Using Your

Adapter

AE1200/AE2500 Wireless-N USB Network Adapter

Linksys AE1200/AE2500

Product Overview

Features 1

Installation

Installation 2

Wireless Network Conﬁguration

Windows 7 3

Windows Vista 4

Windows XP 6

Troubleshooting

AE1200/AE2500 9

Speciﬁcations

Linksys AE1200 10

Linksys AE1200 11

Contents

Product Overview

Linksys AE1200/AE2500

Thank you for choosing the Linksys Wireless-N USB adapter. Using the latest

wireless networking technology, the adapter adds or upgrades wireless

connectivity on your Windows-based desktop or laptop computer. To help

protect your data and privacy, you can use Wi-Fi Protected Access 2 (WPA2)

encryption to protect your wireless connection.

Features

USB plug LED

USB plug: Connect this end to any available USB port on your computer.

LED: Flashes when there is wireless network activity.

Product Overview

Installation

Linksys AE1200/AE2500

This chapter describes the procedure for installing the adapter.

Installation

To install the adapter:

1. Insert the CD into your CD or DVD drive.

2. Click Set up your Linksys Adapter.

DVD/CD-RW Drive (E:) Linksys

Adapter Setup

AutoPlay

Always do this for software and games:

Install or run program

General options

Set up your Linksys Adapter

Published by Cisco Consumer Products LLC

View more AutoPlay options in Control Panel

Open folder to view files

using Windows Explorer

DVD/CD-RW Drive (E:) Linksys

Router Setup

Always do this for software and games:

Install or run program

General options

Set up your Linksys Adapter

Published by Cisco Consumer Products LLC

Set AutoPlay defaults in Control Panel

Open folder to view files

using Windows Explorer

Speed up my system

using Windows ReadyBoost

If you do not see this, access setup on the CD directly. To do so, perform

the following steps for your specific operating system:

Windows 7

a. Go to Start > Computer.

b. Double-click your CD or DVD drive.

Windows Vista

a. Go to Start > Computer.

b. Double-click your CD or DVD drive.

Windows XP

a. Go to Start > My Computer and select your CD or DVD drive.

b. Double-click Setup.exe.

3. Follow the on-screen instructions to finish setting up your Linksys

wireless adapter.

Note

You need to run Setup only once to install your adapter. After you

run Setup, your computer recognizes the adapter each time it is

connected to your computer’s USB port.

Installation

Wireless Network Configuration: Windows 7

Linksys AE1200/AE2500

To configure the adapter’s wireless connection settings, use a wireless network

configuration utility. If you have installed such a utility on your computer,

or if your computer came with one already installed, refer to that utility’s

documentation for instructions on use. Otherwise, follow the instructions in

the appropriate section below to use your operating system’s built-in utility:

• “Windows 7” on page 3

• “Windows Vista” on page 4

• “Windows XP” on page 6

Windows 7

After you have installed the adapter, the Wireless Network Configuration

utility icon appears on your computer’s system tray. (If you do not see the

icon, click the Show hidden icons arrow in the system tray.)

When your mouse pointer hovers over the icon, the status information of

your wireless connection appears.

New Wireless Connection

To connect to a different wireless network:

1. Click the Wireless Network Configuration utility icon. A list of available

wireless networks appears.

2. Select your network, and then click Connect.

3. If your network does not use wireless security, go to step 5.

Wireless Network Configuration

Wireless Network Configuration: Windows Vista

Linksys AE1200/AE2500

4. Enter the Wi-Fi Protected Access (WPA/WPA2) passphrase or the Wired

Equivalent Privacy (WEP) key (depending on your type of security), then

click OK.

This screen appears while the adapter connects to your network. Do not

cancel, unless you want to end the connection.

Your computer is now connected to your wireless network.

Note

For help with the Wireless Network Conﬁguration utility, click Start,

then click Help and Support.

Windows Vista

After you have installed the adapter, the Wireless Network Configuration

utility icon appears on your computer’s system tray.

When your mouse pointer hovers over the icon, the status information of

your wireless connection appears.

New Wireless Connection

To connect to a different wireless network:

1. Right-click the Wireless Network Configuration utility icon.

2. Click Connect to a network.

Wireless Network Configuration: Windows Vista

Linksys AE1200/AE2500

3. Select your network, then click Connect.

4. If your network uses wireless security, go to Step 5.

If your network does not use wireless security, this screen appears.

a. To connect to your unsecured network, click Connect Anyway and

go to Step 6.

5. Enter the Wi-Fi Protected Access (WPA/WPA2) passphrase or the Wired

Equivalent Privacy (WEP) key (depending on your type of security), then

click Connect.

This screen appears while the adapter connects to your network. Do not

cancel, unless you want to end the installation.

Wireless Network Configuration: Windows XP

Linksys AE1200/AE2500

This screen appears when you are connected to your network.

6. If you want to save your settings, select Save this network.

7. Click Close.

The Set Network Location screen may appear. This screen helps apply the

correct settings for your type of location.

a. Click Home, Work, or Public location, then click Close on the

resulting screen.

Note

For help with the Wireless Network Conﬁguration utility, click Start,

then click Help and Support.

Your computer is now connected to your wireless network.

Windows XP

After you have installed the adapter, the Windows XP Wireless Zero

Configuration Utility icon appears on your computer’s system tray.

When your mouse pointer hovers over the icon, the status information of

your wireless connection appears.

Wireless Network Configuration: Windows XP

Linksys AE1200/AE2500

New Wireless Connection

To connect to a new wireless network:

1. Right-click the Windows XP Wireless Zero Configuration icon in your

computer’s system tray, then click View Available Wireless Networks. A

window displays the available wireless networks.

2. Select the network that you want, then click Connect.

If the network uses wireless security, go to Step 4. Otherwise, continue

to Step 3.

3. Click Connect Anyway to connect the adapter to your unsecured

network, then go to Step 5.

4. If your network uses Wired Equivalent Privacy (WEP) wireless security,

enter the WEP Key in the Network key and Confirm network key fields. If

your network uses Wi-Fi Protected Access (WPA/WPA2) wireless security,

enter the passphrase in the Network key and Confirm network key fields.

Click Connect.

Note

Windows XP Wireless Zero Configuration does not support the use

of a WEP passphrase. Enter the exact WEP key used by your wireless

router or access point.

Note

If your network is using WPA2 security, make sure that you have

installed the Update for Windows XP (KB893357), available at

www.microsoft.com.

Wireless Network Configuration: Windows XP

Linksys AE1200/AE2500

Your wireless network will appear as Connected when your connection

is active.

Note

For help with the Wireless Network Conﬁguration utility, click Start,

then click Help and Support.

Your computer is now connected to your wireless network.
