Setup Guide

3User's Guide / FAQ

• After you finish reading this guide, store it in a safe

place for future reference.

• The information in this guide is subject to change

without notice.

1Important Safety Instructions

Be sure to read these instructions before using

the machine.

2Setup Guide (this document)

1234567 12

Checking the Items

Included

Removing the Packing

Material

1. Install the machine in the location where it

will be used.

2. Remove all packing material.

Remove all of the tape.

Do not remove the sticker that covers the USB port

until you actually use the USB port.

Loading Paper

1 2 3 4 5 6 7 12

A5/A4

Ensure that the amount

of paper loaded is not

above this line

Installing the Optional

Part

If you are not using optional part, proceed to

step .

Before Installing the Optional Part

When installing the optional part after the machine has

been installed, perform the following before starting work:

1. Shut down the machine and your computer.

2. Unplug the machine from the mains power outlet.

3. Disconnect all cords and cables from the machine.

Cassette feeding module

1. Install the cassette feeding module in the

location where it will be used.

1234567 12

45678 121

Connecting the Power Cord

Specifying the Basic

Settings

When you turn on the machine for the first time, the Setup

Guide starts up on the operation panel. Perform the initial

machine setup by following the on-screen instructions.

Operation panel

1. Select the language, then the country/

region and finally the time zone.

2. Set the current date/time.

Specifying the Security

Settings

Specify the basic security settings to prevent unauthorized

access to the machine.

1. To use the Remote UI, select <Yes>.

To continue without using the Remote UI, select

<No> and proceed to step 8.

2. To use General User mode, select <Yes>.

• Set the PIN to be used by general users to access

the Remote UI.

• To continue without using General User mode,

select <No> and proceed to step 8.

3. Set the Remote UI Access PIN.

• Enter any number and then select <Apply>.

• Re-enter the same PIN on the next screen as

confirmation and select <Apply>.

1 2 3 4 5 6 7 12

6 7 8 9 1110 121

Specifying the Network

Settings

Specify the settings for connecting the machine to a

network. Before proceeding, check that the computer and

router are correctly connected to the network.

Wireless LAN

1. Check the router's "SSID" and "Network

key."

SSID : XXXXXXXXXXXX

Network key : XXXXXXXXXXXX

2. To configure the settings, select <Yes> on

the operation panel.

3. Check the message and select <OK>.

4. Select the network with a matching SSID.

5. Enter the password (network key) and select

<Apply>.

Wired LAN

Connect the router to the machine with a LAN cable and

then select <No> in the screen for choosing how to

connect to the network.

8Setting Up the Toner

Replenishment Service

Use this procedure to set up the toner replenishment

service. To use this service, you must enter into an

agreement beforehand.

1. Check the message and select <Next>.

2. Check the conditions of use, and then

choose whether or not to use the service.

• To use the service: <Accept>.

• To not use the service or not enter into an

agreement: Select <Do Not Accept> and proceed

to step 10 .

3. When <Connection was successful.> appears,

select <OK>.

Ending the Setup Guide

Check the description in the Application Library and then

select <End>.

Installing the Software/

Drivers

Install the software and drivers from the CD/DVD-ROM

included, or visit the URL below and download them from

the Canon website for your country/region.

https://global.canon/en/support/

Example: MF455dw download

XXXXXXX download

Next, configure the fax settings.

1234567 1245678 121

6789 1110 121

Fax Setup

The first time you select <Fax> on the Home screen, the Fax Setup Guide starts up.

Setup Procedure

1. Select <Fax> on the Home screen.

2. Select <Set Up Now>.

3. Select <Next>.

4. Enter the Unit Telephone Number and

select <Apply>.

5. Select <Next>.

6. Enter the Unit Name (name and company

name, etc.) and select <Apply>.

7. Select the receive mode that best suits your

telephone connection and the way you

receive calls.

Refer to the illustration below and select <Yes> or

<No>. Finally, select <Apply> to set the receive

mode.

8. Connect the machine to a telephone line.

Telephone line jack

Telephone

9. When you have completed the connection,

select <End>.

10. Select <Yes>.

Selecting the Receive Mode

Start

Do you want to

connect a telephone?

Yes

Do you want to use an

answering machine?

Do you want to receive faxes

automatically?

Manual

Auto

Answering Machine

Fax/Tel (Auto Switch)

Can be used for both fax and phone. Allows you

to check for incoming faxes and receive them

manually.

Can be used for both fax and phone. Receives faxes

automatically.

Can be used for both fax and phone. Uses an

answering machine function to record phone

messages while you are away. Receives faxes

automatically.

For fax use only. Receives faxes automatically.

https://oip.manual.canon/https://oip.manual.canon/

• Après avoir lu ce guide, rangez-le dans un

endroit sûr pour information.

• Les informations figurant dans ce guide sont

sujettes à modifications sans préavis.

Guide de

configuration

1Consignes de sécurité importantes

Veillez à lire ces instructions avant d'utiliser l'appareil.

3Guide de l'utilisateur / FAQ

2Guide de configuration

(ce document)

1 2 3 4 5 6 7 12

Vérification des articles

inclus

Retrait du matériel

d'emballage

1. Installez l'appareil là où il sera utilisé.

2. Retirez tout le matériel d'emballage.

Retirez tout le ruban adhésif.

Ne retirez l'autocollant qui recouvre le port USB

qui si vous avez besoin d'utiliser le port USB.

Chargement du papier

1 2 3 4 5 6 7 12

A5/A4

Assurez-vous que la quantité

de papier chargée ne dépasse

pas cette ligne

Installation de

l'équipement en option

Si vous n'utilisez pas l'équipement en option,

passez à l'étape .

Avant d'installer l'équipement en option

Avant d'installer l'équipement en option sur l'appareil que

vous avez installé, effectuez les opérations suivantes :

1. Éteignez l'appareil et l'ordinateur.

2. débrancher l'appareil de la prise secteur.

3. Débranchez tous les cordons et les câbles de

l'appareil.

Module de cassette

1. Installez le module de cassette là où il sera

utilisé.

1 2 3 4 5 6 7 12

4 5 6 7 8 121

Branchement du câble

d'alimentation

Réglages de base

Lorsque vous allumez la machine pour la première fois, le

guide de configuration s'ouvre sur le panneau de

commande. Effectuez la configuration initiale de la

machine en suivant les instructions à l’écran.

Panneau de commande

1. Sélectionnez la langue, puis le pays ou la

région et enfin le fuseau horaire.

2. Définissez la date/heure actuelle.

Paramètres de sécurité

Spécifiez les paramètres de sécurité de base pour

empêcher les accès non autorisés à l'appareil.

1. Pour utiliser l'interface utilisateur distante,

sélectionnez <Oui>.

Pour continuer sans utiliser l'interface utilisateur

distante, sélectionnez <Non> et passez à l'étape 8.

2. Pour utiliser le mode Utilisateur général,

sélectionnez <Oui>.

• Définissez le code PIN à utiliser par les utilisateurs

généraux pour accéder à l'interface utilisateur

distante.

• Pour continuer sans utiliser le mode Utilisateur

général, sélectionnez <Non> et passez à l'étape

3. Définissez le code PIN d'accès à l'interface

utilisateur distante.

• Saisissez un nombre puis sélectionnez <Appliquer>.

• Saisissez de nouveau le même code PIN sur

l'écran suivant pour confirmation, puis

sélectionnez <Appliquer>.
