Casio QV-R40 Manuale di servizio
OTHER SETTINGS
117
OTHER SETTINGS
Specifying the File Name Serial Number
Generation Method
Use the following procedure to specify the method for
generating the serial number used for file names (page
104).
1.
In the REC mode or the PLAY mode, press
[MENU].
2.
Select the “Set Up”tab, select “File No.”, and
then press [].
3.
Use [] and [] to change the setting, and
then press [SET].
Select this setting:
Continue
Reset
To do this for a newly saved file:
Store the last file number used and
increment it, regardless of whether
files are deleted or whether the
memory card is replaced with a new
one
Find the highest file number in the
current folder and increment it
OTHER SETTINGS
118
Specifying an Image for the Startup Screen
You can specify an image you recorded as the startup
screen image, which causes it to appear on the monitor
screen for about two seconds whenever you press the
power button or [ ] (REC) to turn on the camera. The
startup screen image does not appear if you press [ ]
(PLAY) to turn on the camera.
1.
In the REC mode or the PLAY mode, press
[MENU].
2.
Select the “Set Up”tab, select “Startup”, and
then press [].
3.
Use [] and [] to display the image you want
to use as the startup image.
•You can specify a snapshot image or a movie image
that is two seconds (200KB) or less in length.
4.
Use [] and [] to change the setting, and
then press [SET].
Select this setting:
On
Off
To do this:
Use the currently displayed image
as the startup screen image
Disable the startup screen
Turning the Key Tone On and Off
Use the following procedure to turn the tone that sounds
when you press a key on and off.
1.
In the REC mode or the PLAY mode, press
[MENU].
2.
Select the “Set Up”tab, select “Beep”, and
then press [].
3.
Use [] and [] to change the setting, and
then press [SET].
Select this setting:
On
Off
To do this:
Turn on the key tone
Turn off the key tone
OTHER SETTINGS
119
IMPORTANT!
•The snapshot image or movie that you select as the
startup image is stored in a special memory location
called “startup image memory”. Only one image can
be stored in startup image memory at one time.
Selecting a new startup image overwrites anything
that is already stored in startup image memory.
Because of this, if you want to return to a previous
startup image, you need to have a separate copy of
that image in the camera’s standard image memory.
Note that you cannot delete an image from startup
image memory. You can only replace it with another
image.
Configuring Power Down Image Settings
With the Power Down Image feature, you can configure the
camera so a specific image stored in camera image
memory appears whenever you turn off power. You can
specify a snapshot or a movie as the power down image.
■To configure power down image settings
1.
Use the USB cable to connect the camera to
your computer (page 135).
2.
Move the image data that you want to use for
the power down image to the top (root)
directory of the camera’s built-in Flash
memory.
•The file name extension will not be displayed if your
computer is configured to hide file name extensions.
Example: CIMG0001
•If your power down image is stored on a memory
card, be sure to copy the image to built-in memory
before removing the memory card from the camera.
OTHER SETTINGS
120
IMPORTANT!
•Only a snapshot (JPEG) or movie (AVI) file can be
used as the power down image.
•Note that the Power Down Image feature works only
with images recorded with this camera. The Power
Down Image feature may not operate properly when
another type of image is specified as the power down
image.
•Formatting the camera’s Flash memory deletes the
power down image.
•When both a still image and a movie are present for
the power down image, only the movie is used.
•Note that a power down image display operation
cannot be interrupted once it starts. Because of this,
you should select a relatively short movie when using
a movie file as the power down image.
3.
Change the name of the file to one of the
following.
Snapshot Image: ENDING.JPG
Movie Image: ENDING.AVI
•Input the following file name only (without file name
extension) if your computer is configured to hide file
name extensions.
File Name: ENDING
•Your camera is now configured to display a power
down image. The power down image will appear any
time you press the power button to turn off the
camera. The power down image appears regardless
of whether or not your camera has a memory card
loaded in it.
OTHER SETTINGS
121
Using the Alarm
You can configure up to three alarms that cause the
camera to beep and display a specified image at the time
you specify.
To set an alarm
1.
In the PLAY mode, press [MENU].
2.
Select the “PLAY”tab, select “Alarm”, and
then press [].
3.
Use [] and [] to select the alarm whose
setting you want to configure, and then press
[].
4.
Use [] and [] to select the setting you want
to change, and then use [] and [] to
change the selected setting.
•You can set an alarm time and configure the alarm to
sound either once or at the same time everyday. You
can also turn the alarm on or off.
■To disable the Power Down Image feature
1.
Use the USB cable to connect the camera to
your computer.
2.
Change the name of the current power down
image from ENDING.JPG or ENDING.AVI to
something else, or delete the current power
down image from Flash memory.
OTHER SETTINGS
122
5.
Press [DISP].
•You could press [SET] in place of [DISP] if you want
to configure the alarm without an image.
6.
Use [] and [] to select the scene you want
to appear at the alarm time, and then press
[SET].
7.
After all the settings are the way you want,
press [SET].
•You can configure up to three alarms, named “Alarm
1”, “Alarm 2”, and “Alarm 3”.
Stopping the Alarm
When an alarm time is reached while the camera is turned
off, the alarm will sound for about one minute (or until you
stop it), and then the camera will turn on. To stop the alarm
after it starts to sound, press any button.
