Casio DL-270B Manuale utente
R
(without price)
NOV. 1995
DL-270B(ZX-510IY)
DR-220TA(ZX-510AY)
DR-220TADL-270B
INDEX
CONTENTS
1. SPECIFICATIONS ......................................................................................................... 1
2. BLOCK DIAGRAM ........................................................................................................ 2
3. CPU (MN158418YCY) PIN FUNCTION......................................................................... 3
4. TROUBLESHOOTING................................................................................................... 4
5. DIAGNOSTIC................................................................................................................. 5
6. SCHEMATIC DIAGRAMS ............................................................................................. 6
7. DISASSEMBLY VIEW ................................................................................................... 8
8. PARTS LIST .................................................................................................................. 9
— 1 —
1. SPECIFICATIONS
Functions: 4 basic arithmetic operations (+, -, ×, ÷), constants for ×/÷, sub-total/total/
grand total, item counting, ADD mode calculations, repeat calculations,
memory calculations, percentage calculations and various kinds of practical
calculations.
Decimal point: Full floating, and fixed (0, 1, 2, 3, 4 or 6) with round-off, round-up or cut-off.
Capacity: 12 digits
Display: Digitron tube panel
Ambient temperature range: 0°C ~ 40°C (32°F ~ 104°F)
Power supply: AC 100/120/220 or 240 V (±10 V), 50/60 Hz ••••• Fixed
*Rated current and voltage are printed on the calculator.
Dimensions: 83 mmH ×214 mmW ×376 mmD
(3 1/4"H ×8 3/8"W ×14 3/4"D) including rollholder.
Weight: 1.7 kg (3.8 lbs)
— 2 —
Display tube
SC131MH
CPU
MN158418YCY
Power supply
circuit
Slide switch
Keyboard
Printer
M-80
VF1, VF2
Ribbon shift signal
Character selective signal
Timing pulse
Digital signal
D1 ~ D13
Motor control signal
Motor power supply
Detector power supply
VDD
GND
VSS
Segment signal
S1 ~ S7, SAP, SDP
SO1 ~ SO7
SI1 ~ SI3, SI5
KO1 ~ KO8
KI1 ~ KI6
2. BLOCK DIAGRAM
— 3 —
3. CPU (MN158418YCY) PIN FUNCTION
Pin No.
1~7, 64
8~12
13
14
15
16
17
18~30
31, 32
33~39
40
41~43
44~56
57
58
59, 60
61
62
63
I/O
Out
In
In
In
In
Out
Out
Out
Out
Out
Out
In
Out
—
—
I/O
—
—
In
Signal
P00~P13
P20~P22, P32, P33
IRQ
DEBIN
IRQCNT
P40
P41
P42, P43, P50~P53
P70~P73, P80~P82
P83, P90
P91~P93
PA0~PA3
P60
P61~P63
PB0~PB3
PC1~PC3
PD0~PD3
PE0
VPP
VDD
OCS1, OCS2
VSS
SYNC
RST
Function
Common signal for keyboard
Key signal from keyboard
Timing pulse signal from printer
Not used
VDD (33 V, 30 mA)
Motor control signal
Ribbon shift signal for printer
Character selective signal for printer
Character selective signal for printer,
Segment signal for display
Segment signal for display,
Common signal for slide switch
VDD (33 V, 30 mA)
Signal from slide switch
Digit signal for display
GND terminal
VDD terminal
Clock signal for CPU
VSS terminal
Not used
Signal from slide switch, Reset signal
— 4 —
4. TROUBLESHOOTING
Trouble
1) Does not work
at all.
2) No display.
3) No print.
4) Poor display.
5) Poor printing
• Motor does
not stop.
• Missing of
digits
Cause
• Defective power transformer
• Defective LSI
• No voltage at VF1, VF2
• No digit signal or no segment
signal
• Defective display tube
• Poor voltage VM
• Defective motor
• Defective LSI
• Short or open circuits
between digit signals and
segment signals.
• Defective display tube
• Timing signal is bad.
• Defective printer magnet
Checkpoint
Secondary voltage of
transformer
Waveforms of each pin
VF1, VF2
Signal D1 ~
S1 ~
Between LSI and
display tube
Note
VDD, VSS, VM, VF1, and
VF2 are OK?
Check the pulse signals
from LSI.
If VF1, VF2, Digit and
Segment signals are OK.
VM=11V (while printing)
Check detector of printer
block and timing signal.
•Refer to the printer service manual published separately.
— 5 —
DISPLAY
100.
0.
-888.888888888
-888.88888888
0.
1234.
1.61307189542
M 1.613071
M 1.6131
M 1.614
M 1.54
M 3.1
M 5.
1.613
1.613
K 0.01
-0.02
-0.02
-0.02
-0.03
-0.03
0.
MODE SWITCHES
ON F 6
ON F 6
ON F 6
ON F 6
ON F 6
PRINT F 6
PRINT F 6
PRINT CUT 6
PRINT CUT 4
PRINT UP 3
PRINT UP 2
PRINT 5/4 1
PRINT 5/4 0
PRINT 5/4 ADDX
PRINT 5/4 ADDX
PRINT 5/4 ADDX
PRINT 5/4 ADD+
PRINT 5/4 ADD+
ITEM+ 5/4 ADD+
ITEM+/– 5/4 ADD+
ITEM+/– 5/4 ADD+
ITEM+/– 5/4 ADD+
ITEM+/– 5/4 ADD+
OPERATION
1 00 TM
C
8 – ÷9 % ◊/#
CA
1 2 3 4 ÷
7 6 5 +
M+
M+
M–
÷5 MU/MD
+
+
M◊
M❊
CA 1 ÷ ÷ 1 =
X 1 – 1 –
◊/#
◊/#
– ❊
G
FEED
AC
1• K÷
0 • 01 ÷
1 • =
0 • 01
0 • 01 X
[- 1 • =]
[- 0 • 01+]
[0 • 01-]
[0 • 01 -]
[- 0 • 02◊]
002
[- 0 • 02◊]
[0 • 01 -]
001
[- 0 • 03 ❊]
001
[- 0 • 03G❊]
Paper feeding
• • 0 • •
NOTE
The character with
"[ ]" will be printed
by red ink.
Press the button 2
or 3 seconds
continuously.
STEP
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
23
24
PRINT
[-]
[88.8888888888]
1.234 • ÷
765 • =
1.61307189542+
1.613071 M+
1.6131 M+
[1.614 M+]
1.614 ÷
5 • %M
0.08 -%
1.54
1.5 +
2 • +
1.613 M◊
1.613 M*
• • 0 • •
1 • ÷
▲
5. DIAGNOSTIC
— 6 —
6. SCHEMATIC DIAGRAMS
6-1. Main Board
— 7 —
6-2. Key Matrix6-2. Key Matrix
— 8 —
1
23
4
5
6
7
8
9
10
11
15
12
14
13
16
17
18
18
21 19
20
22
23
24
25
26
Power Cord
Black
Projection side
Projection side
Marking side
Brown
Blue
Brown
Blue
Transformer
Black
Yellow
Blue
Black
Black
White
Black
Red
Connection
Voltage
100V
120V
220V
240V
7. DISASSEMBLY VIEW
