Clarion MSS433 Manuale utente
SOURCE COMMANDER
MSS433
OWNER’S MANUAL
INSTALLATION GUIDE
MULTISTATION
A/V SELECTOR
RLVRLVRLVRLV
OWNER’S MANUAL/INSTALLATION GUIDE
1
WARNING!
THE CLARION MSS433 MULTISTATION A/V SELECTOR IS
DESIGNED FOR SWITCHING OF VIDEO SOURCES FOR REAR
SEAT VIEWING ONLY.
THIS PRODUCT IS NOT INTENDED FOR VIEWING BY THE
DRIVER WHILE THE VEHICLE IS IN MOTION SINCE SUCH USE
MAY DISTRACT THE DRIVER OR INTERFERE WITH THE DRIV-
ER’S SAFE OPERATION OF THE VEHICLE AND MAY RESULT
IN SERIOUS INJURY OR DEATH. SUCH USE MAY ALSO VIO-
LATE STATE LAW.
CLARION DISCLAIMS ANY LIABILITY FOR ANY BODILY
INJURY, INCLUDING FATALITIES, OR PROPERTY DAMAGE
THAT MAY RESULT FROM ANY IMPROPER OR UNINTENDED
USES OF THIS PRODUCT.
ABOUT INSTALLATION
Installation of mobile audio and video components requires
experience with a variety of mechanical and electrical proce-
dures. Even though this manual provides general installation
and operation instructions for your new Clarion MSS433
Multistation A/V Selector, it does not show the exact installa-
tion methods for your particular vehicle.
If you do not have the required knowledge and experience to
successfully complete the installation, we strongly recom-
mend consulting an authorized Clarion dealer about profes-
sional installation options.
TABLE OFCONTENTS
Introduction...............................................................2
Installation And Operation Precautions......................3
Installation And Wiring .............................................5
Description Of MSS433 Front Connectors .................10
Description Of MSS433 Rear Connectors ..................12
Description Of Control Station..................................13
Applications Input Configurations............................15
Applications Output Configurations .........................16
Operating the MSS433 ...........................................17
Troubleshooting ......................................................19
Specifications ..........................................................20
SOURCE COMMANDER MSS433
2
INTRODUCTION
The Clarion MSS433 is a full-featured Multistation A/V
Selector specifically created for the mobile environment.
When used with the enclosed Control Stations, the system
allows true multi-zone control with independent audio/video
selection of up to four sources and connection of up to three
monitors, each capable of displaying a different audio/video
program. Each station provides individual entertainment.
The MSS433 also includes the following features:
•Works with all Clarion monitors
•Accepts up to three individual Control Stations
•All solid-state electronic circuits
•Audio level gain controls
•Buffered input and output audio/video circuits
•Gold-plated RCA connectors
•High-quality video/audio selector circuits
•Rear Vision Camera automatic switching
About The Manual And Warranty
To start enjoying your new Clarion MSS433 Multistation A/V
Selector, please read all remaining instructions listed in this
manual. Keep all instructions for future reference.
This product is covered by a limited warranty (see the
enclosed warranty card). Save the sales receipt to protect
your purchase and aid in warranty service.
OWNER’S MANUAL/INSTALLATION GUIDE
3
INSTALLATION AND OPERATION PRECAUTIONS
Installation Precautions
•This unit operates on an automotive 12-volt negative
ground power source and requires additional mobile audio
and video components for proper operation.
•Before installation, disconnect the (–) negative lead from
the vehicle’s battery.
•Use only supplied screws and hardware. Make sure all
connections and components are fastened securely.
•At the proposed installation sites, make sure there is ade-
quate space to accommodate both MSS433 and the
Control Station dimensions.
•Use extreme caution when drilling around electrical
wiring, brake lines, and fuel lines. Check clearances on
both sides of a planned installation surface before drilling
any holes or installing any screws.
•Always wear protective eyewear when using tools.
•Use only high-quality RCA cables that are no longer than
necessary for direct connections to other components in
the system. Extra-length audio and video cables can
cause signal loss and act as an “antenna” for noise.
•When routing RCA cables, keep them away from power
cables and output speaker wires.
Operation Precautions
•Donot allow liquids or foreign objects to enter the
MSS433 Multistation A/V Selector or Control Station(s).
•If any unit should become wet, turn off all power and let
your authorized Clarion dealer clean or service the equip-
ment.