IMPORTANT!
•Note that the alarm does not sound if the alarm time
is reached when any one of the following conditions
exists.
—While the camera is turned on
—While a USB data communication operation is in
progress
OTHER SETTINGS
123
Setting the Clock
Use the procedures in this section to select a Home Time
Zone, and to change its date and time settings.
IMPORTANT!
•Make sure you select your Home Time zone (the
zone where you are currently located) before
changing the time and date settings. Otherwise, the
time and date setting will change automatically when
you select another time zone.
To select your Home Time zone
1.
In the REC mode or the PLAY mode, press
[MENU].
2.
Select the “Set Up”tab, select “World Time”,
and then press [].
•This displays the current World Time zone.
3.
Use [] and [] to select “Home”, and then
press [].
4.
Use [] and [] to select “City”, and then
press [].
5.
Use [], [], [], and [] to select the
geographical area that contains location you
want to select as your Home Time zone, and
then press [SET].
6.
Use [] and [] to select the city you want,
and then press [SET].
7.
After selecting the city you want, press [SET]
to register its zone as your Home Time zone.
OTHER SETTINGS
124
Changing the Date Format
You can select from among three different formats for
display of the date.
1.
In the REC mode or the PLAY mode, press
[MENU].
2.
Select the “Set Up”tab, select “Date Style”,
and then press [].
3.
Use [] and [] to change the setting, and
then press [SET].
Example: October 23, 2003
Select this format:
YY/MM/DD
DD/MM/YY
MM/DD/YY
To display the date like this:
03/10/23
23/10/03
10/23/03
To set the current time and date
1.
In the REC mode or the PLAY mode, press
[MENU].
2.
Select the “Set Up”tab, select “Adjust”, and
then press [].
3.
Set the current date and the time.
Do this:
Press [] or [].
Press [] or [].
Press [DISP].
To do this:
Change the setting at the current
cursor location
Move the cursor between settings
Toggle between 12-hour and 24-
hour timekeeping
4.
When all the settings are the way you want,
press [SET] to register them and exit the
setting screen.
OTHER SETTINGS
125
Using World Time
You can use the World Time screen to view a time zone
that is different from the home time zone when you go on a
trip, etc. World Time can display the time in one of 162
cities in 32 time zones.
To display the World Time screen
1.
In the REC mode or the PLAY mode, press
[MENU].
2.
Select the “Set Up”tab, select “World Time”,
and then press [].
•This displays the current World Time zone.
3.
Use [] and [] to select “World”.
To configure World Time settings
1.
In the REC mode or the PLAY mode, press
[MENU].
2.
Select the “Set Up”tab, select “World Time”,
and then press [].
•This displays the current World Time zone.
3.
Use [] and [] to select “World”, and then
press [].
4.
Use [] and [] to select “City”, and then
press [].
5.
Use [], [], [], and
[] to select the
geographical area you
want, and then press
[SET].
4.
Press [SET] to exit the setting screen.
Select this:
Home
World
To do this:
Display the time in your home time zone
Display the time in a different time zone
OTHER SETTINGS
126
6.
Use [] and [] to
select the city you
want, and then press
[SET].
•This displays the current
time in the city you
select.
7.
When the setting is the way you want, press
[SET] to apply it and exit the setting screen.
To configure summer time (DST)
settings
1.
In the REC mode or the PLAY mode, press
[MENU].
2.
Select the “Set Up”tab, select “World Time”,
and then press [].
•This displays the current World Time Settings.
3.
Use [] and [] to select “World”, and then
press [].
•If you want to configure Home Time settings, select
“Home”instead.
4.
Use [] and [] to select “DST”, and then
press [].
5.
Use [] and [] to select the summer time
(DST) setting you want.
Select this:
On
Off
To do this:
Advance the current time setting by
one hour
Display the current time as-is
Altri manuali per QV-R40
7
Indice
Altri manuali Casio Macchina fotografica digitale
Casio
Casio Exilim EX-FR10CT Guida all'installazione
Casio
Casio EX-Z550 - EXILIM Digital Camera Manuale utente
Casio
Casio Exilim EX-P600 Guida alla risoluzione dei problemi
Casio
Casio KX-787 Guida alla risoluzione dei problemi
Casio
Casio Exilim EX-Z8 Manuale utente
Casio
Casio EX-S3 - 4 Manuale di istruzioni e di sicurezza
Casio
Casio QV-R40 Manuale utente
Casio
Casio QV-R40 Guida all'installazione
Casio
Casio EX Z55 - EXILIM Digital Camera Manuale utente
Casio
Casio Exilim EX-S200 Manuale utente
Casio
Casio EX-FR100CA Manuale utente
Casio
Casio QV-7000SX Manuale utente
Casio
Casio EX-S3 - Exilim 3MP Digital Camera Manuale di istruzioni e di sicurezza
Casio
Casio QV-R40 Guida alla risoluzione dei problemi
Casio
Casio Exilim EX-H15 Manuale utente
Casio
Casio QV-770 Manuale utente
Casio
Casio QV-3EX Manuale utente
Casio
Casio QV-700 Manuale utente
Casio
Casio QVR61 - Digital Camera - 6.0 Megapixel Manuale utente
Casio
Casio QV-R3 Manuale elenco delle parti
