Canon I70 Series Manuale utente

BUBBLE JET PRINTER

Quick Start Guide

Table of Contents

Preface 1

Shipping Materials 1

Introduction 1

Setting Up 2

Preparing the Printer 2

Connecting the Printer to the Computer 2

Installing the Print Head 3

Loading Paper 6

Installing the Printer Driver 7

Aligning the Print Head 11

Basic Operations 15

Printing with Windows 15

Printing with Macintosh 17

Print Head Maintenance 19

Appendix 20

Printing Data through Infrared Transmission 20

Printing Photos from the Digital Camera Directly 22

Notes on Handling the USB Interface (for Windows Users) 23

For Further Details... 24

QA7-2540-V02

Exif Print

This printer supports Exif 2.2 (also called “Exif Print”).

Exif Print is a standard for enhancing the communication between digital cameras and printers. By

connecting to an Exif Print-compliant digital camera, the camera’s image data at the time of shooting is

used and optimized, yielding extremely high quality prints.

Canadian Radio Interference Regulations

This digital apparatus does not exceed the Class B limits for radio noise emissions from a digital

apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus,”

ICES-003 of the Industry Canada.

Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils

numériques de Classe B prescrites dans la norme sur le matériel brouilleur NMB-003 d'Industrie

Canada intitulée « Appareils numériques ».

International ENERGY STAR®Program

As an ENERGY STAR®Partner, Canon Inc. has determined that this product meets the ENERGY

STAR guidelines for efficiency.

The International ENERGY STAR®Office Equipment Program is a global program

that promotes energy saving through the use of computer and other office equipment.

The program backs the development and dissemination of products with functions

that effectively reduce energy consumption. It is an open system in which business

can participate voluntarily. The targeted products are office equipment such as com-

puters, monitors, printers, faxes and copiers.

Their standards and logos are uniform among participating nations.

Power Requirements

Never use a power supply voltage other than that supplied in the country of purchase. Using the incor-

rect voltage could cause a fire or electric shock. The correct power supply voltages and frequencies are

as follows:

AC 100-127 V, 50/60 Hz

AC 220-240 V, 50/60 Hz

This product emits low level magnetic flux.

If you use a cardiac pacemaker and feel abnormalities, please keep away from this product in use and

consult your doctor.

Printer Model: K10222 (i70)

Preface

Shipping Materials

Thank you for purchasing a Canon Bubble Jet Printer.

Check that all the following items are in the box. If anything is missing or is damaged, contact your Canon

Authorized Dealer or Sales Representative.



Printer



Setup Software & User’s Guide CD-ROM



Quick Start Guide



Print Head



BCI-15 Black and BCI-15 Color Ink Tanks



Universal AC Adapter



Power Cord

* A USB cable should be purchased separately according to your computer. For details on cable

specifications, refer to page 2.

Introduction

This Quick Start Guide uses the following symbols to indicate important information. Always observe the

instructions indicated by these symbols.

Instructions that, if ignored, could result in death or serious personal injury caused by incorrect

operation of the equipment. These must be observed for safe operation.

Instructions that, if ignored, could result in personal injury or material damage caused by incorrect

operation of the equipment. These must be observed for safe operation.

Also read the Safety Precautions in the User’s Guide. Observe the warnings and cautions to avoid

personal injury or damage to the printer.

Trademark Notices

• Canon

is a registered trademark of Canon Inc.

•BJ

™

is a trademark of Canon Inc.

• Microsoft

and Windows

are registered trademarks of Microsoft Corporation in the U.S. and other

countries.

• Apple, Mac, Macintosh are trademarks of Apple Computer, Inc., registered in the U.S. and other

countries.

• All other trademarks and registered trademarks appearing in this Quick Start Guide are the property of

their respective owners.

without the express written permission.

Setting Up

1 Preparing the Printer

Place the printer on a flat surface.

Remove the tape from the printer.

The tape position is subject to change.

2 Connecting the Printer to the Computer

• Never attempt to plug the power cord into the power outlet or unplug the power cord when your

hands are wet.

• Never damage, modify, stretch, or excessibly bend or twist the power cord. Do not place heavy

objects on the power cord.

• Never use any power supply other than the standard power supply available in the country of

purchase. Using the incorrect voltage and frequency could cause a fire or electric shock.

