Canon MF832Cdw Manuale utente
En
He
Setup Guide
3User's Guide / FAQ
1Important Safety Instructions
Be sure to read these manuals before using
the machine.
• After finish reading this guide, store it in a safe place
for future reference.
• The information in this guide is subject to change
without notice.
2Setup Guide (this document)
https://oip.manual.canon/
2
1234567
En
He
Checking the Items
Included
× 4
Removing the Packing
Material
1. Install the machine in the location where it
will be used.
2. Remove all the packing material.
Remove all of the tape.
Loading Paper
1.
2.
A4 A5/A4
1
2
3
En
He
3
1234567
3.
Ensure that the amount
of paper loaded is not
above this line
4.
Installing the Optional
Product
If you are not using optional product,
proceed to step .
Before Installing the Optional Product
When installing the optional product after the machine
has been installed, perform the following before starting
work:
1. Shut down the machine and your computer.
2. Unplug the machine from the mains power outlet.
3. Disconnect all cords and cables from the machine.
4
Paper Feeder/Cassette Pedestal
1. Install the paper feeder in the location
where it will be used.
2.
3.
4.
4
1234567
En
He
1234567
• You can stack up to two paper feeders.
5.
6.
When Using the Cassette Pedestal
1. Install the cassette pedestal in the location
where it will be used.
2.
Lock the four casters.
3.
4.
5.
6.
En
He
5
1234567
• You can stack up to two paper feeders and a
cassette pedestal with the machine.
Handset
1.
2.
Insert the attached pin
halfway (Do not insert it
all the way in here).
3.
Insert the pin all the
way in.
4.
Connecting the Cords
and Cables
1. To connect to a wired LAN, connect the
machine to the router using a LAN cable.
2. To use the machine for faxes, connect it to
the phone line using a modular cable.
Telephone line jack
Telephone
Handset (Optional)
• Always check the line before connecting.
Connecting to a dedicated line for business
phones, etc. could cause a fault.
3. Connecting the Power Cord.
1
2
5
6
1234567
En
He
1234567
Setting Up Using the
Setup Guide
When you turn the machine on for the first time, the
Setup Guide starts up on the operation panel.
Operation panel
Scan the following QR code for information on
using the Setup Guide.
Installing the Software/
Drivers
Install the software and drivers from the CD/DVD-ROM
included, or visit the URL below and download them from
the Canon website for your country/region.
https://global.canon/en/support/
XXXXXXX download
Example: MF832Cdw download
6
7
What You Can Use the
1Specifying the Basic Settings
6
Adjusting the Gradation Automatically
Specify basic settings such as the screen display
language and the type of paper used.
You can adjust the color gradations to get a better
printing result.
En
He
7
1234567
Setup Guide For
2Specifying the Security Settings 3Setting the Date and Time
4Specifying the Network Settings
5Specifying the Fax Settings
Set the machine's date and time.
Specify the settings for connecting the machine to a
network.
Select a wired LAN or wireless LAN and specify the IP
address. Depending on your network environment,
specify the DNS and proxy settings also.
Specify the administrator login and user authentication
settings to improve the security of the machine.
The default administrator login is "Administrator"
and the default password is "7654321".
Specify the settings required for using the fax
functions.
8
10
En
He
7654321
םילולכה םיטירפה לש הקידב
4 ×
הזיראה רמוח תרסה
1 . תדעוימ איה וב םוקימב הנוכמה תא וניקתה
.שומישל
2 ..הזיראה רמוח לכ תא וריסה
.םיטרסה לכ תא וריסה
ריינ תניעט
.
2 .
2
3
A4 A5/A4
1
