Canon ImageCLASS LBP622Cdw Manuale utente

FT6-2237 (000) XXXXXXXXXX Copyright CANON INC. 2018 PRINTED IN XXXXX

Getting Started

Imprimé XXX XXXXX

Quick Operation P.21

Quick Setup NEXT PAGE

Please read "Important Safety Instructions" before operating this product. After you finish

reading this guide, store it in a safe place for future reference.

The information in this document is subject to change without notice.

Getting Started

Mise en route

Introducción

Introdução

canon.com/oip-manual

Getting Started

Please read "Important Safety Instructions" before operating

this product.

P.26

After you nish reading this guide, store it in a safe place for

future reference.

The information in this document is subject to change

without notice.

Mise en route

Prenez connaissance des "Consignes de sécurité importantes"

avant toute utilisation de ce produit.

P. 32

Après en avoir pris connaissance, conservez ce guide dans

un endroit sûr en vue de consultations ultérieures.

Les informations contenues dans ce document peuvent être

modiées sans avis préalable.

Introducción

Lea las "Instrucciones de seguridad importantes" antes de usar

este producto.

página 38

Cuando termine de leer esta guía, guárdela en un lugar

seguro para futuras consultas.

La información de este documento puede ser modicada sin

previo aviso.

Introdução

Leia "Instruções de segurança importantes" antes de operar

este produto.

página 44

Depois de ler este guia, guarde-o em um local seguro para

referência futura.

As informações contidas neste documento estão sujeitas a

alterações sem aviso prévio.

You can access

canon.com/oip-manual to read the User's Guide that de-

scribes all functions of this machine.

Le guide de l'utilisateur,

qui décrit toutes les fonctions de cet appareil se trouve sur

canon.com/oip-manual.

Puede acceder a

canon.com/oip-manual para leer la Guía de usuario donde

se describen todas las funciones de este equipo.

Você pode acessar

canon.com/oip-manual para ler o Guia do usuário que

descreve todas as funções desta máquina.

Quick Setup

Before starting the installation

• Remove all of the tape.

• Do not remove the sticker that covers the USB

port.

Sticker

Installation Requirements

Provide a space of 4" (100 mm) or more around

the machine.

17"

(430 mm)

14 7/8"

(377 mm) 16 1/2"

(418 mm) 8 1/2"

(216 mm)

11 3/8"

(287 mm)

× 4

Starter toner cartridges are included.

Installing the MachineItems Included with the Machine

Installation of the Machine

Quick Setup

Up to here

Installation of the Machine

Quick Setup

Next, proceed to configure the machine.

Quick Setup

Configuring the Method of

Connecting to a Computer

2. Configure the initial settings, according to the

screen.

• Set the language and country/region.

• Set the time zone and current date/time.

Before starting the configuration

• The machine cannot be connected to both

wired and wireless LANs at the same time.

• If the machine is connected to an

unsecured network, your personal

information might be leaked to a third

party. Please be aware and careful of this.

• The machine does not come with a

router. Please have one ready, if necessary.

• Even in an environment without wireless

LAN router, you can use Access Point

Mode to make a wireless connection to

the machine directly from your mobile

device (Direct Connection).

User's Guide

Specifying the connection method

NoYes

Use wireless LAN to

connect to network?

(Can config. later.)

• To connect via wireless LAN : <Yes>

• To connect via wired LAN or USB : <No>

To connect via wireless LAN

1. Make sure that the computer is connected to a

router properly.

2. Check the network settings on the computer.

NOTE

Parts and functions of the operation panel

P.22 "Start the Operation from the Operation

Panel"

Configuring the Initial Settings of

the Machine

Configuring the Machine Configure the settings in the following order.

Quick Setup

For details

"Setting Up Using the Setup Guide" in the User's Guide

3. Take note of the SSID and network key.

• Check the label on the router. User's Guide

• The setting operation is easier if the router is

provided with a WPS mark. User's Guide

4. Set the access point and network key

according to the screen below.

For more

information, refer

to the manual.

1. Select <OK>.

2. Select <SSID Settings>.

3. Select <Select Access Point>.

4. Select the access point (SSID).

5. Enter a WEP key (network key), and select

<Apply>.

6. Select <Yes>.

• Wait until message <Connected.> is displayed.

7. Select <Close>.

• The IP address will be automatically

configured in a few minutes.

To view a video guide on the process

You can find a video and guide to assist the

process for the Wireless Network connection

from the URL below. Viewing these guides will

ensure a smooth setup of the device into your

existing wireless environment.

http://www.usa.canon.com/WirelessHelp

"Toner replenishment service" settings

Precautions

• Use of the toner replenishment service

requires prior registration with select

retailers. This service is only available in

certain countries.

Through the toner replenishment service, new

toner cartridges are automatically delivered to you

before your existing toner cartridge is used up.

• This service can be set up through "Toner

Delivery Settings" displayed on the Home screen.

Did you sign up for

toner replenishment

service when you

purchased this

product?

To continue setup

for automatic toner

delivery, press OK,

then press OK again

(if you agree) on

the next screen.

*Network connection

required to complete

registration.

Next Screen:

Press OK

1. Press OK .

2. Press OK .

• To skip "Toner replenishment service" (or set it

later), press and proceed to Step 4.

3. Press OK .

• If an error message appears, follow the on-screen

instructions to resolve it.

4. Install the driver and software.

P.9 "Installing the software"

Now you are nished with the

conguration of the initial settings.

Quick Setup

To connect via wired LAN

The machine does not come with a LAN cable.

Please have one ready, if necessary.

1. Make sure that the computer is connected to a

router properly.

2. Check the network settings on the computer.

3. Connect the LAN cable.

• After connecting the cable, wait a few minutes

(until the IP address is set automatically).

