Cardo Systems FREECOM1+ Manuale utente

HIGH POWEREDTECHNOLOGY

1. INTRODUCTION

Thank you for choosing the Cardo FREECOM 1+/2+ communication and entertainment system for motorcycle

helmets.

If you have not yet installed the FREECOM 1+/2+ unit on your helmet, please install it as described in the

Installation Guide provided in the package.

2. GETTING STARTED

2.1 GETTING TO KNOW YOUR FREECOM 1+/2+

2.2 CHARGING THE FREECOM 1+/2+

Make sure that your FREECOM 1+/2+ battery is charged for at least 4 hours before initial use.

To charge the unit:

1. Using the supplied USB cable, connect your computer or wall charger to the USBport on your FREECOM

1+/2+.

●Charging with the wall charger is faster than via a computer USB port.

●Charging your unit switches it off automatically. To use your unit while it is being charged, switch it

on.(see Switching Your Unit On/Off on page 5).

While charging, the LED indicates the charging status as follows:

●Red LED on — charging

●Red LED off — charging complete

2.3 SWITCHING YOUR UNIT ON/OFF

To switch your FREECOM 1+/2+on:

●Press both and for 1 second.

The speaker plays an ascending tone and a voice message greets you.

The LED confirms your FREECOM 1+/2+ is on:

●Normal and low battery — LED flashes blue three times.

●Charging — LED flashes red and purple three times.

To switch your FREECOM 1+/2+ off:

●Press both and .

The LED flashes red three times, confirming that your unit is switching off. The speaker plays a descending

tone and a voice message, "Goodbye".

2.4 USING YOUR FREECOM 1+/2+

You can operate the various features of your FREECOM 1+/2+ in the following ways:

●Press a button or combination of buttons on the unit.

●Use the Cardo Mobile App on your mobile device (once it is paired with the unit).

You can also configure your unit by connecting it to a computer with the supplied USBcable and running the

Cardo Updater while your computer is connected to the Cardo Community website.

2.5 PAIRING YOUR UNIT TO BLUETOOTH DEVICES

Your FREECOM 1+/2+ has two Bluetooth channels for connection to Bluetooth devices such as mobile phones,

GPS devices, and Bluetooth music players with A2DP.

To connect your unit to a Bluetooth device, you must first pair them. Once paired, they automatically recognize

each other whenever they are within range.

If you are pairing more than one device, Cardo recommends that you pair the mobile phone to channel 1, and

the additional device (such as GPS, music player or additional mobile phone) to channel 2.

If you are pairing the unit to more than one mobile phone, the phone paired with channel 1 is the default phone

for outgoing calls.

To pair Bluetooth channel 1 to a mobile phone:

1. Enable Bluetooth on the mobile phone.

2. On the unit in standby mode, press for 5 seconds.

The LED flashes red and blue.

3. On your mobile phone, search for Bluetooth devices.

4. When your FREECOM 1+/2+ appears in the list of available devices, select it.

If prompted for a PIN or Passkey, enter 0000 (four zeros).

The phone confirms that pairing has succeeded and the LED flashes purple for 2 seconds.

To pair Bluetooth channel 2 to another Bluetooth device:

1. Enable Bluetooth on the device (for example, your mobile phone, GPS device, or music player).

2. On the unit in standby mode, press for 5 seconds. The LED flashes red and blue.

3. Tap twice. The LED flashes red and green.

4. If you are pairing a GPS device, press .

The LED flashes slower.

5. On the device you are pairing, search for Bluetooth devices.

6. When your FREECOM 1+/2+ appears in the list of available devices, select it.

If prompted for a PIN or Passkey, enter 0000 (four zeros).

The device confirms that pairing has succeeded and the LED flashes purple for 2 seconds.

●If pairing is not completed within 2 minutes, the unit automatically returns to Standby.

●If you have paired two different mobile phones directly to your FREECOM 1+/2+, set one as default

for making calls (see Setting the Default Mobile Phone on page 16).

●Not all Bluetooth mobile phones broadcast Bluetooth Stereo music (A2DP) even if the phone has an

MP3 player function. Consult your mobile phone’s user manual for more information.

●Not all Bluetooth GPS devices allow connection to Bluetooth audio devices. Consult your GPS User

Manual for more information.

To cancel the pairing process:

●Press for 2 seconds.

The LED stops flashing red and blue/green.

To reset all Bluetooth device pairing:

1. Press for 5 seconds.

The LED flashes red and blue.

2. Press and for 2 seconds.

The LED flashes purple 5 times, confirming that pairing has been reset.

3. ON THE ROAD

FREECOM 1+/2+ makes it easy for you to receive phone calls and listen to music in a convenient and safe

manner.

