Canon PIXMA iP4820 Series Manuale utente

Make sure to read this manual before using the printer. Please keep it in hand for future reference.

Getting Started

Read Me First

Canon Inkjet Premium Photo Printer

series

Symbols Used in This Document

Instructions including important information.

Prohibited actions.

In this guide, Windows 7 operating system is referred to as Windows 7

and Windows Vista operating system as Windows Vista.

In this guide, the screens are based on Windows 7 Home Premium

and Mac OS X v.10.6.x. (Unless noted otherwise, the screens are

those of Windows 7.)

•

Preparation.....................................................P.1

Try Using the Printer.......................................

P.17Print Photos from a Computer..........................

Load Paper.....................................................

Install the Software.........................................

Install the Print Head ......................................

2P.3

P.8

P.13

P.16

Install the Ink Tanks ........................................

3P.6

Specications .................................................

7P.18

Describes how to set up and use

your printer. Introduces the printer

and its functions, the included

manuals and application software.

Getting Started

(this manual)

Describes basic operations

and media, and gives

an introduction to other

functions available.

Describes various operating

procedures to make full use

of printer.

Describes troubleshooting

tips for problems you may

encounter when using the

printer.

Basic Guide Advanced Guide Troubleshooting

For details on opening the on-screen manuals, refer to page 16.

On-Screen Manuals

Printed Manual

This printer contains both printed manuals and on-screen manuals to be viewed on a computer.

The on-screen manuals are included on the Setup CD-ROM and are installed during the software installation.

Model Number: K10357 (iP4820)

321

Preparation

Do not install the printer

where an object may

fall on it. In addition, do

not place any object on

the top of the printer. It

may fall into the printer

when opening covers,

resulting in malfunction.

•

A USB cable is necessary to connect the printer with your

computer.

•

Make sure all the following items are supplied. Remove all orange tape and

protective materials from the inside

and outside of the printer.

1. Print Head

2. Ink tanks (5: BK, M, C, PGBK, Y)

3. Manuals

4. Power cord

5. Setup CD-ROM (containing the drivers, applications and on-

screen manuals)

6. Matte Photo Paper MP-101 (for Automatic Print Head Alignment)

7. Other documents

21 Preparation

When removing the power plug, make sure that the POWER lamp is

not lit before removing the plug. Removing the power plug while the

POWER lamp lights up or ashes may cause drying and clogging of

the Print Head, resulting in poor printing.

•

When it is necessary to turn off the printer

Be sure to follow the procedure below.

It may take up to 35 seconds until the printer turns off.

1. Press the ON button to turn off the printer.

2. Make sure that the POWER lamp is not lit.

Insert the power cord

into the connector on the

printer and into the wall

outlet rmly.

Do NOT connect

the USB cable at

this stage.

•

Press the ON

button (A) to turn

on the printer.

Make sure that

the POWER lamp

(B) lights green.

The specication of the power cord differs for each country or region.•

2123

Install the Print Head

Open the Paper Output Tray (A). Open the Top Cover (B). The Print Head Holder (C) moves

to the installation position.

If the Print Head Holder does not move,

make sure that the printer is turned on.

4 65

42 Install the Print Head

Firmly lift the part (D) of the Print Head Lock Lever in the Print Head

Holder until it stops.

Remove the Print Head from the

silver package.

Remove the orange protective cap.

Do not touch the inside (E) or metal parts (F) of the Print Head. The

printer may not print properly if you touch them.

There may be some ink on the inside of the bag the Print Head comes in,

or the inside of the protective cap - this has no effect on print quality. Be

careful not to get ink on yourself when handling these items.

•

7 8

2 Install the Print Head

Tilt the Print Head forward and set it in place as shown. Hold the Print Head Lock Lever rmly and lower it completely.

Do not knock the Print Head against the sides of the holder.• Once you have installed the Print Head, do not remove it

unnecessarily.

•

3123

Install the Ink Tanks

1. Remove the orange tape

completely.

2. Remove the protective lm

completely.

Handle the ink tanks carefully. Do not drop or apply excessive pressure to

them.

Be sure to use the supplied ink tanks.

If the orange tape remains on the L-shape air hole, ink may splash or the

printer may not print properly.

If you push the sides of the ink tank with the L-shape air hole blocked, ink

may splash.

•

Hold the ink tank with the orange

protective cap (A) pointing up while

being careful not to block the L-

shape air hole (B).

Do not touch the inside (C) of the orange protective cap or

the open ink port (D). The ink may stain your hands if you

touch them.

•

Hold the ink tank by its sides and slowly twist the orange

protective cap 90 degrees horizontally to remove it off.

Do not push the sides of the ink tank.

4 5 6 7

3 Install the Ink Tanks

Tilt the ink tank, then insert it

under the label and against

the back end of the slot.

Press the PUSH mark on the

ink tank rmly until it clicks.

When the installation is

completed properly, the Ink

lamp lights red.

Install all the other ink tanks

in the same way according to

the color order indicated on

the label.

Make sure that the color of the

label matches the ink tank.

Close the Top Cover (E).

The POWER lamp (green) (G) flashes for about 5

minutes, then stays lit. Wait until the lamp stays lit

and go to the next step.

•

If the Alarm lamp (H) ashes orange, make sure

that the Print Head and the ink tanks are correctly

installed.

•

Make sure the Inner Cover (F) is closed.

Quit all applications before installation.

Log on as the administrator (or a member of the

Administrators group).

•

To use the printer by connecting it to a computer,

software including the drivers needs to be copied

(installed) to the computer's hard disk. The

installation process takes about 20 minutes. (The

installation time varies depending on the computer

environment or the number of application software to

be installed.)

•

If you connect the printer via USB cable before installing the

software:

□

If the dialog box closes, proceed to

on page 9.

1. Remove the USB cable

connected to your computer.

1. Remove the USB cable connected to your computer.

2. Proceed to on page 9.

2. Click Cancel.

3. Proceed to on page 9.

Do not connect the USB cable yet.

Install the Software

Easy-WebPrint EX□

Easy-WebPrint EX is Web print software that is installed on the

computer when installing the supplied software. Internet Explorer

7 or later is required to use this software. An Internet connection

is required for installation.

For Windows 7

This dialog box may appear.

For Windows Vista/Windows XP
