Casio Fx-7400G PLUS Documento tecnico

Appendix

Appendix A Resetting the Calculator

Appendix B Power Supply

Appendix C Error Message Table

Appendix D Input Ranges

Appendix E Specifications

194

Appendix

Appendix A Resetting the Calculator

Warning!

The procedure described here clears all memory contents. Never perform this op-

eration unless you want to totally clear the memory of the calculator. If you need

the data currently stored in memory, be sure to write it down somewhere before

performing the RESET operation.

uTo reset the calculator

1. Press mto display the main menu.

2. Highlight the MEM icon and press w, or press j.

3. Use cto move the highlighting down to “Reset” and then press w.

4. Press 1(YES) to reset the calculator or 4(NO) to abort the operation without

resetting anything.

•If the display appears to dark or dim after you reset the calculator, adjust contrast.

1234

195

Appendix

Resetting the calculator initializes it to the following settings.

Item Initial Setting

Icon RUN

Angle Unit Rad

Exponent Display Range Norm 1

Fraction Reduction Automatic

Mixed Fraction Display

Graph Type Rectangular coordinate (Y=)

Statistical Graph Automatic

Va r i able Memory Clear

Answer Memory (Ans) Clear

Graphic Display/Text Display Clear

View Window Clear (initialized)

View Window Memory Clear

Graph Function Clear

Enlargement/Reduction Factor Clear (initialized)

Table & Graph Data Clear

List Data Clear

Statistical Calculation/Graph Memory Clear

Program Clear

Input Buffer/AC Replay Clear

•Performing the RESET operation while an internal calculation is being per-

formed will cause all data in memory to be deleted. Make sure that no calcula-

tion be being performed before starting a RESET operation.

•If the calculator stops operating correctly for some reason, use a thin, pointed

object to press the P button on the back of the calculator. This should make the

RESET confirmation screen appear on the display. Perform the procedure to

complete the RESET operation.

P button

196

Appendix

Appendix B Power Supply

This unit is powered by two AAA-size (LR03 (AM4) or R03 (UM-4)) batteries. In addi-

tion, it uses a single CR2032 lithium battery as a back up power supply for the memory.

If the following message appears on the display, immediately stop using the calcula-

tor and replace batteries.

If you try to continue using the calculator, it will automatically switch power off, in

order to protect memory contents. You will not be able to switch power back on until

you replace batteries.

Be sure to replace the main batteries at least once every two years, no matter how

much you use the calculator during that time.

Warning!

If you remove both the main power supply and the memory back up batteries at the

same time, all memory contents will be erased. If you do remove both batteries,

correctly reload them and then perform the reset operation.

The batteries that come with this unit discharge slightly during shipment and

storage. Because of this, they may require replacement sooner than the normal

expected battery life.

kReplacing Batteries

Precautions:

Incorrectly using batteries can cause them to burst or leak, possibly damaging the

interior of the unit. Note the following precautions:

•Be sure that the positive (+) and negative (–) poles of each battery are facing in

the proper directions.

•Never mix batteries of different types.

•Never mix old batteries and new ones.

•Never leave dead batteries in the battery

compartment.

•Remove the batteries if you do not plan to

use the unit for long periods.

•Never try to recharge the batteries sup-

plied with the unit.

•Do not expose batteries to direct heat, let

them become shorted, or try to take them

apart.

197

Appendix

(Should a battery leak, clean out the battery compartment of the unit immedi-

ately, taking care to avoid letting the battery fluid come into direct contact with

your skin.)

Keep batteries out of the reach of small children. If swallowed, consult with a

physician immediately.

uTo replace the main power supply batteries

*Never remove the main power supply and the memory back up batteries from

the unit at the same time.

*Besure to switch the unit off before replacing batteries. Replacing batteries

with power on will cause data in memory to be deleted.

*Never replace the back cover or switch the calculator on while the main power

supply batteries are removed from the calculator or not loaded correctly. Doing

so can cause memory data to be deleted and malfunction of the calculator. If

mishandling of batteries causes such problems, correctly load batteries and

then perform the RESET operation to resume normal operation.

*Be sure to replace all two batteries with new ones.

1. Press !O to turn the calculator off.

2. Making sure that you do not accidently press the okey, attach the case to the

calculator and then turn the calculator over.

3. Remove the back cover from the unit by pull-

ing with your finger at the point marked ✩.

4. Remove the two old batteries.

5. Load a new set of two batteries, making sure

that their positive (+) and negative (–) ends

are facing in the proper directions.