• If a static IP address has been set on the

computer, set the machine's IP address

manually.

4. Install the driver and software.

P.9 "Installing the software"

Now you are finished with the

configuration of the initial settings.

To connect via USB

• The machine does not come with a USB cable.

Please have one ready, if necessary.

• Make sure that the USB cable you

use has the following mark.

• Do not connect the USB cable before installing

the driver. If you did, disconnect the USB cable

from the computer, close the dialog box, and then

perform the following procedure from step 1.

1. Install the driver and software.

P.9 "Installing the software"

• When a screen with instructions for connecting

the USB cable to the machine is displayed,

remove the sticker that covers the USB port.

Now you are finished with the

configuration of the initial settings.

Configuring the Machine

Quick Setup

Installing the software

• The procedure described here is only applicable

when your computer runs on the Windows OS.

For more details on the software installation

procedure, see the driver's manual.

• For the installation when your computer runs on

the macOS, see the driver's manual.

• Your machine may not come with the driver for

the macOS , depending on the time of purchase.

New drivers are uploaded to the Canon website,

and you can download and use the latest one.

If the screen is not displayed properly, re-

insert the CD-ROM/DVD-ROM or search for

"D:\MInst.exe" on the Windows platform (This

description assumes that "D:" is the CD-ROM/

DVD-ROM drive name).

Quick Setup

Configuration de la méthode

de connexion à un ordinateur

2. Configurez les réglages initiaux en suivant les

instructions à l'écran.

• Spécifiez la langue et le pays/région.

• Spécifiez le fuseau horaire et réglez la date et

l'heure.

Avant de commencer la configuration

• Il n'est pas possible de connecter

l'appareil à la fois à un réseau sans fil et

à un réseau filaire.

•

Faites attention, si l'appareil est connecté à un

réseau non sécurisé, vos données personnelles

peuvent être divulguées à un tiers.

• L'appareil n'est pas livré avec un routeur.

Vous devez vous en procurer un.

•

Même dans un environnement sans routeur

de réseau sans fil, vous pouvez utiliser

le mode Point d'accès pour établir une

connexion sans fil entre l'imprimante et

votre appareil mobile (connexion directe).

Guide de l'utilisateur

Spécification de la méthode de connexion

NonOui

Util rés sans fil

pour conn. rés. ?

(Config. ult.)

• Connexion par réseau sans fil: <Oui>

• Connexion par réseau filaire ou USB: <Non>

Connexion par réseau sans fil

1. Assurez-vous que l'ordinateur est correctement

connecté à un routeur.

2. Vérifiez les réglages réseau sur l'ordinateur.

REMARQUE

Sections et fonctions du panneau de commande

P.28 "Lancez l'opération depuis le panneau

de commande"

Configuration des réglages

initiaux de l'appareil

Configuration de l'appareil

Configurez les réglages dans l'ordre suivant.

Configuration rapide

Altri manuali per imageCLASS LBP622Cdw

Indice

Lingue:

Altri manuali Canon Stampante

Canon

Canon imagePROGRAF iPF8300 Manuale utente

Canon

Canon BJC-55 Series Manuale di riferimento

Canon

Canon S830D Manuale utente

Canon

Canon imagePROGRAF iPF6400S Series Manuale utente

Canon

Canon C1333iF Manuale utente

Canon

Canon iPF6100 - imagePROGRAF Color Inkjet Printer Manuale utente

Canon

Canon LBP352 Manuale utente

Canon

Canon iR2030 Manuale utente

Canon

Canon MultiPASS L60 Scheda informativa del prodotto

Canon

Canon SELPHY CP770 Guida alla configurazione

Canon

Canon iR3530 Scheda informativa del prodotto

Canon

Canon Pixma MG3270 Series Manuale utente

Canon

Canon imageCLASS LBP6300dn Manuale utente

Canon

Canon IPF670 Manuale utente

Canon

Canon Pixma TR7800 Series Guida all'installazione

Canon

Canon LBP-3200 Manuale utente

Canon

Canon Oce PlotWave 300 Manuale di istruzioni

Canon

Canon Pixma TS7700i Series Manuale utente

Canon

Canon Color imageRUNNER LBP5360 Manuale di istruzioni

Canon

Canon imagePROGRAF iPF6300S Guida utente

Canon

Canon iRC3380 Guida

Canon

Canon imageCLASS MF273dw Manuale utente

Canon

Canon PIXMA MP240 Manuale utente

Canon

Canon iP8500 - PIXMA Color Inkjet Printer Manuale

Manuali Stampante popolari di altre marche

Lexmark

Lexmark 1400 Series Manuale

Evolis

Evolis Elypso Manuale utente

Kyocera

Kyocera FS-9530DN Manuale utente

Samsung

Samsung BIXOLON SRP-350plusF Manuale utente

Dell

Dell Color Laser Printer 2130cn Manuale utente

Tektronix

Tektronix Phaser 840 Manuale utente

Epson

Epson ET-7750 Istruzioni operative

Eltron

Eltron P210 Guide Manuale utente

Ricoh

Ricoh MD-P1 Manuale utente

Epson

Epson SC-F7100 series Manuale utente

Epson

Epson Stylus C40UX Manuale utente

IRA3D

IRA3D POETRY4 Manuale utente

Ricoh

Ricoh Aficio AP400 Manuale utente

BIXOLON

BIXOLON SRP-352plusV Manuale utente

Epson

Epson Stylus Photo PX700W Istruzioni per il montaggio

Ricoh

Ricoh SP204SF Manuale utente

Star Micronics

Star Micronics futurePRNT TSP100 Manuale utente

Epson

Epson TM-TM88V-i Manuale per l'uso e la cura

Canon imageCLASS LBP622Cdw Manuale utente

Manuali Stampante popolari di altre marche
