E

Digital Camera

EX-Z70

User’s Guide

K817PCM1DKX

Thank you for purchasing this CASIO

product.

• Before using it, be sure to read the

precautions contained in this User’s Guide.

• Keep the User’s Guide in a safe place for

future reference.

• For the most up-to-date information about

this product, visit the official EXILIM

Website at http://www.exilim.com/.

INTRODUCTION
2
Unpacking
Check to make sure that all of the items shown below are included with your camera. If something is missing, contact your
dealer as soon as possible.
INTRODUCTION
Rechargeable Lithium
Ion Battery (NP-20)
CD-ROM USB Cable Basic Reference
Camera Strap
AV Cable
Lithium Ion Battery
Charger
(BC-11L)
AC Power Cord
*
*The shape of the AC power
cord plug varies according to
country or geographic area.

INTRODUCTION
3
Contents
2INTRODUCTION
Unpacking .................................................................... 2
Features ....................................................................... 9
Precautions ................................................................ 12
17 QUICK START GUIDE
First, charge the battery! ............................................ 17
To configure display language and clock settings ..... 18
To record an image .................................................... 19
To view a recorded image .......................................... 20
To delete an image ..................................................... 20
21 GETTING READY
About This Manual ..................................................... 21
General Guide ............................................................ 22
Camera 22
Lithium Ion Battery Charger 24
Monitor Screen Contents ........................................... 25
REC Mode 25
PLAY Mode 27
Changing the Contents of the Monitor Screen 29
Attaching the Strap .................................................... 30
Power Requirements .................................................. 31
To charge the battery 31
To load the battery 34
Low Battery Indicator 36
To replace the battery 37
Power Supply Precautions 38
Turning the Camera On and Off 41
Configuring Power Saving Settings 42
Using the On-screen Menus ...................................... 44
Configuring Display Language and Clock Settings ... 46
To configure display language and clock settings 47

INTRODUCTION
4
50 BASIC IMAGE RECORDING
Recording an Image ................................................... 50
Aiming the Camera 50
Recording an Image 51
Using the easy Mode 55
Recording Precautions 57
Using Zoom ................................................................ 59
Optical Zoom 59
Digital Zoom 61
Using the Flash .......................................................... 63
Flash Unit Status 65
Changing the Flash Intensity Setting 66
Using Flash Assist 66
Using the Self-timer ................................................... 68
Specifying Image Size ............................................... 71
Specifying Image Quality ........................................... 72
74 OTHER RECORDING FUNCTIONS
Selecting the Focus Mode ......................................... 74
Using Auto Focus 75
Using the Macro Mode 78
Using Pan Focus 79
Using the Infinity Mode 79
Using Manual Focus 80
Using Focus Lock 81
Exposure Compensation (EV Shift) ........................... 82
Adjusting White Balance ............................................ 84
Configuring the White Balance Setting Manually 85
Using Continuous Shutter .......................................... 87
Normal-speed continuous shutter 88
High-speed continuous shutter 88
Flash continuous shutter 88
Using the BEST SHOT Mode .................................... 89
Displaying Sample Scenes Individually 91
Creating Your Own BEST SHOT Setup 92
To delete a BEST SHOT user setup 94
Reducing the Effects of
Hand or Subject Movement ....................................... 94
Shooting with High Sensitivity ................................... 96
Recording Images of Business Cards
and Documents (Business Shot) ............................... 97
Before recording with Business Shot 98
To use Business Shot 98
Restoring an Old Photograph .................................... 99
Before trying to restore an old photograph 99
To restore an old photograph 100
Recording a Movie ................................................... 102
Specifying Movie Image Quality 103
Recording a Movie 104
Recording Audio ....................................................... 106
Adding Audio to a Snapshot 106
Recording Your Voice 107
Using the Histogram ................................................. 109

