Central Pneumatic 41164 Guida di riferimento rapido
AIR HAND NAILER
41164
ASSEMBLY & OPERATING INSTRUCTIONS
99
REV07/01
®
THANKYOU for choosing a HARBOR FREIGHTTOOLS product. For future reference, please complete the
owner’s record below:
Model____________ Serial No._______________ Purchase Date _________________
SAVE THE RECEIPT, WARRANTY ANDTHESE INSTRUCTIONS. It is important that you read the entire
manual to become familiar with the unit BEFORE you begin assembly.
Technical Specifications
Tool Name:Air Hand Nailer
Item Number: 41164
Material: GravityAluminum
Air Nipple Material: Chrome Plated Steel
Tool Length: 5-1/4"
ToolWidth: 3-1/6"
Nail Length: 4"
OperatingPressure: 70 to 125 PSI *
AirConsumption: 8CFMnon-continuous
Driver Hardness: HRC 46 to 56
Air Inlet: 1/4" NPT Female
Warning: The warnings, cautions and instructions discussed in this instruction manual
cannot cover all possible conditions and situations that may occur. It must
be understood by the operator that COMMON SENSE AND CAUTION ARE
FACTORS WHICH CANNOT BE BUILT INTO THIS PRODUCT, BUT
MUST BE SUPPLIED BYTHE OPERATOR.
The Operator
PLEASEREMEMBER:
Do not operate the product if under the influence of alcohol or drugs. Read warning labels on prescriptions to
determine if your judgment/reflexes might be impaired.
Do not wear loose clothing or jewelry as they can be caught in moving parts.
Protective gloves and non-skid footwear is recommended.
Wear restrictive hair covering to contain long hair.
Use eye and ear protection. Always wear ANSI approved impact safety goggles.
Maintain proper footing and balance at all times.
Keep hands away from firing part of the Nailer or serious injury may occur.
#41164 REV07/01 REV 11/06 Page 2
*The air pressure setting must not exceed job site regulations/restrictions. The air pressure setting
must not exceed 90 PSI when being used with work pieces that have a thickness of less than 1-3/4”.
Do not point Nailer at yourself, other people or pets.
Do not randomly shoot the Nailer into open space, as this may result in injury.
Work Area
TO AVOID RISK OF PERSONAL INJURY, EQUIPMENT DAMAGE, FIRE AND SHOCK, MAKE SUREYOUR
WORK AREA IS:
Free of damp, wet or rainy conditions
Free of flammable gasses or liquids
Free of children (never let them handle tools or machinery)
Well-lit
Clean and uncluttered
Well-ventilated
Before Operating
Before operating your Air Hand Nailer, check for damaged parts.
Never force the tool or attachment to do the work of a larger industrial tool. It is designed to do
the job better and more safely at the rate for which it was intended.
Do not try to use inappropriate attachments in an attempt to exceed the tool’s capacity. Approved accessories
are available from Harbor Freight Tools.
Check for damaged parts. Before using any tool, any part that appears damaged should be carefully checked
to determine that it will operate properly and perform its intended function.
Never drive fasteners on top of other fasteners as the fastener may deflect, resulting in injury.
Assembly
Your Air HandNailercomes completely assembled.
Air connection
Step 1) You will need a Union fitting (sold separately) before you can connect your Air
Hand Nailer to an air compressor. Attach the Union fitting to the Air Inlet and
tighten the fitting.
Step2) Attach an Air Coupler (sold separately) to the Union fitting if desired. This is a useful
accessory as it allows quick-coupling action when using a variety of tools with the same
aircompressor.
Set up
Frequent, but not excessive, lubrication is required for best performance. Oil added through the airline
connection will lubricate internal parts. An automatic airline oiler is recommended but oil may be added
manually before every operation or after about one (1) hour of continuous use. Only a few drops of oil at a time
are necessary. Too much oil will collect inside of the tool and be blown out during the exhaust cycle. Use only
Pneumatic tool oil. Do not use detergent oil or additives as these lubricants will cause accelerated wear to
#41164 REV 07/01 Page 3
Dirt and water in the air supply are major causes of pneumatic tool wear. Use a filter/oiler for better
performance and longer life of the tool. The filter must have adequate flow capacity for the specific application.