• Always push the plug all the way into the power outlet.

• If using Windows 95, you can print only via infrared transmission.

• If your computer has an infrared transmission feature, you can print data without connecting a USB

cable. After connecting the universal AC adapter, proceed to “Installing the Print Head” on page 3.

• If your computer has an earth connection, ensure that this is attached.

• If you do not intend to use the printer for a long period of time, unplug the power cord from the

power outlet after turning off the printer.

USB cable Universal AC adapter Power cord

Recommended: Canon or

other computer manufacturer

cable, up to 5 meters in length

The power cord shape defers

with countries.

Follow the steps below to install the printer driver

correctly.

Ensure the printer and the computer are

switched off.

Connect the cable.

Plug the power cord into the Universal

AC adapter.

Plug the DC plug into the printer.

Plug the power cord into the power

outlet.

3 Installing the Print Head





Installing the Print Head

Open the paper rest.

Turn on the printer. Do NOT turn on the

computer yet.

The POWER lamp flashes and the printer begins to

operate. Wait until the POWER lamp remains fully lit.

Open the print head cover.

The print head holder moves to the center.

If the Add New Hardware Wizard or Found New Hardware Wizard screen appears when carrying out

the following operations, click Cancel and turn off the computer. For details, refer to page 7.

print head cover

print head holder

Press the lock button, then raise the

lock lever.

Do not touch internal parts other than the lock lever.

Remove the protective cap from the

print head.

Place the print head in the holder

aligning the mark with the mark.

• Do not touch the print

head nozzles.

• Do not attempt to

reattach the protective

cap once it has been

removed.

lock button

print head

nozzles

print head

print head holder

Lock the print head into place by

lowering the lever.

Press down the lock button until it clicks.

Do not touch the lock lever once the print head has been

installed.





Installing the Ink Tanks

• For safety reasons, store ink tanks out of the reach of small children.

• Do not drop or shake ink tanks as this may cause the ink to leak out and stain your clothes and hands.

Take out the black ink tank.

Hold the ink tank as shown in the

diagram and remove the protective cap.

Insert the black ink tank slant into the

back slot aligning the mark with the

mark.

Press the until it clicks into place.

• Do not touch the ink port.

• Do not attempt to reattach the

protective cap once it has

been removed.

protective cap

ink port

Use the same procedure to install the

color ink tank in the front slot.

Close the print head cover.

4 Loading Paper





Loading A4 (Letter) Size Plain Paper

Open the paper rest and the paper

output slot cover as shown.

Ensure the paper thickness lever to the

right position.

To avoid paper jams, fan the stack to

remove static cling, then align the

edges of the stack by tapping it on a flat

surface.

Load the paper, aligning it with the right

side of the sheet feeder.

You can load up to 30 sheets of plain paper. Do not load

exceeding the load limit mark.

Slide the paper guide against the left

side of the stack of paper.

Wait until the preparatory operation is complete: it

takes about 2 minutes.

Set the paper thickness lever to the right when using

plain paper, to the left when using thick paper. Refer

to the User’s Guide for infomation on loading

envelopes and other media.

You now need to install the printer driver:

Windows: Go to page 7

Macintosh: Go to page 9

print side load limit mark

5 Installing the Printer Driver





Installing the Printer Driver – Windows

Ensure the printer and computer are

switched off.

Turn on the computer and start

Windows. If any applications

automatically run, quit them.

Disable any virus detection programs.

Do NOT turn the printer on at this stage.

• When performing infrared transmission, requirements for using the computer must be satisfied.

Refer to “Printing Data through Infrared Transmission” on page 20 before installing the printer driver.

• Do not disconnect the cable or remove the CD-ROM during the installation. The driver cannot be

correctly installed.

• The screens below refer to Windows XP installation. Screen may differ depending on the operating

system you are using.

• When installing the printer driver in Windows XP or Windows 2000, log on to the system as a

member of the Administrators group.

• The Setup Software & User’s Guide CD-ROM contains the application software to import, edit,

and print image data. If you want to install the application software, click Install on step 7.

Internet Explorer 4.0 or later must be installed for Easy-PhotoPrint.

Internet Explorer 5.5 or later must be installed for Easy-WebPrint.

