Canon PIXMA iP8720 Manuale utente
Getting Your Printer
Back On Your Network
After A Router Or Network Change
PIXMA iP8720
Mac OS
1
Getting Your Printer
Back On Your Network
After A Router Or Network Change
PIXMA iP8720
Mac OS
Preparing to Connect My Printer to the Network 3
Network Requirements 3
Notes on Wireless Connection 4
Installing the Drivers & Software 5
2
Important
If any of the following situations exist
•You have replaced your Router or Access Point
•You want to use a different wireless network
•Router settings have been changed.
Please complete the following steps to apply the new configuration settings to your printer.
3
<< Previous Next >>
Information
Preparing to Connect the Multifunction
To the Network
Network Requirements
Before connecting the machine to the network, make sure that configuration of the computer and access point or router is
complete, and that the computer is connected to the network.
Wireless Connection
Before connecting the machine to the network, the computer needs to be connected to the network. Make sure that
configuration of the computer and access point or router is complete.
4
Preparing to Connect the Multifunction
To the Network
5
Notes on Network Connection
•The configuration, router functions, setup procedures and security settings of
the network device vary depending on your system environment. For details,
refer to your device's instruction manual or contact its manufacturer.
•In an office setup, consult your network administrator
•If you connect to a network that is not protected with security measures, there
is a risk of disclosing data such as your personal information to a third party.
•Place the machine and computer on the same network segment.
An "Ad-hoc connection," which establishes a direct
connection to the computer over a wireless connection
without using an access point, is not supported.
Software Installation
To use the machine by connecting it to a computer, software including the drivers needs to be copied (installed) to the computer's hard disk.
Installation time varies depending on the computer environment or the number of application software to be installed.
Installing the Drivers & Software
6
IMPORTANT
•Log on as the administrator (or a member of the Administrators group).
•Quit all running applications before installation.
•Do not switch users during the installation process.
•Internet connection may be required during the installation. Connection fees may apply. Consult the internet service provider.
•If the firewall function of your security software is turned on, a warning message may appear that Canon software is attempting to access
the network. If such a warning message appears, set the security software to always allow access.
When you reinstall your printer on your network because of a router or network change, you follow the same procedure as for a first time
install. A step-by-step walk through of the wireless setup is built into the installation routine of the software for your PIXMA.
To begin the reinstall of your PIXMA iP8720 to your wireless network, you must first download the software to your computer.
Click here to access the IJ Setup site. Read the Product Setup instructions, then click Download. Double-cick the downloaded file to start the
install procedure.
If the following screen appears, click Start Setup Again
Installing the Drivers & Software
7
<< Previous Next >>
Installing the Drivers & Software
88
After starting the setup, follow on-screen instructions until the 2-1 Printer Setup screen. Click Connect to the Network
Installing the Drivers & Software
99
Select Cableless setup on the 3-1 Setup Procedure Selection screen.
Installing the Drivers & Software
1010
Continue to follow on-screen instructions.
As directed in the 4-1 Connection via Cableless setup screen, hold down the Wi-Fi button on the printer until the POWER lamp flashes twice,
then release the Wi-Fi button