Set up (Cont’d)
Consultthe manufacturer’s instructionsforproper maintenance of yourfilter.
The connector on the tool must not hold pressure when the air supply is disconnected. If the wrong fitting is
used, the tool can remain charged with air after being disconnected and still be able to drive a fastener.
Operation
Please refer to the Parts List on pages 5 and the Assembly Diagram on page 6 prior to operation. It is
important that your read the entire manual to become familiar with the unit BEFORE you use it.
Step 1) Set the air compressor regulator to between 70 PSI and 125 PSI.
Step 2) Turn on the compressor.
Step 3) Connect the air line to the Air Plug (part #21).
Step 4) Grasp the fastener by the shaft and insert it into the Guide Bushing (part #20) as shown below
in Figure 1.
Warning: Never allow the point of any fastener to face your body, any other person or
animal, or any equipment that could be injured or damaged!
Step5) Holding the Nailer firmly, bring the point of the Fastener in to contact with the work
piece and firmly press down until the Guide Bushing (#20) is fully retracted into the Guide
Bushing Retainer (part #18). The Nailer will then begin nailing.
the seals in the tool.
Air Plug
#41164 REV07/01 REV 11/06 Page 4
Air Nailer
Step6) Lift the Nailer off of the work piece immediately after the fastener has been driven in.
Step 7) Upon completion of your job, disconnect the Nailer from the air supply. Turn off
the compressor.
Caution: Disconnect the Air Hand Nailer from the compressor hose before performing maintenance or
replacing parts.
Spring and Connector Replacement
If the Spring (part #17) begins to slip, you must replace the Guide Bushing (#18), Guide Bushing Retainer (#18),
andSealRing(part #19).
Step 1) Remove the Guide Bushing Retainer from theTool. Slide the Retainer off of the Guide
Bushing.
Step 2) Remove the Spring from the Nailer. Replace the Spring, Guide Bushing and
Guide Bushing Retainer. Securely tighten back into place.
Seal Ring Replacement
If air leaks from the unit, you will need to replace the Seal Ring (part #14). Take the following steps if you are
replacing the Seal Ring.
Step 1) Remove the four Hex Bolts (part #1) from the Exhaust Cover (part #2). Remove the Exhaust
Cover from the body (part #16).
Step #2) Remove the Seal Ring. It may involve some scraping for removal.
Step #3) Using the appropriate replacement Seal Ring (available through Harbor Freight Tools), replace
the worn Seal Ring with the new Seal Ring.
Step #4) Replace the Exhaust Cover and Hex Bolts. Tighten down securely.
IF THERE IS ANY QUESTION ABOUT ACONDITION BEING SAFE OR UNSAFE, DO NOT OPERATE THE TOOL.
Unpacking
UNPACK AND CHECK CONTENTS
When unpacking your Air Hand Nailer, check to make sure the following parts are included. If any parts are
missingorbroken,please call HARBOR FREIGHTTOOLS at1-800-444-3353.
Part # Description Quantity Part # Description Quantity
1 Hex Bolt 1 13 Pipe 1
2 Exhaust Cover 1 14 Seal Ring 1
3 O-Ring 2 15 O-Ring 1
4 O-Ring 1 16 Body 1
5 O-Ring 2 17 Spring 1
6 Main Piston Unit 1 18 Guide Bushing 1
7 Slide Cover 1 19 Seal Ring 1
8 O-Ring 1 20 Guide Bushing Retainer 1
9 O-Ring 1 21 Air Plug 1
10 Cylinder 1 22 Hook 1
11 Cylinder Sleeve 1 23 Washer 1
12 Bumper 1 24 Hex Bolt 1
#41164 REV 07/01 Page 5
Assembly Diagram-Air Hand Nailer
#41164 REV 07/01 Page 6
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE
MANUFACTURER NOR DISTRIBUTOR MAKES ANY REPRESENTATION OR
WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE
ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS
REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED
TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND
LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR
REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