3.1 BASIC AUDIO FUNCTIONS

The basic audio functions are the same whether you are listening to music, speaking on the intercom, or having a

phone conversation.

To turn the volume up:

●Tap .

An increasingly louder tone is played on the speaker until you reach the maximum volume, as indicated by

the maximum volume tone.

To turn the volume down:

●Tap .

An increasingly quieter tone is played on the speaker until you reach the minimum volume, as indicated by

the minimum volume tone.

To mute the microphone and lower the speaker volume to the minimal level:

●Simultaneously tap and .

To unmute the microphone and raise the speaker volume to the previous level:

●Tap or .

An ascending tone is played on the speaker.

3.1.1 MAKING AND RECEIVING PHONE CALLS

You can use your mobile phone to make and receive phone calls while paired to your FREECOM 1+/2+.

To make a phone call:

●To dial using your mobile phone's voice dial option, simultaneously tap and , then make your call as

per the instructions for your mobile device.

●To redial the last number called on your mobile device, press and hold down for 2 seconds.

●To dial your preset speed dial number, tap 3 times. (The speed dial number must be set in the Cardo

Mobile App or community website prior to use.)

●If you connected two mobile phones to your unit, you cannot make an additional phone call from the other

phone while a phone call is already active.

To answer a call:

●Tap .

To reject a call:

●Press for 2 seconds.

To ignore a call:

●Simultaneously tap and , or wait 30 seconds.

To end a call:

●Tap .

3.1.1.1 SWITCHING BETWEEN TWO CALLS ON TWO MOBILE PHONES

Your FREECOM 1+/2+ can toggle between two calls on two mobile phones when both mobile phones are paired

to your unit.

To toggle between two calls on two mobile phones (without disconnecting either call):

●Tap twice.

To disconnect the current call and switch to the other call:

●Tap .

3.1.2 STREAMING MUSIC

You can stream music from your paired device to your FREECOM 1+/2+.

To start music streaming from your paired device:

●Tap .

To stop music streaming:

●Press for 2 seconds.

To skip to the next track (while streaming):

●Tap .

To skip back to the previous track (while streaming):

●Tap twice.

3.1.2.1 SWITCHING MUSIC SOURCES

If two music (A2DP) audio sources are paired, FREECOM 1+/2+ uses the audio source from which you last

played music.

To switch to the other audio source:

1. Stop music (A2DP) playback from the current device (see Streaming Music on page 9).

2. Play music (A2DP) from the other device.

FREECOM 1+/2+ automatically remembers your last played device.

3.2 LISTENING TO FM RADIO

The FREECOM 1+/2+ is equipped with a built-in FM radio.

To turn on the FMradio:

●Tap twice.

When you switch on your FMradio, the station that was playing when you last switched off resumes playing.

To turn the FMradio off:

●Press for 2 seconds.

To skip to the next station:

●Tap .

To skip back to the previous station:

●Tap twice.

To scan for and select a station:

1. Simultaneously tap and .

The FMradio plays each station that it finds for several seconds.

2. When you hear a station you want to select, tap .

To store a scanned station in the active preset:

●Tap within 20 seconds of stopping the scan.

4. RIDING WITH OTHERS

4.1 BLUETOOTH INTERCOM

To connect your unit to another unit with a Bluetooth intercom, such as a Cardo Bluetooth unit or other Bluetooth-

enabled devices, you must first pair their channels. Once paired, the units automatically recognize each other

whenever they are in range:

For FREECOM 1+: Rider-To-Passenger only.

For FREECOM 2+: Line of sight up to 500 m / 1,600 ft subject to terrain.

●Pairing a channel replaces any existing paired unit on that channel with the new unit.

●If you purchased the FREECOM 1+/2+ DUO, the retail package contains two pre-paired units.

●The Intercom range with other models is limited to the distance of the unit with the shorter range.

To set up a Bluetooth intercom connection:

1. Confirm your unit is in Standby mode (LED flashes blue slowly).

2. To initiate 2-way pairing:

●On your unit, press for 5 seconds to enter pairing mode.

The LED flashes red.

Bluetooth intercom pairing needs to be initiated on the other device.

If pairing is not completed within 2 minutes, the unit automatically returns to Standby mode.

To pair a non-Cardo Bluetooth intercom unit:

1. Confirm your unit is in Standby mode (LED flashes blue slowly).

2. To initiate 2-way pairing:

●On your unit, press for 5 seconds.

The LED flashes red.

●Tap to activate the Cardo gateway.

The LED flashes red and blue.

Mobile phone pairing needs to be initiated on the other device.

If pairing is not completed within 2 minutes, the unit automatically returns to Standby mode.