INTRODUCTION
5
REC Mode Camera Settings.................................... 112
Assigning Functions to the [왗] and [왘] Keys 112
Turning the On-screen Grid On and Off 113
Turning Image Review On and Off 114
Using Icon Help 114
Specifying Power On Default Settings 115
Specifying ISO Sensitivity 117
Selecting the Metering Mode 118
Using the Filter Function 120
Specifying Outline Sharpness 120
Specifying Color Saturation 121
Specifying Contrast 121
Date Stamping Snapshots 122
Resetting the Camera 123
124 PLAYBACK
Basic Playback Operation ........................................ 124
Playing an Audio Snapshot 125
Zooming the Display Image ..................................... 126
Resizing an Image ................................................... 127
Cropping an Image................................................... 128
Keystone Correction ................................................. 130
Using Color Restoration to
Correct the Color of an Old Photograph .................. 131
Playing and Editing a Movie ..................................... 133
Playing a Movie 133
Editing a Movie 134
Capturing a Still Image from a Movie
(MOTION PRINT) 138
Displaying the 9-image View .................................... 139
Displaying the Calendar Screen .............................. 140
Playing a Slideshow ................................................. 141
Rotating the Display Image ...................................... 144
Adding Audio to a Snapshot .................................... 145
To re-record audio 146
Playing Back a Voice Recording File ....................... 147
Displaying Camera Images on a TV Screen ........... 148
Selecting the Video Output System 150
152 DELETING FILES
Deleting a Single File ............................................... 152
Deleting All Files ...................................................... 153
154 FILE MANAGEMENT
Folders ...................................................................... 154
Memory Folders and Files 154

INTRODUCTION
6
Protecting Files ........................................................ 155
To protect a single file 155
To protect all files in memory 156
Using the FAVORITE Folder .................................... 156
To copy a file to the FAVORITE folder 156
To display a file in the FAVORITE folder 158
To delete a file from the FAVORITE folder 159
To delete all files from the FAVORITE folder 159
160 OTHER SETTINGS
Configuring Sound Settings ..................................... 160
To configure sound settings 160
To set the confirmation tone volume level 160
To set the audio volume level for movie and audio
snapshot playback 161
Specifying an Image for the Startup Screen ........... 161
Specifying the File Name
Serial Number Generation Method .......................... 162
Setting the Clock ...................................................... 163
To select your Home Time zone 163
To set the current time and date 164
Changing the Date Format 164
Using World Time ..................................................... 165
To display the World Time screen 165
To configure World Time settings 165
Editing the Date and Time of an Image ................... 166
Changing the Display Language .............................. 167
Changing the USB Port Protocol ............................. 168
Configuring [ ] (REC) and [ ] (PLAY)
Power On/Off Functions ........................................... 169
Formatting Built-in Memory ...................................... 170
171 USING A MEMORY CARD
Using a Memory Card .............................................. 172
To insert a memory card into the camera 172
To replace the memory card 173
Formatting a Memory Card 174
Copying Files ............................................................ 175
To copy all the files in built-in memory
to a memory card 176
To copy a specific file
from a memory card to built-in memory 177
178 PRINTING IMAGES
DPOF ........................................................................ 179
To configure print settings for a single image 180
To configure print settings for all images 181
Using PictBridge or USB DIRECT-PRINT ............... 183
Date Printing 187
PRINT Image Matching III ........................................... 188
Exif Print ................................................................... 188

INTRODUCTION
7
189 VIEWING IMAGES ON A COMPUTER
Using the Camera with a Windows Computer ......... 189
Using the Camera with a Macintosh Computer ....... 196
Using a Memory Card to
Transfer Images to a Computer ............................... 200
Memory Data ............................................................ 201
DCF Protocol 201
Memory Folder Structure 202
Image Files Supported by the Camera 203
205 USING THE CAMERA WITH A COMPUTER
Using the Camera with a Windows Computer ......... 205
Selecting the Software You Need 205
Computer System Requirements 207
Managing Images on a PC 208
Retouching, Reorienting, and Printing a Snapshot 211
Playing a Movie 213
Viewing User Documentation (PDF Files) 214
User Registration 214
Exiting the Menu Application 214
Using the Camera with a Macintosh Computer ....... 215
Selecting the Software You Need 215
Computer System Requirements 216
Managing Images on a Macintosh 217
Playing a Movie 218
Viewing User Documentation (PDF Files) 218
To register as a camera user 219
220 APPENDIX
Menu Reference ....................................................... 220
Indicator Lamp Reference........................................ 223
Troubleshooting Guide ............................................. 226
If you have problems installing the USB driver... 231
Display Messages 232
CA-32 USB Cradle/AC Adaptor (Option) ................. 234
General Guide 234
Using the USB Cradle to Charge the Battery 235
Using the Photo Stand Feature 238
Using the USB Cradle to Display Images on
a TV Screen 239
Using the USB Cradle to Print Images 240
Using the USB Cradle to Connect to a Computer 241
USB Cradle Indicator Lamp Reference 246
Specifications ........................................................... 247

