Canon DR 7090C - imageFORMULA - Document Scanner Manuale utente
Ultimate Document Scanning Flexibility and Image Quality
For High-Volume Scanning
The Canon imageFORMULA DR-7090C universal production scanner delivers flexibility,
image quality, and reliability, at high scanning speeds by leveraging the technologies from
its award-winning imageFORMULA and imageRUNNER®product lines.
Flexible Two-Way Design
The versatile DR-7090C scanner has a two-way design that’s
capable of fast one-pass duplex rotary and easy flatbed scan-
ning, both in a single compact unit. Using Canon’s award-
winning imageRUNNER Automatic Document Feeder (ADF),
the DR-7090C scanner offers fast, high-volume scanning
while the flatbed offers easy scanning of thick, hard-to-handle
documents such as books, bound reports, business cards, or
documents too fragile to pass through the feeder.
Rapid Scanning
With a 100-sheet ADF, the DR-7090C scanner achieves
rapid scanning at speeds of up to 70 pages per minute*
whether scanning color, grayscale, or black and white. Dual
image sensors enable one-pass duplex document scanning
at speeds of up to 88 images per minute.*
Outstanding Canon Image Quality
The DR-7090C scanner delivers clear, high-quality images
at resolutions up to 600 dpi and in diverse formats such as
searchable and encrypted PDF. Intricate details are captured
with precision and clarity through intelligent scanning using
the DR-7090C scanner’s Image Controller and advanced
processing features, which include Three-Dimensional Color
Correction and two Advanced Text Enhancement modes.
Designed for Efficiency
This combination flatbed/sheetfed color production scanner
provides a high-speed scanning solution. The conveniences
and efficiencies gained from having such a well engineered
design are immeasurable. The space-saving universal
design and dual Hi-Speed USB 2.0 and SCSI-III interfaces
ensure easy integration into most business environments.
The bundled CapturePerfect 3.0 software streamlines
the image capture process and helps produce consistent,
high-quality scans from even the most difficult original
documents.
The imageFORMULA DR-7090C scanner’s blend of out-
standing image quality, flexibility, reliability, durability,
and leading value enable it to reduce costs and increase
scanning efficiencies in the production environment.
* Landscape at 300 dpi
** Long document mode up to 24.8”
High Reliability and Durability
The durable DR-7090C scanner is built to withstand the
rigors of continuous use in low-volume production scanning
environments and features a suggested daily volume of
8,000 sheets per day. In addition, the DR-7090C scanner
employs the imageRUNNER’s proven Inclined Plane
Separating Mechanism to help ensure smooth, jam-free
feeding by minimizing double-feeds from occurring. The
scanner also has a Count Only mode, which performs a
hard count of pages to help double-check that all pages are
scanned. The Canon DR-7090C scanner offers high durability
and reliability for minimum downtime.
Easy to Use and Maintain
With the versatile DR-7090C scanner, there’s no manual
presorting required when using the ADF, as the scanner auto-
matically detects the length and width of each document
in a mixed batch, up to 12" x 17".**
The scanner also offers an easy-to-use control panel that
helps ensure effortless operation, even for walk-up users.
The Scan-to-Job functions on the panel can be programmed
to support direct, one-touch scanning to e-mail, file folders,
printers, and up to 99 customized predefined jobs. The
advanced page separation mechanism ensures smooth and
efficient document feeding for unattended batch scanning.
The DR-7090C scanner also comes equipped with a tool
that enables users to reach and clean the sensor glasses for
easy maintenance.
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042
Specifications
Type: Universal Production Scanner
Document Feeding: Automatic or Flatbed
Document Size
Automatic Document
Feeder Width: 5.5" – 12"
Automatic Document
Feeder Length: 5" – 17"*
Flatbed: Maximum 12" – 17"
Weight
Automatic Document
Feeding: 11 – 32 lb. Bond
Flatbed Thickness: Up to 2"
Feeder Capacity: 100 Sheets
Grayscale: 8-bit
Color: 24-bit
Scanning Element
Front: CCD
Back: Contact Image Sensor (CMOS)
Light Source: Xenon Lamp
Scanning Modes: Simplex, Duplex, Flatbed, Auto, Color, Grayscale,
Black and White, Error Diffusion
Color Dropout: RGB
Optical Resolution: 600 dpi
Output Resolution: 100/150/200/240/300/400/600 dpi
Scanning Speeds** Simplex Duplex
Black and White: 70 ppm 88 ipm
Grayscale: 70 ppm 88 ipm
Color: 70 ppm 88 ipm
Interface: Hi-Speed USB 2.0/SCSI-III
Scanner Drivers: ISIS/TWAIN for Windows
®
2000/XP/Vista
®
Dimensions (H x W x D): 12.4" x 24.3" x 23.7"
Weight: 90.2 lb.
Power Consumption: 218W or Less (Energy Saving Mode: 6.3W or Less)
Suggested Daily Volume: 8,000 Scans***
BUNDLED SOFTWARE
• ISIS/TWAIN Driver
•Canon CapturePerfect 3.0
OPTIONS
• Exchange Roller Kit
• Cleaning Cloth A1
•9-Month Extended Service Package
• 12-Month Extended Service Package
OTHER FEATURES
ITEM NUMBER
3200B002
* 24.8" in Long Document Mode
** Examples based on typical settings, rated in pages/images per minute with
letter-sized documents at 300 dpi, landscape. Actual processing speeds may
vary based on PC performance and application.
*** Calculation based on scanning speed and assumed daily time of use.
ISIS and MultiStream are trademarks of EMC Corporation. Windows and Windows Vista
are registered trademarks of Microsoft Corporation in the United States and/or other
countries. CapturePerfect is a registered trademark of Canon Electronics Inc. CANON
and IMAGERUNNER are registered trademarks of Canon Inc. in the United States and
may also be registered trademarks or trademarks in other countries. IMAGEANYWARE
is a trademark of Canon. All other referenced product names and marks are trademarks
of their respective owners and are hereby acknowledged.
Specifications and availability subject to change without notice.
©2008 Canon U.S.A., Inc. All rights reserved.
0129W121
1108-7090C-6M-LSP
printed on recycled
paper in the u.s.a.
• Automatic Page Size Detection
• Count Only
• Deskew
• Punch Hole Removal
• User Registration
• Advanced Text Enhancement
(Two Types)
• Skip Blank Page
• Pre-scan
• Scan Area Setting
• Batch Separation
• Text Orientation Recognition
• MultiStream
™
• Edge Emphasis
• Border Removal
• Preset Gamma Curve
• Color Dropout
(RGB)/Enhancement (RED)