DO NOT ATTEMPT TO OPEN OR SERVICE THE
MSS433 OR CONTROL STATIONS. THE INTER-
NAL PARTS ARE NOT USER-SERVICEABLE.
DOING SO WILL VOID THE WARRANTY.
•Do not place heavy objects on the MSS433 Multistation
A/V Selector or Control Station(s).
SOURCE COMMANDER MSS433
4
•Do not drop or excessively jar the MSS433 Multistation
A/V Selector or Control Station(s).
•Do not use liquid cleaners on any surfaces. Only use a
soft (cotton or other non-static) cloth to wipe off finger-
prints or other imprints from the faceplate or remote con-
trol.
•Do not subject the unit to direct sunlight or an extremely
hot environment (e.g., closed windows on a hot summer
day, direct path of heater vent, etc.).
•Avoid using the products under the following conditions:
– After extended parking on an extremely hot or cold day
– Near strong magnetic fields
– In an environment with excessive humidity, dust, or
vibration (e.g., off-road travel, etc.)
OWNER’S MANUAL/INSTALLATION GUIDE
5
INSTALLATION AND WIRING
Parts List
•(1) Source Commander MSS433 A/V Selector
•(3)Control Stations
•(3) Control Station Cables
•(2) Mounting L-Brackets
•(4) M4 x 8 Pan Head Machine Screws
•(4) M4 x 15 Self-tapping Sheet Metal Screws
•(1) 4-pin Molex Power Connector
•(3) 2-pin Monitor Power Connectors
•Owner’s Manual/Installation Guide
•Warranty Registration Card
Installing the MSS433
Figure 1. Installing the MSS433.
RLVRLVRLVRLV
POWER
M4x15 Self-tapping
SheetMetalScrew
(4supplied)
M4x8PanHead
MachineScrews
(4supplied)
SOURCE COMMANDER MSS433
6
Installing the Control Station
Figure 2. Installing the Control Station in a center console.
MSS433 Wiring for the 4-Pin Power Harness
Figure 3. Wiring and pinouts for the 4-pin power harness.
Reverse (Green)
Ignition (Red)
Battery +12V (Yellow)
Ground (Black)
1
2
3
4
1 2
34
END
VIEW
ToGround
Black
Green
ReverseSwitch
ToVehicle
Circuits
IgnitionSwitch
ReverseLights
(onvehicle’srear)
Battery
+
-
Red
Fuse(NotSupplied)
Yellow
Opening
MountingBazel
ControlStation
OWNER’S MANUAL/INSTALLATION GUIDE
7
INSTALLATION AND WIRING (CONTINUED)
MSS433 Wiring for DVD Disc Player
Figure 4. Wiring diagram using a VS718 DVD player.
MSS433 Wiring for VCR
Figure 5. Wiring diagram for a VCR Input.
RLVRLVRLVRLV
VideocassetteRecorder (rearview)
Yellow
RED
RLVRLVRLVRLV
SOURCE COMMANDER MSS433
8
MSS433 Wiring for Rear Vision Camera
Figure 6. Wiring diagram for a Clarion Rear Vision Camera.
R L V R L V R L V R L V
OWNER’S MANUAL/INSTALLATION GUIDE
9
Power Connector Pinouts
Figure 7. 4- and 2-pin Molex Power connector pinouts.
MSS433 Video and Power Connector Pinouts
Figure 8. MSS433 Chassis A/V Inputs, Outputs, & Power connectors.
POWER
4-Pin Connector
(Male Pins)
END
VIEW
END
VIEW
Reverse (Green)
Ignition (Red)
Battery (Yellow)
Ground (Black)
1
2
3
4
1 2
34
MONITOR OUTPUT
2-Pin Connector
(Male Pins) Positive Lead
Negative Lead
1
2
1 2
CenterConnductor is signal(+),
Outsideconductor is signalground (-).
CenterConnductor is signal(+),
Outsideconductor is signalground (-).
A/V INPUT 1~4
RCAs
A/V OUTPUT 1~3
RCAs
MONITOR OUTPUT
2-Pin Connector
Chassis
View
Positive Lead
Negative Lead
1
2
12
POWER INPUT
4-Pin Molex
Reverse (Green)
Ignition (Red)
Battery (Yellow)
Ground (Black)
1
2
3
4
12
3
4
Chassis
View