INTRODUCTION
8
 IMPORTANT!
•The contents of this manual are subject to change
without notice.
•CASIO COMPUTER CO., LTD. assumes no
responsibility for any damage or loss resulting from
the use of this manual.
•CASIO COMPUTER CO., LTD. assumes no
responsibility for any loss or claims by third parties
which may arise due to the use or malfunction of the
EX-Z70.
•CASIO COMPUTER CO., LTD. shall not be held
liable for any damages or losses suffered by you or
any third party due to the use of Photo Loader and/or
Photohands.
•CASIO COMPUTER CO., LTD. assumes no
responsibility for any damage or loss caused by
deletion of data as a result of malfunction, repairs, or
battery replacement. Be sure to back up all important
data on other media to protect against its loss.
•Note that the example screens and product
illustrations shown in this User’s Guide may differ
somewhat by the screens and configuration of the
actual camera.
• The SD logo is a registered trademark.
• Windows, Internet Explorer, Windows Media, and
DirectX are registered trademarks of Microsoft
Corporation.
• Macintosh and QuickTime are trademarks of Apple
Computer, Inc.
•
MultiMediaCard is a trademark of Infineon
Technologies AG of Germany, and licensed to the
MultiMediaCard Association (MMCA).
• Adobe and Reader are either registered trademarks
or trademarks of Adobe Systems Incorporated in the
United States and/or other countries.
• Other company, product and service names used
herein may also be trademarks or service marks of
others.
• Photo Loader and Photohands are the property of
CASIO COMPUTER CO., LTD. Except as stipulated
above, all copyrights and other related rights to these
applications revert to CASIO COMPUTER CO., LTD.

INTRODUCTION
9
Features
• 7.2 million effective pixels
The CCD provides 7.41 million total pixels for images of
outstanding resolution and detail.
• 2.5-inch TFT color LCD monitor screen
• 8.3MB built-in memory
Images can be recorded without using a memory card.
• REC mode or PLAY mode power up (page 41)
Press [ ] (REC) or [ ] (PLAY) to turn on the camera
and enter the mode you want to use.
• easy mode (page 55)
This feature eliminates troublesome setups.
• 12X zoom (page 59)
3X optical zoom, 4X digital zoom
• Flash Assist (page 66)
This feature compensates when flash intensity is not
strong enough, so images are better illuminated.
• Triple Self-timer (page 68)
The self-timer can be set up to repeat three times,
automatically.
■LCD Panel
The LCD panel is a product of the latest LCD
manufacturing technology that provides a pixel yield of
99.99%. This means that less than 0.01% of the total pixels
are defective (they do not turn on or always remain turned
on).
■Copyright Restrictions
Except for the purposes of your own personal enjoyment,
unauthorized copying of snapshot files, movie files, and
audio files violates copyright laws and international
contracts.
Distribution to third parties of such files over the Internet
without permission of the copyright holder, whether for
profit or for free, violates copyright laws and international
contracts.

INTRODUCTION

10

• Auto Macro (pages 76, 78)

Auto Macro automatically switches to the macro mode

when the distance between the camera and subject it

shorter than the Auto Focus range.

• Quick Shutter (page 76)

When you press the shutter button all the way down

without pausing, the camera immediately records the

image without waiting for Auto Focus to be performed.

This helps to avoid missing a special moment while you

wait for the camera to Auto Focus.

• Auto Focus Area Selection (page 77)

When “Multi”is selected for the Auto Focus area, the

camera takes simultaneous meter readings at nine

different points and automatically selects the best one.

• Three continuous shutter modes (page 87)

In addition to normal-speed continuous shutter, you can

also select high-speed continuous shutter or flash

continuous shutter.

• BEST SHOT (page 89)

Simply select one of a collection of built-in sample scenes

and the camera sets up for the scene you selected. It’s

the simple way to set up for beautiful snapshots quickly

and easily. New BEST SHOT sample scenes include

setups for High Sensitivity and Anti Shake. A [BS] (BEST

SHOT) button provides direct access to BEST SHOT

sample scenes.

• Business Shot (page 97)

Business Shot automatically corrects rectangular shapes

when recording the image of a business card, document,

whiteboard, or similar subjects from an angle.

• Restoring an Old Photograph (page 99)

You can use the procedure in this section to restore an

old, faded photograph with the color provided by modern

digital camera technology.

• Movie recording with audio (page 102)

VGA size, 30 fps, Motion JPEG format

• Audio Snapshot mode (page 106)

Use this mode to record snapshots that also include

audio.

• Voice Recording (page 107)

Quick and easy recording of voice input.

• Real-time RGB histogram (page 109)

An on-screen histogram lets you adjust exposure as you

view the effect on overall image brightness, which makes

shooting under difficult lighting conditions easier than

ever before.

• Keystone Correction (page 130)

A simple operation corrects for keystoning, which occurs

when you record the image of a blackboard or poster from

an angle.