If the following screen appears automatically, click

Cancel

and follow steps 1 to 8 to install the printer

driver.

Special Notes for Windows 98 or Windows Me USB Users

Click

Cancel

to quit the screen and turn off the printer. Next, remove and replace the USB cable

connected to your computer.

When printing via IrDA, align the infrared port of

the computer to that of the printer.

OFF

Place the Setup Software & User’s

Guide CD-ROM in the CD-ROM drive.

Follow the instructions displayed on

screen. When the screen shown on the

left is displayed, click Install.

When the screen shown on the left

appears, turn the printer on.

If the printer is recognized, the printer driver will be

automatically installed.

Click OK.

Before you use the printer, you must carry out print head

alignment on page 11.

• If the CD-ROM does not run automatically, click

Start and select My Computer, then double-click

the CD-ROM icon. For non-XP Windows, double-

click My Computer in the Windows screen, then

double-click the CD-ROM icon.

• If the language selection screen appears, select a

language, then click the

button.

• If the USB connection is not recognized, refer to

“Notes on Handling the USB Interface (for

Windows Users)” on page 23.

• If the computer is not recognized when you use

infrared transmission, carry out the following

operations:

1. Click Manual selection.

2. Select the port from Selected Port:

· Windows XP/Windows 2000o[IR]

· Windows Me/Windows 98/Windows 95o[LPT3]

then click Next.

* Some computers may allocate port number for

infrared ports differently.

Altri manuali per i70 Series

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Canon Stampante

Canon

Canon iR3300 Series Manuale utente

Canon

Canon i-SENSYS X C1946P Manuale utente

Canon

Canon BJ-20 Manuale utente

Canon

Canon PowerShot G1 X Manuale di istruzioni

Canon

Canon 2909B002 Manuale utente

Canon

Canon imagePROGRAF W6400 Manuale utente

Canon

Canon imageRUNNER ADVANCE DX 4700 Series Manuale utente

Canon

Canon TS8200 Series Manuale utente

Canon

Canon I450 - i 450 Color Inkjet Printer Manuale utente

Canon

Canon BJC-S900 Manuale utente

Canon

Canon LBP3200 Series Manuale utente

Canon

Canon iP6210D - PIXMA Color Inkjet Printer Guida alla configurazione

Canon

Canon varioPRINT 6000 TITAN Series Manuale utente

Canon

Canon MF832Cdw Manuale utente

Canon

Canon MultiPASS L90 Manuale utente

Canon

Canon IR C2100 Manuale di programmazione

Canon

Canon BJC-55 Series Manuale di riferimento

Canon

Canon PIXMA TR4500 Series Guida all'installazione

Canon

Canon imagePROGRAF iPF8300 Manuale utente

Canon

Canon g3000 series Manuale utente

Canon

Canon iP100 - PIXMA Color Inkjet Printer Manuale utente

Canon

Canon Color imageCLASS MF8280Cw Manuale di servizio

Canon

Canon BJC-600 Manuale utente

Canon

Canon Oce VarioPrint 135 Manuale utente

Manuali Stampante popolari di altre marche

Lexmark

Lexmark 1400 Series Manuale

Evolis

Evolis Elypso Manuale utente

Kyocera

Kyocera FS-9530DN Manuale utente

Samsung

Samsung BIXOLON SRP-350plusF Manuale utente

Dell

Dell Color Laser Printer 2130cn Manuale utente

Tektronix

Tektronix Phaser 840 Manuale utente

Epson

Epson ET-7750 Istruzioni operative

Eltron

Eltron P210 Guide Manuale utente

Ricoh

Ricoh MD-P1 Manuale utente

Epson

Epson SC-F7100 series Manuale utente

Epson

Epson Stylus C40UX Manuale utente

IRA3D

IRA3D POETRY4 Manuale utente

Ricoh

Ricoh Aficio AP400 Manuale utente

BIXOLON

BIXOLON SRP-352plusV Manuale utente

Epson

Epson Stylus Photo PX700W Istruzioni per il montaggio

Ricoh

Ricoh SP204SF Manuale utente

Star Micronics

Star Micronics futurePRNT TSP100 Manuale utente

Epson

Epson TM-TM88V-i Manuale per l'uso e la cura

Canon i70 Series Manuale utente

Manuali Stampante popolari di altre marche