6. Replace the back cover and press oto turn

power on. The memory back-up battery pro-

vides power to the memory while the main

batteries are removed, so memory data is not

lost.

198

Appendix

•Power will not switch on if you press owhile the back cover is open.

•Do not leave the unit without main power supply batteries loaded for long periods.

Doing so can cause deletion of data stored in memory.

•If the figures on the display appear too light and hard to see after you turn on

power, adjust the contrast.

uTo replace the memory back up battery

*Before replacing the memory back up battery, switch on the unit and check to see

if the “Low battery!” message appears on the display. If it does, replace the main

power supply batteries before replacing the back up power supply battery.

*Never remove the main power supply and the memory back up batteries from the

unit at the same time.

*Besure to switch the unit off before replacing battery. Replacing battery with

power on will cause data in memory to be deleted.

*Be sure to replace the back up power supply battery at least once 2 years, re-

gardless of how much you use the unit during that time. Failure to do so can

cause data in memory to be deleted.

1. Press !O to turn the calculator off

2. Making sure that you do not accidently press the okey, attach the case to the

calculator and then turn the calculator over.

3. Remove the back cover from the unit by pull-

ing with your finger at the point marked ✩.

4. Remove screw ion the back of the calcula-

tor, and remove the back up battery holder.

5. Remove the old battery.

P. 1 1

199

Appendix

6. Wipe off the surfaces of a new battery with a

soft, dry cloth. Load it into the calculator so

that its positive (+) side is facing up.

7. Pressing down on the battery with the battery

holder, replace the screw that secures the

holder in place.

8. Replace the back cover and press oto turn power on. The main batteries

provide power to the memory while the back-up battery is removed, so memory

data is not lost.

kAbout the Auto Power Off Function

The calculator switches power off automatically if you do not perform any key opera-

tion for about 6 minutes. To restore power, press o.

The calculator automatically turns off it is left for about 60 minutes with a calculation

stopped by an output command (^), which is indicated by the “–Disp–” message on

the display.

200

Appendix

Meaning

1Calculation formula contains an

error.

2Formula in a program contains

an error.

1Calculation result exceeds

calculation range.

2Calculation is outside the input

range of a function.

3Illogical operation (division by

zero, etc.)

4Poor precision in differential

calculation results.

1No corresponding Lbl nfor

Goto n.

2No program stored in program

area Prog “file name”.

3No corresponding “Next” for

“For”, no corresponding

“LpWhile” for “Do”, or no

corresponding “WhileEnd” for

“While”.

•Nesting of subroutines exceeds

10 levels.

Countermeasure

1Use dor eto display the

point where the error was

generated and correct it.

2Use dor eto display the point

where the error was generated

and then correct the program.

123

Check the input numeric value

and correct it.

When using memories, check

that the numeric values stored

in memories are correct.

4Try using a smaller value for ∆x

(xincrement/decrement).

1Correctly input a Lbl nto corres-

pond to the Goto n, or delete

the Goto nif not required.

2Store a program in program

area Prog “file name”, or delete

the Prog “file name” if not

required.

3Correctly match “Next” with

“For”, “LpWhile” with “Do”, or

“WhileEnd” with “While”.

•Ensure that Prog “file name” is

not used to return from

subroutines to main routine. If

used, delete any unnecessary

Prog “file name”.

• Trace the subroutine jump

destinations and ensure that no

jumps are made back to the

original program area. Ensure

that returns are made correctly.

Appendix C Error Message Table

Message

Syn ERROR

Ma ERROR

Go ERROR

Ne ERROR

201

Appendix

Meaning

•Execution of calculations that

exceed the capacity of the stack

for numeric values or stack for

commands.

1Not enough memory to hold

function input in the Graph

Mode for graph drawing.

2Not enough memory to hold

function input in the TABLE

Mode.

3Not enough memory to store

data in list function.

•Incorrect argument specification

for a command that requires an

argument.

•Illegal dimension used during

list calculations.

•Problem with cable connection

or parameter setting during

program data communications.

•Problem with cable connection

or parameter setting during

data communications.

•Problem with cable connection

or parameter setting during

data communications.

•Memory of receiving unit

became full during program

data communications.

Countermeasure

•Simplify the formulas to keep

stacks within 10 levels for the

numeric values and 26 levels

for the commands.

•Divide the formula into two or

more parts.

123

•Keep the number of variables

you use for the operation within

the number of variables

currently available.

•Simplify the data you are trying

to store to keep it within the

available memory capacity.

•Delete no longer needed data

to make room for the new data.

