Unpacking
Remove and discard the plastic bag.
Be responsible when handling the packing materials.
eep the original packaging for future transportation and/or storage.
Check all accessories are removed from the packaging before storing it away for future use.
KEEP P ASTIC BAGS AWAY FROM CHI DREN!
Choosing a Suitable ocation
This electric fire is designed to be fitted within an existing brick / masonry chimney breast
which must be dry with the chimney capped off using a suitable chimney cap.
The appliance must be kept away from any source of damp or moist conditions. Avoid any
close contact with water.
Important Notice: To reduce heat losses and to prevent any chimney up draught affecting
the operation of your fire we recommend that the chimney is blocked off.
The chimney breast, wall or fireplace must be of sound construction and all fixings used
must be suitable for the type of wall. If there is any doubt regarding the suitability of the in-
stallation site please contact your supplier.
From the front of the fire ensure that there is a minimum clearance of 50mm between any
non-combustible materials. For combustible material clearances please consult with the man-
ufacturer.
The fire can be connected direct or plugged into a mains socket which can be sited on the
right hand side of the fire.
Ensure that the plug socket-outlet connection for this appliance is accessible. It MUST be
readily accessible for easy electrical isolation in the event of servicing and replacing compo-
nents etc. This appliance MUST NOT be located immediately below an electrical socket-out-
let.
Please refer to the relevant installation instructions applicable to the model fire purchased.
Installation must be carried out by a qualified and competent person.
The opening sizes required to install the fires are
Ultiflame 22” Ultiflame 33”
Height = 650mm Height = 605mm
Width = 610mm Width = 890mm
Depth = 185mm Depth = 185mm
