmission Device–Built-in IrDA port or IrDA

transmission adapter on the PC; IrDA version 1.1 or later

Drivers–BJC-85 printer driver and Microsoft infrared

driver version 3.0. NOTE: Microsoft IrDA driver is not

included on the CD-ROM.

The distance between

the PC and BJC-85

infrared ports should

not exceed 3 feet for

data transmission.

For more detailed

information on wireless

printing, see your

online User's Manual

after installing the

printer driver from

the CD-ROM.

Parallel Interface Cable—

IEEE 1284-compliant

Wire Clips

Screws

Important! The socket-outlet shall be

installed near the equipment and shall

be easily accessible.

Insert the power cord into

the AC Adapter.

Plug the DC plug into the

back of the printer.

Plug the power cord

into the power outlet.

Power Cord

AC Adapter

DC Plug

Power Cord

Plug

USB Port

Install the Canon

BJ®Cartridge

Remove the BC-11e Color

BJ Cartridge from

its package.

Load Paper

Lift the top cover.

Press the POWER

button to turn

on the printer.

Align the triangular marks on the

BJ cartridge and the

cartridge holder;

set the cartridge

in the holder at a

slight angle.

Gently press down on the raised

left side of the

BJ cartridge until

it locks into place.

Open the cartridge cover, and press

the CARTRIDGE button to move the

cartridge holder to the center of

the printer.

Close the cartridge cover and press

the CARTRIDGE button.

The BJ cartridge and

holder move to the

home position on

the right side of

the printer.

Remove these protective materials:

Orange cap

Orange

tape

Move the paper guide to

the left.

Adjust the paper guide to the

left edge of the stack.

Printing side

face up

Align sheets here

Paper Guide

With the side you want to print

on facing up, insert the paper

into the printer until it stops.

Remove

Cap

Remove

Tape

Do Not Touch

these areas

Cartridge Holder

Top Cover

Cartridge Cover

Windows 98—USB Cable Users

Install the Printer Driver

6The printer driver controls communication between the printer and your computer. Use the printer driver CD-ROM

and follow these simple steps and the instructions on the screen.

9. Follow the on-screen instructions.

Setup includes:

Printer driver installation

Product registration

Creative software installation

Installation Tips

If Setup does not start automatically,

click Start on the Windows taskbar

and then click Run.

Type X:\SETUP (where X:is your

CD-ROM drive). Then click OK.

1. Turn on the computer. The Add New

Hardware screen appears:

If you do not see this screen, eject the CD-ROM

and re-insert it. Then follow the instructions on

the screen.

2. Insert the printer driver CD-ROM into your

CD-ROM drive and click Next. The next

screen asks what you want Windows to do:

6. Click Next. The next screen shows the successful

completion of this installation. USB is now enabled

on your computer.

7. To proceed on to the printer driver installation,

click Finish.

8. Eject the CD-ROM and re-insert it. Setup starts

automatically.

3. Choose "Search for the best driver for your

device," and click Next. The next screen

asks you where to look for the driver:

4. As shown above, click the "CD-ROM drive"

check box; be sure to uncheck the other

options. Click Next.

5. Once the driver is found, this screen appears:

Windows 95/98/NT—Parallel Cable Users

Installation Tips

5. Follow the on-screen instructions.

Setup includes:

Printer driver installation

Product registration

Creative software installation

If Setup does not start automatically, click Start on the Windows taskbar

and then click Run.

Type X:\SETUP (where X:is your CD-ROM drive). Then click OK.

1. Turn on the computer. If you see any type of "New Hardware Found" or "Update Wizard" screen, click Cancel

to return to the Windows desktop.

2. If any other applications start automatically, close them before you start the driver installation. This is very

important. Make sure NO applications are running, including any virus protection programs.

3. Make sure the Windows desktop appears on the screen.

4. Insert the printer driver CD-ROM into your CD-ROM drive. Setup starts automatically.

If you do not see this screen,eject the CD-ROM and re-insert it. Then follow the instructions on the screen.

1. Turn on the computer.

2.Insert the printer driver CD-ROM into your

CD-ROM drive. The following screen appears:

Macintosh—USB Cable Users

3. Click on the "Install BJC-85 Drivers."

The License Agreement screen appears.

Read the agreement and click Agree

to continue.

4. The next screen asks you to choose the

printer you are installing:

7. After driver installation, you must reboot the

system. Click the Restart button when you see

the "Installation was successful" screen.

8. After rebooting, you can proceed with other

portions of the installation process.

9. Once installation is complete, be sure to go to

the Chooser menu (under the Apple®sign) and

select the BJC-85 as the default printer.

5. Click on the printer name to highlight it,

and click Choose. This screen appears:

6. Click on Install to continue with Easy Install.

The next screen reports the progress of the

driver installation.

Online User's Manual

What's Next Getting Help From Canon

Printed in U.S.A.

CST-5307-001

40-41661-0400

ENERGY STAR®Compliant

Bubble Jet are trademarks of Canon Inc. All other product and brand

names are trademarks or service marks of their respective owners.

As an Energy Star®Partner, Canon U.S.A., Inc., has determined that

this product meets the Energy Star®guidelines for energy efficiency.

IS-12 Color Image Scanner

Cartridge (Optional)

Your online User's Manual in Adobe®

Acrobat® PDF format has been loaded on

your hard drive. To view the online

User's Manual:

Click Start.

Select Programs.

Select Canon BJC-85.

Select BJC-85 User's Manual.

Add the optional IS-12 Color Image Scanner

Cartridge and your printer becomes a

360 dpi color sheetfed scanner—the perfect

way to add images and graphics to reports

and presentations.

For more detailed information, visit Canon's

website at www.ccsi.canon.com.

For e-mail technical support, the latest driver

downloads and answers to frequently asked

questions (www.ccsi.canon.com)

24-hour, 7-day-a-week automated support

for troubleshooting issues on most current

products (1-800-423-2366)

24-hour, Fax-On-Demand System for

product specifications and technical

information (1-800-526-4345)

Free technical support Monday–Saturday for

products still under warranty**

(1-757-413-2848)

Technical support 7 days a week for

products no longer under warranty for

$24.99 per call (1-800-423-2366), or for

$2.50 per minute, to a maximum of $25.00

per call (1-900-246-1200)

Canon Computer Systems, Inc. offers a full

range of customer technical support* options:

NOTE: Within Canada, call for technical support

24 hours a day, 7 days a week

(1-800-OK-CANON)

*Support program specifics subject to

change without notice.

**Refer to individual product information

for warranty details.