Correct the argument.

•Fix

n, Sci n: n= integer from 0

through 9.

•Lbl n, Goto n: n= integer from

0 through 9.

•Check list dimension.

•Check cable connection.

•Delete some data stored in the

receiving unit and try again.

Message

Stk ERROR

Mem ERROR

Arg ERROR

Dim ERROR

Com ERROR

Transmit

ERROR!

Receive ERROR!

Memory Full!

202

Appendix

Function

sinx

cosx

tanx

sin–1x

cos–1x

tan–1x

logx

Inx

10x

1/x

nPr

nCr

Pol (x, y)

Rec

(r,

)

Internal

digits

15 digits

Precision

As a rule,

precision is

±1 at the

10th digit.*

Notes

However, for tanx:

|x|

90(2n+1):DEG

|x|

π/2(2n+1):RAD

|x|

100(2n+1):GRA

Input ranges

(DEG) |x| < 9 ×109°

(RAD) |x| < 5 ×107πrad

(GRA) |x| < 1 ×1010grad

|x| <1

|x| < 1 ×10100

1 ×10–99 <x< 1 ×10100

–1 ×10100 < x< 100

–1 ×10100

< x<230.2585092

0 <x< 1 ×10100

|x| <1 ×1050

|x| < 1 ×10100 , x

|x| < 1 ×10100

0 <x<69

(xis an integer)

Result < 1 ×10100

n, r(nand rare integers)

0 <r<n,

n< 1 ×1010

< 1 ×10100

x2+ y2

|r| < 1 ×10100

(DEG) |

| < 9 ×109°

(RAD) |

| < 5 ×107πrad

(GRA) |

| < 1 ×1010grad

Appendix D Input Ranges

However, for tan

90(2n+1):DEG

π/2(2n+1):RAD

100(2n+1):GRA

Altri manuali per fx-7400G PLUS

Indice

Altri manuali Casio Calcolatrice

Casio

Casio FX-61F SCIENTIFIC CALCULATOR Manuale utente

Casio

Casio CFX-9850G PLUS Manuale utente

Casio

Casio fx-7000GA Manuale utente

Casio

Casio V.P.A.M. fx-100s Manuale utente

Casio

Casio FX-8000G Manuale utente

Casio

Casio fx-95SG PLUS Manuale utente

Casio

Casio ClassWiz fx-991EX Manuale utente

Casio

Casio fx-1000F Manuale utente

Casio

Casio FX-9700GE Manuale utente

Casio

Casio CFX-9970G Manuale per l'uso e la cura

Casio

Casio CFX-9850GB PLUS Manuale utente

Casio

Casio MJ-12Sb Manuale utente

Casio

Casio FX-9860GII - SOFTWARE VERSION 2-00 Manuale utente

Casio

Casio FX-300ES PLUS Manuale utente

Casio

Casio FX-911Z Manuale utente

Casio

Casio FX-9750GII - SOFTWARE VERSION 2-00 Manuale utente

Casio

Casio fx-7400G PLUS Manuale utente

Casio

Casio fx-570ES PLUS Manuale utente

Casio

Casio FX-10 Istruzioni per il montaggio

Casio

Casio GX-120S Manuale utente

Casio

Casio DC-810 Manuale utente

Casio

Casio ALGEBRA FX 2.0 Plus Istruzioni utente

Casio

Casio FX260HA Guida all'installazione

Casio

Casio FX-7400GII Manuale utente

Manuali Calcolatrice popolari di altre marche

HP 35s Manuale

LEXIBOOK

LEXIBOOK EL350 Manuale utente

HP HP-97 Manuale utente

Citizen

Citizen SDC-414N Manuale utente

Canon

Canon P26-DHIII Manuale utente

Citizen

Citizen 520DPA Manuale utente

Sharp

Sharp EL-9900 Manuale utente

Sharp

Sharp WriteView EL-W506 Manuale tecnico

HP HP-67 Guida utente

Royal

Royal CBC2000 Manuale utente

Heathkit

Heathkit IC-2009 Manuale utente

Universal

Universal UNV-15907 Manuale utente

Sharp

Sharp EL-9650 Manuale utente

Sharp

Sharp EL2192RII - Printing Calculator Manuale utente

Ativa

Ativa AT-30i Manuale utente

HP StreamSmart 400 Manuale utente

HP 20b Business Consultant Manuale utente

HP 9g Manuale utente

Casio fx-7400G PLUS Documento tecnico

Manuali Calcolatrice popolari di altre marche
