Cisco DX70: etting up for care home use v1.2

Your DX70 is able to connect to NHS Scotland’s video conference infrastructure through a standard

broadband connection. We reco end linking the unit to your router using a network cable to receive

the best connection however the unit can connect via wi-fi too. Please note,

the quality of signal you receive and therefore video quality can di inish

rapidly the further your syste is fro your wireless access point.

Please contact [email protected], supplying the unit's MAC address e.g.

1C6A7AE09V47 (found on the rear of the unit, by the base on a DX70 or

under the flap for a DX80) for a userna e and password. You will also be

sent a 4-digit PIN nu ber to be used to unlock the screen. These are

required for the initial stages of setup.

1. Attach the power pack to the unit and network cable between the unit and your router (if you intend

to use a wireless connection please note the SSID and passcode you will require) then power on.

2. If you are connected by network cable your first screen will ask you to sign in. If no network cable is

attached, because you intend using a wireless

connection, you will be asked to choose your network

and enter the wireless password. As soon as you tap

on the box asking for Service Do ain an onscreen

keyboard will appear.

The Service Do ain is vc.scot.nhs.uk. Add the

userna e and case-sensitive password supplied by

the NVCS support desk and tap Sign In.

3. You'll then be greeted with a Welco e screen. Please tap the Get tarted button.

4. Tap Don't Allow when asked about WebEx Meetings.

5. Tap kip (botto RHS of screen) when asked about Finding the right people with Jabber.

6. Tap kip when asked about voice ail.

7. Tap kip when asked about contacts and calendars.

8. Tap Continue when you reach a screen saying you are all signed in.

9. When asked for a PIN tap OK and on the following screen tap PIN, enter

the 4-digit PIN you received in your e ail fro [email protected] and tap

Continue. You'll be asked to enter the PIN a second ti e. Do so and tap OK.

10. Your syste will now link to our network, will be auto atically configured to work with our other

units and will download any necessary fir ware and software updates. Your syste is now ready to

ake and receive video calls. You will see your syste ’s na e and its dial-in nu ber at the botto

LHS of your screen.

11. Now, please set up the default ho e page on the browser to allow the collection of service

evaluation data fro the unit's users.

a. Tap the Apps button (six white dots) at the top right hand corner of the screen

then Tap the Browser icon.

b. Once open, navigate to

https://www.survey onkey.co.uk/r/TECVC

c. Tap the browser enu button in the top right hand

corner (three square dots) and select Settings (last

ite ).

d. Under the General section, tap Set ho epage.

e. Then Select Current page.

f. Exit the browser and test by opening it again.

Setup Troubleshooting

If you don’t see the initial Sign In screen:

You'll probably see the Welco e screen with the Get Started

button entioned in setup ite 3. Follow instructions 3

through 8 (and 9 if asked for a PIN). Your syste should

eventually look like the screenshot to the left.

At the top right-hand corner you’ll see 6 s all dots.

Tap the Dots to access the inbuilt settings and apps.

Tap the orange and white ettings icon

The first enu you see on the LHS of the screen is Wireless

and Networks. Tap More... then tap Reset Network Settings

fro the RHS enu. Make sure the s all tick box for “Enable

auto atic local telephone service directory” is empty and tap

Reset. Follow the setup instructions overleaf fro 3 again
