CITROEN C5 Manuale utente

PRIVATE CARS

C5-SYNERGIE

PRIVATE CARS

CAR 050011

Volume 2

2002

AC.QCAV/MTD

Méthodes Techniques Documentation



’’The intellectual property rights relating to the technical information contained in this document belong

exclusively to the manufacturer. Reproduction, translation or distribution in whole or in part without

prior written authorisation from the manufacturer is forbidden.‘‘

«The technical information contained in this document is intended for the exclusive use of the trained personnel of the

motor vehicle repair trade. In some instances, this information could concern the security and safety of the vehicle. The

information is to be used by the professional vehicle repairers for whom it is intended and they alone would assume full

responsibility to the exclusion of that of the manufacturer».

«The technical information appearing in this brochure is subject to updating as the characteristics of each model in the

range evolve. Motor vehicle repairers are invited to contact the CITROËN network periodically for further information and

to obtain any possible updates».

2002

PRESENTATION

THIS HANDBOOK summarises the characteristics, adjustments, checks and special features of CITROEN vehicles, not including COMMERCIA

vehicles for which there exists a separate handbook.

The handbook is divided into nine groups representing the main functions :

GENERA - ENGINE - INJECTION - IGNITION - C UTCH, GEARBOX, DRIVESHAFTS - AX ES, SUSPENSION, STEERING - BRAKES - E ECTRICA -

AIR CONDITIONING.

In each section, the vehicles are dealt with in the following order : C5 - SYNERGIE and all models where applicable.

The information given in this handbook is based on vehicles marketed in EUROPE.

IMPORTANT

If you find that this handbook does not always meet your requirements, we invite you to send us your suggestions which we will take into account

when preparing future publications. For example :

– INSUFFICIENT INFORMATION

– SUPERF UOUS INFORMATION

– NEED FOR MORE DETAI S

Please send your comments and suggestions to :

CITROEN U.K. td.

221, Bath Road,

S OUGH,

S 1 4BA.

U.K.

GENERAL

IDENTIFICATION OF VEHICLES

E1APO8RD

(A) Chassis stamp

(cold stamp on bodywork).

(B) Manufacturer’s data plate.

(under the rear bench seat)

(label on front pillar close to driver’s door).

(D) Inflation pressures and tyre references.

(label on front pillar close to driver’s door)

(E) Serial no. on odywork.

(F) Gear ox reference – Factory serial no.

(G) Engine legislation type – Factory serial no

GENERAL

DC 6FZB DC 6FZC/IF DC 6FZE DC RFNC/IF DC RFNB DC RFNE

6FZ RFN

1749 1997

78 9

BE4/5 AL4 BE4/5 AL4

20 DL 29 20 TP 44 20 BL 30 20 TP 42

Emission st nd rd L4 L5 L4 L5 L4 L5

Type code

Engine type

Cubic c p city (cc)

Fisc l r ting (hp)

Ge rbox type

Ge rbox ident. pl te

C5 - All Types IDENTIFICATION OF VEHICLES

Petrol s loons

X-SX

1.8i 16V

X-SX-Exclusive

2.0i 16V

Autom tic

GENERAL

L4 L5

DC RLZB DC XFXC/IF DC XFXF/IF

RLZ XFX

1997 2946

81314

BE4/5 ML/5C ML/5T 4 HP 20

20 DL31 20 LM 21 20 LE 95 20 HZ 13

C5 - All Types

IDENTIFICATION OF VEHICLES

Petrol s loons

2.0 HPi 30.i 24V V6

Exclusive

Autom tic

Emission st nd rd

Type code

Engine type

Cubic c p city (cc)

Fisc l r ting (hp)

Ge rbox type

Ge rbox ident. pl te

GENERAL

Emission st nd rd L4

Type code DC RHYB DC RHSB DC RHSE DC RHZB DC RHZE

Engine type RHY RHS RHZ

Cubic c p city (cc) 1997

Fisc l r ting (hp) 6767

Ge rbox type BE4/5 ML/5C ML/5T (*) AL4 ML/5C ML/5T AL4

Ge rbox ident. pl te 20 DL 32 20 LM 18 20 LE 94 20 TP 43 20 LM 18 20 LE 94 20 TP 43

C5 - All Types IDENTIFICATION OF VEHICLES

Diesel s loons

2.0 HDi

XX-Exclusive

Autom tic Autom tic

(*) FAP = Particle filter

GENERAL

Autom tic

Emission st nd rd L4

Type code DC 4HXB DC 4HXE

Engine type 4HX

Cubic c p city (cc) 2179

Fisc l r ting (hp) 8

Ge rbox type ML/5C ML/5T 4 HP 20

Ge rbox ident. pl te 20 LM 17 20 LE 96 20 HZ 20

IDENTIFICATION OF VEHICLES

Diesel s loons

2.2 HDi

SX-Exclusive

C5 - All Types

GENERAL

Emission st nd rd L4 L5 L4 L5

Type code DE 6FZC/IF DE 6FZB DE RFNC/IF DE RFNE DE RLZB DE XFX/IF DE XFXF/IF

Engine type 6FZ RFN RLZ XFX

Cubic c p city (cc) 1749 1997 2946

Fisc l r ting (hp) 7981314

Ge rbox type BE4/5 AL4 BE4/5 ML/5C ML/5T 4 HP 20

Ge rbox ident. pl te 20 DL 29 20 DL 30 ? 20 DL 31 20 LM 21 20 LE 95 20 HZ 13

IDENTIFICATION OF VEHICLES

Petrol est tes

3.0i 24V V6

2.0 HPi

2.0i 16V1.8i 16V

Exclusive

X-SX

Autom tic

C5 - All Types

GENERAL

Emission st nd rd L4

Type code DE RHYB DE RHSB DE RHSE DE RHZB DE RHZE

Engine type RHY RHS RHZ

Cubic c p city (cc) 1997

Fisc l r ting (hp) 6767

Ge rbox type BE4/5 ML/5C ML/5T AL4 ML/5C ML/5T AL4

Ge rbox ident. pl te 20 DL 32 20 LM 18 20 LE 94 (*) 20 TP 43 (*) 20 LM 18 20 LE 94 20 TP 48 (*)

C5 - All Types

IDENTIFICATION OF VEHICLES

Diesel est tes

2.0 HDi

XX-Exclusive

Autom tic Autom tic

(*) FAP = Particle filter
