Casio XJ-M145 Istruzioni di installazione e manutenzione

Projector Wired LAN

Version 1.03

Keep this manual in a safe place future reference.

• PJLink trademark and logo are trademarks applied for registration or are already registered in

Japan, the United tates of America and other countries and areas.

• Crestron is a registered trademark of Crestron Electronics, Inc. of the United tates.

• AMX is a registered trademark of AMX LLC of the United tates.

• Extron is a registered trademark of Extron Electronics of the United tates.

• Other company and product names may be registered product names or trademarks of their

respective owners.

• The contents of this manual are subject to change without notice.

• This manual is published under strict quality control standards. hould you notice any errors or

other problems, please feel free to contact us about them.

• Copying of this manual, either in part or its entirety is forbidden. You are allowed to use these

instructions for your own personal use. Any other use is forbidden without the permission of

CA IO COMPUTER CO., LTD.

• CA IO COMPUTER CO., LTD. shall not be held liable for any lost profits or claims from third

parties arising out of the use of this product or this manual.

• CA IO COMPUTER CO., LTD. shall not be held liable for any loss or lost profits due to loss of

data due to malfunction or maintenance of this product, or any other reason.

• The sample screens shown in this manual are for illustrative purposes only, and may not be

exactly the same as the screens actually produced by the product.

• Unless specifically stated otherwise, all illustrations in this manual show the XJ-H1650 projector.

The XJ-M145, XJ-M155, XJ-M245, XJ-M255, XJ-H1650, XJ-H1750, XJ-H2650, XJ- T145, and

XJ- T155 (hereinafter referred to collectively as "the Projector" or "this Projector") can be controlled

from an external device via its LAN port.

The operation of the wireless LAN control function differs depending on the Projector's firmware

version Differences are explained in detail as required in each section of this manual.

For information about how to check the firmware version of your projector, refer to "Checking the

Current Firmware Version".

Connection

Connect the LAN port of the Projector to the LAN hub to which the device to be linked to via a wired

LAN connection is connected.

In a configuration like the one in the illustration above, you should normally use straight type LAN

cables. If you are connecting the Projector's LAN port directly to the LAN port of an external device,

use a cross type LAN cable.

Supported Devices and Standards

Web Browser

This Projector supports control using a computer web browser.

For details, see "Controlling the Projector from a Computer" in the User's Guide on the CD that

comes with this Projector.

PJLink

This Projector supports the PJLInk Class1 standard formulated by the Japan Business Machine

and Information ystem Industries Association (JBMIA).

For detailed information about PJLink, visit the website below.

URL http://pjlink.jbmia.or.jp/english/

• The following shows input switching instruction and input switching query parameters and

their corresponding input sources.

Parameter

Input

ource

COMPUTER

Terminal etting

Remarks

11 Computer Auto On the XJ-H1650, XJ-H1750, XJ-H2650,

XJ- T145, and XJ- T155 the input source is

Computer 1.

12 Computer RGB ''

13 Computer Component ''

14 Computer2 Auto XJ-H1650, XJ-H1750, XJ-H2650, XJ- T145,

XJ- T155 only

15 Computer2 RGB ''

16 Computer2 Component ''

21 Video

22 -video

31 HDMI

41 U B

• Image only mute is not supported by the AV mute instruction and AV mute state query.

• The cover open error and filter error are not supported by the error state query.

• A projector name query returns the projector name specified on the ystem Admin Page. For

details about the ystem Admin page, see " ystem Admin Page Operations and ettings" in

the "Wireless Function Guide" on the CD-ROM that comes with the projector.

• A manufacturer name query returns CA IO

CA IOCA IO

CA IO.

• A device name query returns XJ

XJXJ

XJ-

-NP

NPNP

NP.

• The password used for the connection authentication process is the same as the ystem

Admin page password. The Projector can be configured to enable or disable authentication. To

do so, use [Wired LAN ettings]-[PJLink authentication] on the Projector's etup Menu.

nable

ableable

able : PJLink connection authentication enabled. (Default)

Disabl

DisablDisabl

Disable

e : PJLink connection authentication disabled.

• Up to firmware version *.0.3.1, when the digest generated by the password is appended to the

command and sent to the projector during the authentication process, all of the letters

included in the digest must be upper-case.

Example: a6bb86c8a36e251485e539e7abb71b50%1POWR

↓

A6BB86C8A36E251485E539E7ABB71B50%1POWR

From firmware version *.0.3.2 onwards, the digest is accepted even if it contains lower-case

letters.

For information about the functions of other commands, see the PJLink specifications issued by

JBMIA.

Crestron

This Projector supports Crestron Electronics controller and software (RoomView®) commands.

For detailed information and information about downloading RoomView®, visit the website below.

URL http://www.crestron.com/roomviewconnected/

When using the Crestron controller, the controller IP address and other settings must be configured

on the Projector. ettings are configured on the Crestron Control page shown below, which appears

when your click [Crestron Control] on the ystem Admin page.

• IP address pecifies the controller IP address.

• IP ID pecifies the controller IP ID.

• Port pecifies the number of the port being used. (Always 41794)

Enter the applicable information for each item and then click the [Apply] button. This will restart

the network function and apply the new settings.

Up to firmware version *.0.3.7, the Crestron Control Image Mute function corresponds to the

Projector's Blank function. From firmware version *.0.3.8 onwards, both Image Mute and AV Mute

correspond to Blank.

AMX

This Projector supports the AMX controller and Device Discovery. Commands used for control are

PJLink standard commands.

For detailed information, visit the website below.

URL http://www.amx.com/

xtron

This Projector supports the Extron controller. Commands used for control are PJLink standard

commands.

For detailed information, visit the website below.

URL http://www.extron.com/

Caution

• The Projector can be configured to enable or disable power via wired LAN on from the

standby state. To do so, use [Wired LAN ettings]-[Remote On] on the Projector's etup

Menu.

Enable

EnableEnable

Enable : Power on enabled.

Disable

DisableDisable

Disable : Power on disabled. (Default)

Initializing network settings or performing a "Restore All Defaults" operation with the etup

Menu will cause this setting to change to "Disable". If you are operating the Projector using a

wired LAN setting, be sure to change this setting back to "Enable" after initialization.

• Up to firmware version *.0.3.2, when the IP address is set manually using the ystem Admin

screen, the default gateway setting is configured by the Projector, regardless of the input

value. When performing connection from an external network, allow acquisition of the IP

address and default gateway address under a DHCP environment.

From firmware version *.0.3.3 onwards, the default gateway setting is configured in

accordance with the input setting.

Checking the Current Firmware Version

Perform the following procedure to check a Projector's current firmware version.

1. Turn on the Projector and plug U B memory into the U B port. Memory contents do not matter.

2. Under initial Projector default settings, Viewer should start up automatically, unless plug and

play has been disabled on your Projector. If Viewer does not start up, press the INPUT key to

switch input to U B.

3. When the main Viewer window is projected, press the Projector's [▲] and [

◄

] cursor keys at the

same time.

4. This will cause the Projector's current firmware version number to appear in the lower left

corner of the screen.

The version number has four digits. The first digit on the left indicates whether your projector is a

XGA model or WXGA model. Digits 2 through 4 indicate the relative age of the version.

1.0.3.0

Firmware version age

XGA/WXGA identifier

This means that you need to pay attention to the final three digits of the version number when

determining how functions are affected. ince the first digit has no relation to what we are

discussing here, all version numbers in this manual have an asterisk (*) as the first digit.

NG120528E-D
