vk700 Compact Steam Oven with

Grill

Manual for Installation, Use and Maintenance

Important

This appliance must only be used for the purpose for which it is

intended, i.e. domestic cooking, defrosting and reheating foods. Any

other use could be dangerous and may lead to premature failure of

the appliance.

The CDA Group Ltd cannot be held responsible for injuries or losses

caused by incorrect use or installation of this product. Please note

that CDA reserve the right to invalidate the guarantee supplied with

this product following incorrect installation or misuse of the appliance.

User information:

•Ovens become hot during and immediately after use. Ensure you

do not touch the heating elements located inside the appliance.

•The oven door can become very hot during operation.

•After use, please ensure that the appliance is switched o.

•Keep children away from the appliance when in use, and

immediately after use.

•Keep the oven door closed when in use.

Appliance information:

Please enter the details on the appliance rating plate below for

reference, to assist CDA Customer Care in the event of a fault with

your appliance and to register your appliance for guarantee purposes.

Appliance Model

Serial Number

CE Declarations of Conformity:

This oven has been designed, constructed and marketed in

compliance with safety requirements of EEC Directive 2006/95/EEC

(Low voltage) and requirements of EMC Directive 2004/108/EEC.

This appliance has been manufactured to the strictest standards and

complies with all applicable legislation, including Electrical safety (LVD)

and Electromagnetic interference compatibility (EMC). Parts intended

to come into contact with food conform to EEC/89/109.4

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE

PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.

At the end of its working life, the product must be taken to a special

local authority waste collection centre or to a dealer providing

appliance recycling services. Disposing of a household appliance

separately avoids possible negative consequences for the

environment and health. It also enables the constituent materials to be

recovered, saving both energy and resources.

As a reminder of the need to dispose of household appliances

separately, the product is marked with a crossed-out wheeled dustbin.

Important

• Read the user instructions carefully before using the oven for the

ﬁrst time.

• Follow the instructions for rst use of the oven.

• Clean the oven regularly.

• Remove spills as soon as they occur.

• Always use oven gloves when removing shelves and trays from the

oven.

• Do not allow children near the oven when in use.

• Do not allow fat or oils to build up on the oven shelves, grill pan or

oven base.

• Do not place any cooking utensils or plates directly on the oven

base.

• Always grill with the oven door closed.

• Do not grill food containing fat without using the grill pan grid.

• Do not cover the grill pan grid or the oven walls with aluminium foil.

• Do not perform maintenance or cleaning of the oven without rst

switching o the electricity supply. If the oven has recently been

used, allow it to cool.

• Do not use abrasive cleaners or powders that will scratch the

surface of the appliance.

• Do ensure that the door is completely closed during cooking to

ensure the seal works properly.

• Do not attempt to repair the internal workings of your oven.

• Steam will escape when the door is opened. Step back from the

appliance and wait until the steam has dissipated.

• When opening the appliance, take great care that hot water which

may have collected in the drip tray does not overﬂow, as this may

cause injury.

• Do not come into contact with hot steam and do not touch the hot

oven sides.

Fitting Out The Appliance

Metal shelf

The metal shelf can be used for

toasting, browning and grilling. It is also

used for steam cooking.

To install the ﬂat shelf, insert it at a

45-degree angle and then position it

horizontally and push it all the way in, to

the end of the grill track.

To remove the ﬂat shelf, pull it toward

you until it stops and then lift, by pulling

upwards, until it comes completely out

(Fig. 1).

Fig. 1

Drip tray

The drip tray can be slid into its location

underneath the shelf to collect the

juices from grilling or the condensate

from steam cooking (Fig. 2).

To remove it, lift slightly and slide it

toward you.

To reinsert it, slide it back until it is

correctly seated.

Perforated tray

The perforated tray is used for steam

cooking and is positioned, with its

support frame, on the at grill (Fig. 3).

The drip tray is used with this to catch

drips from the food during steam

cooking.

Fig. 2

Fig. 3

The Control Panel

A B C D E

A: Grill warning light D: Steam oven knob

B: Grill knob E: Steam oven warning light

C: Electronic timer

The Timer

F G H J K L

F: Timer button G: Duration button

H: End button J: Manual button

K: - button L: + button

Fig. 4

Fig. 5

Before First Use

Cleaning

Before using the oven for the ﬁrst time we recommend that you clean

it with soapy water, rinse carefully and then heat on the grill setting

at maximum temperature for 30 minutes, with no accessories in the

oven.

A slightly unpleasant smell may be produced, caused by grease

remaining on the oven elements from the production process.

On rst electrical connection

On ﬁrst connection to the electricity supply the oven may give a

continuous beep. In this case, this may be cancelled by turning the

“Steam oven” knob to any position then back to the o position.

Setting the clock

Press the “Duration” button and the “End” button at the same

time, then use the “+” and “-” buttons to adjust the display to show

the correct time. The dot will stop ﬂashing and the time will set after a

delay of approximately 5 seconds.

General Settings & Use

Grill

Note: The grill function can not be used at the same time as the

steam oven function.

To turn the grill on

To turn the grill on, rotate the “Grill” knob (either way) to select the

temperature setting required.

To turn the grill o

To turn the grill o, rotate the “Grill” knob (either way) to return it to the

“0” position.

Steam oven

Note: The steam oven function can not be used at the same time as

the grill function.

Note: If the grill function has recently been used allow the oven to

cool back to room temperature before using the steam oven, in order

to avoid compromising the steam cooking process.

Filling the water reservoir

Open the oven door, then withdraw the water reservoir from the right

side of the aperture. Fill this with water up to the “MAX” mark.

Note: Do not over-ﬁll the reservoir.

Replace the water reservoir into its location in the appliance.

Preparation for steam cooking

The metal shelf, perforated tray and drip tray should be ﬁtted into the

oven as described on pages 5 & 6.

To turn the steam oven on

To turn the oven on, rotate the “Steam oven” knob (either way) to

select the cavity temperature as required.

Warning: Scalding risk - When opening the door stand well back and

allow the steam within the oven to dissipate before reaching inside.

To turn the steam oven o

To turn the steam oven o, rotate the “Steam oven” knob (either way)

to return it to the “0” position.

After use

Allow the oven to cool, then wipe the inside of the oven out to remove

condensation and residues remaining from the cooking process.

Leave the door open or ajar to allow the ﬁnal moisture to evaporate.

Remove and empty the water reservoir, dry it before replacing it in the

appliance.

See pages 14 & 15 for advice on steam defrosting and cooking.
