Canon PIXMA K10335 Manuale utente

Make sure to read this manual before using the printer. Please keep it in hand for future reference.

Getting Started

Read Me First

series

Photo Printer

Contents

After Installing the Printer

Install the Software

Install the Ink Tanks

Install the Print Head

Turn the Power On

Loading Paper

Preparation

Symbols■

The following symbols are used to mark important instructions. Observe these instructions.

Additional explanations.

Instructions that, if ignored, could result in personal injury or material damage.

Instructions that must be observed for safe operation.

Model Number: K10335 (Pro9000 Mark II)

Macintosh and Mac are trademarks of Apple Inc., registered in the U.S. and other countries.•

Descriptions for operations that take some time to complete.

Microsoft is a registered trademark of Microsoft Corporation.•

Windows is a trademark or registered trademark of Microsoft Corporation in the U.S. and/or other countries.•

Windows Vista is a trademark or registered trademark of Microsoft Corporation in the U.S. and/or other countries.•

Caution

Adobe, Adobe Photoshop, Adobe RGB and Adobe RGB (1998) are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and or other countries.•

1Preparation

Check the Included Items■

Manuals•

ink tanksPrint Head

Before turning on the printer, remove all the orange tapes and the protective sheets.

Setup CD-ROM (containing the drivers, applications and on-screen manuals)•

Warranty•

power cord

A USB cable is necessary to connect the printer with your computer.•

612345

Place the printer on a flat surface.•

Do not place any object in front of the printer.•

You can print on large size paper such as 14" x 17"/355.6 x 431.8 mm or thick paper by loading the

paper in the Front Tray. In that case, keep a space of 15.7"/40 cm behind the printer.

•

Choosing a Location■

Do not install the printer where an object may fall on

it. The object may fall inside the printer, resulting in

malfunction.

•

Do not place any object on top of the printer. It may

fall into the printer when opening covers, resulting in

malfunction.

•

There are wheels on the back corners of the printer. Lift the front of the printer to move it back and forth easily.•

15.7"/40 cm behind the printer

612345

21 3

Turn the Power On

Conrm that the POWER lamp (B) lights green.Turn on the printer (A).Plug the power cord into the back left of the

printer, then connect the other end to the wall

outlet.

Do NOT connect the USB cable at this stage.•

61 2 34 5

Install the Print Head

Handle the Print Head carefully. Do not drop or

apply excessive pressure to it.

•

Open the Top Cover (C).

The Print Head Holder (D) comes out. (This is where you install the

Print Head.)

The Print Head Holder makes a noise as it moves. This is normal operation.•

If the Print Head Holder does not move, make sure that the printer is turned on.•

Press the button (A).

The Front Tray (B) opens.

4 53

Firmly raise the Print Head Lock Lever (E) until it stops.

There may be some transparent or light blue ink on the inside of the bag the Print Head comes in,

or the inside of the protective cap - this has no effect on print quality. Be careful not to get ink on

yourself when handling these items. Be careful not to stain your hands.

•

Remove the orange protective cap.Remove the Print Head from the silver

package.

61 2 34 5

Lower the Print Head Lock Lever (E) completely.Set the Print Head in place.

Pinch the Print Head Lock Lever rmly and lower it gently.•

Do not knock the Print Head against the sides of the holder.• Once you have installed the Print Head, do not remove it unnecessarily.•

Install the Ink Tanks

Handle the ink tanks carefully. Do not drop or

apply excessive pressure to them.

•

Pull the orange tape (1) in the

direction of the arrow to peel off the

protective lm and remove the lm (2)

completely.

Do not hold the sides of the ink tank; ink may splash.•

If the Print Head Holder moves to the right, close

and reopen the Top Cover.

•

Be sure to use the supplied ink tanks.•

While pressing down with your left thumb, twist off the orange

protective cap (A) located on the bottom of the ink tank.