To cancel the pairing process:

On your unit, press for 2 seconds.

The LED stops flashing.

4.2 STARTING/ENDING INTERCOM CALLS

You can initiate Bluetooth intercom calls with other riders, including non-Cardo riders.

To start or end communication with a rider or passenger:

●: Tap .

4.2.1 RECEIVING BLUETOOTH INTERCOM CALLS

If another paired unit calls you via Bluetooth intercom, the call begins instantly.

4.3 RESETTING BLUETOOTH INTERCOM PAIRING

Resetting Bluetooth intercom pairing also resets all Bluetooth device pairing.

To reset Bluetooth intercom pairing:

1. Press for 5 seconds. The LED flashes red.

2. Press and for 2 seconds.

The LED flashes purple 5 times slowly, confirming that pairing has been reset.

4.4 SHARING MUSIC AND RADIO

You can share music and FMradio with a passenger or other rider. Music sharing is more suitable for

rider/passenger combinations, whereas FM radio is also intended for rider/rider combinations.

●Music and radio can be shared with only one passenger/rider.

●Bluetooth intercom calls are disabled when sharing music.

●FM radio sharing opens a Bluetooth intercom call automatically.

●If you paired your unit to two mobile phones, music will be shared from the mobile phone through which

you last played music.

●When sharing FM radio, either passenger/rider can change station while the Bluetooth intercom call

remains open.

●When you stop sharing FM radio, the Bluetooth intercom call remains open and the FM radio continues to

play independently on each passenger/rider's unit.

●When you stop sharing music, the music continues to play on your unit only.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Cardo Systems Accessori per motociclette

Cardo Systems

Cardo Systems PACKTALK CUSTOM Manuale utente

Cardo Systems

Cardo Systems FREECOM 4+ Manuale utente

Cardo Systems

Cardo Systems FREECOM X Manuale utente

Cardo Systems

Cardo Systems SPIRIT Manuale utente

Cardo Systems

Cardo Systems SMARTH Manuale utente

Cardo Systems

Cardo Systems scala rider Q3 Manuale utente

Cardo Systems

Cardo Systems PACKTALK EDGE Manuale utente

Cardo Systems

Cardo Systems scalarider q1 Manuale utente

Cardo Systems

Cardo Systems FREECOM 1 Manuale utente

Cardo Systems

Cardo Systems scalarider q1 Manuale utente

Cardo Systems

Cardo Systems Freecom 4x Manuale utente

Cardo Systems

Cardo Systems FREECOM 4+ Manuale utente

Cardo Systems

Cardo Systems scala rider Q1 TEAMSET Manuale utente

Cardo Systems

Cardo Systems FREECOM 2x Manuale utente

Cardo Systems

Cardo Systems PACKTALK EDGE Manuale utente

Cardo Systems

Cardo Systems Packtalk NEO Manuale utente

Cardo Systems

Cardo Systems PACKTALK EDGE Manuale utente

Cardo Systems

Cardo Systems scalarider Q3 Manuale utente

Cardo Systems

Cardo Systems scala rider Q3 Manuale utente

Cardo Systems

Cardo Systems PACKTALK SLIM Manuale utente

Cardo Systems

Cardo Systems ScalaRider Manuale utente

Cardo Systems

Cardo Systems PACKTALK SLIM Manuale utente

Cardo Systems

Cardo Systems PACKTALK EDGE Manuale utente

Cardo Systems

Cardo Systems Freecom 4x Manuale utente

Manuali Accessori per motociclette popolari di altre marche

SRC

SRC B-TRK502-01-01-SL Manuale utente

3M Speedglas 9100 MP Manuale utente

hepco & becker

hepco & becker 6307520 00 01 Manuale utente

HOMCOM

HOMCOM AA0-077 Manuale utente

hepco & becker

hepco & becker 6307558 00 01 Manuale utente

Wunderkind Custom

Wunderkind Custom 106503-F15 Guida utente

Dräger

Dräger HPS 3500 Manuale utente

M-WAVE

M-WAVE SKI Manuale utente

Kuryakyn

Kuryakyn 6212 Manuale utente

hepco & becker

hepco & becker 6507504 00 01 Manuale utente

Tool it

Tool it PROMAX LCD 9.13G Manuale utente

Custom Dynamics

Custom Dynamics TruWrapz Manuale utente

Roof

Roof RO200 CARBON Manuale utente

Kabuto

Kabuto Japan IBUKI Manuale utente

PUIG

PUIG 5051 Manuale utente

rizoma

rizoma ZTH050 Manuale utente

Joubert

Joubert 10001711 Manuale utente

Sperian

Sperian Optrel p420 Manuale utente
