Cisco Small Business RV320 Manuale di istruzioni

Cisco RV320/RV325 Gigabit Dual WAN VPN Router

ADMINISTRATION

GUIDE

78-20928-01

Cisco RV320/RV325 Administration Guide 3

Contents

Chapter 1: Getting Started 7

Features of the User Interface 8

Chapter 2: System Summary 11

System Information 11

Configuration (Wizard) 12

Port Activity 12

IPv4 and IPv6 13

Security Status 14

VPN Setting Status 14

SSL VPN Status 15

Log Setting Status 15

Chapter 3: Setup 17

Setup Network 17

IP Mode 17

WAN1 or WAN2 Port Settings 18

USB1 or USB2 Port Settings 28

3G/4G Connection 28

Setting Failover and Recovery 29

DMZ Enable 31

Password 31

Time 33

DMZ Host 34

(Port) Forwarding 34

Port Address Translation 37

Adding or Editing a Service Name 38

Setting Up One-to-One NAT 38

MAC Address Cloning 39

Assigning Dynamic DNS to a WAN Interface 40

Advanced Routing 41

Cisco RV320/RV325 Administration Guide 4

Contents

Configuring Dynamic Routing 41

Configuring Static Routing 42

Inbound Load Balance 43

USB Device Update 44

Chapter 4: DHCP 45

DHCP Setup 46

Viewing the DHCP Status 48

Option 82 49

IP and MAC Binding 49

DNS Local Database 51

Router Advertisement (IPv6) 52

Chapter 5: System Management 55

Dual WAN Connections 55

Bandwidth Management 57

SNMP 59

Configuring SNMP 59

Discovery-Bonjour 61

LLDP Properties 62

Using Diagnostics 62

Factory Default 63

Firmware Upgrade 63

Language Selection or Language Setup 64

Restart 65

Backup and Restore 65

Chapter 6: Port Management 69

Configuring the Ports 69

Port Status 70

Cisco RV320/RV325 Administration Guide 5

Contents

Traffic Statistics 70

VLAN Membership 71

QoS:CoS/DSCP Setting 71

DSCP Marking 72

802.1X Configuration 72

Chapter 7: Firewall 75

General 75

Access Rules 76

Content Filter 78

Chapter 8: VPN 81

Summary 81

Gateway to Gateway 83

Add a New Tunnel 83

Local Group Setup 84

Advanced Settings for IKE with Preshared Key and IKE with Certificate

Client to Gateway 91

Advanced Settings for IKE with Preshared Key and IKE with Certificate

VPN Passthrough 100

PPTP Server 100

Chapter 9: Certificate Management 101

My Certificate 101

Trusted SSL Certificate 103

Trusted IPsec Certificate 103

Certificate Generator 104

CSR Authorization 105

Cisco RV320/RV325 Administration Guide 6

Contents

Chapter 10: Log 107

System Log 107

System Statistics 110

Processes 110

Chapter 11: SSL VPN 111

Status 112

Group Management 112

Resource Management 115

Advanced Setting 116

Chapter 12: Wizard 117

Chapter 13: User Management 119

Cisco RV320/RV325 Administration Guide 7

Getting Started

The default settings are sufficient for many small businesses. Network demands

or your Internet Service Provider (ISP) might require modification of the settings.

To use the web interface, you need a PC with Internet Explorer (version 6 and

higher), Firefox, or Safari (for Mac).

To launch the web interface:

STEP 1 Connect a PC to a numbered LAN port on the device. If the PC is configured to

become a DHCP client, an IP address in the 192.168.1.x range is assigned to the

PC.

STEP 2 Start a web browser.

STEP 3 In the address bar, enter the default IP address of the device, 192.168.1.1. The

browser might issue a warning that the web site is untrusted. Continue to the web

site.

STEP 4 When the login page appears, enter the default user name cisco and the default

password cisco (lowercase).

STEP 5 Click Login. The System Summary page appears. Check the Port Activity to see

if a WAN connection is enabled. If not, continue to the next step.

STEP 6 To use the setup wizard to configure your Internet connection, click Setup Wizard

on the System Summary page. Or click Wizard in the navigation tree and in the

Basic Setup section, click Launch Now. Follow the on-screen instructions.

If your web browser displays a warning message about the pop-up window, allow

the blocked content.

STEP 7 To configure other settings, use the links in the navigation tree.

Getting Started

Features of the User Interface

8 Cisco RV320/RV325 Administration Guide

Troubleshooting Tips

If you have trouble connecting to the Internet or the web-based web interface:

•Verify that your web browser is not set to Work Offline.

•Check the local area network connection settings for your Ethernet adapter.

The PC should obtain an IP address through DHCP. Alternatively, the PC can

have a static IP address in the 192.168.1.x range with the default gateway

set to 192.168.1.1 (the default IP address of the device).

•Verify that you entered the correct settings in the Wizard to set up your

Internet connection.

•Reset the modem and the device by powering off both devices. Next,

power on the modem and let it sit idle for about 2 minutes. Then power on

the device. You should now receive a WAN IP address.

•If you have a DSL modem, ask your ISP to put the DSL modem into bridge

mode.

Features of the User Interface

The user interface is designed to make it easy for you to set up and manage your

device.

Navigation

The major modules of the web interface are represented by buttons in the left

navigation pane. Click a button to view more options. Click an option to open a

page.

Pop-Up Windows

Some links and buttons launch pop-up windows that display more information or

related configuration pages. If your web browser displays a warning message

about the pop-up window, allow the blocked content.

Help

To view information about the selected configuration page, click Help near the top

right corner of the web interface. If your web browser displays a warning

message about the pop-up window, allow the blocked content.

Getting Started

Features of the User Interface

Cisco RV320/RV325 Administration Guide 9

Logout

To exit the web interface, click Logout near the top right corner of the web

interface. The Login page appears.

Getting Started

Features of the User Interface

10 Cisco RV320/RV325 Administration Guide
