Clarity XL40D Manuale utente

User Guide

XL40D Amplied Telephone

with ClarityLogicTM and DCPTM

TABLE OF CONTENTS

Important Safety Instructions  4

Packaging Contents  7

Basic Installation  8

Wallmount Installation  9

XL40D Features List  10

Operations  14

Boost Function/Amplifying Incoming Sounds                       14

Adjust Volume  14

Adjust Tone  14

Setting Sound Levels  15

Boost Override  15

Memory Storage  16

Outgoing Speech Amplication (OSA)                            16

Technical Specications  18

Clarity LogicTM  19

ClarityLogic Memory Dial®  19

Troubleshooting  21

IMPORTANT SAFETY INSTRUCTIONS

When using your telephone equipment, basic safety precautions should

always be followed to reduce the risk of re, electric shock and injury to

persons, including the following:

1 Read and understand all instructions

2 Follow all warnings and instructions marked on the telephone

3 Do not use this telephone near a bathtub, wash basin, kitchen sink or

laundry tub, in a wet basement, near a swimming pool or anywhere

else there is water

4 Avoid using a telephone (other than a cordless type) during a storm

There may be a remote risk of electrical shock from lightning

5 Do not use the telephone to report a gas leak in the vicinity of the leak

6 Unplug this telephone from the wall outlets before cleaning Do not

use liquid cleaners or aerosol cleaners on the telephone Use a damp

cloth for cleaning

7 Place this telephone on a stable surface Serious damage and/or injury

may result if the telephone falls

8 Do not cover the slots and openings on this telephone This telephone

should never be placed near or over a radiator or heat register This

telephone should not be placed in a built-in installation unless proper

ventilation is provided

9 Operate this telephone using the electrical voltage as stated on the

base unit or the owner’s manual If you are not sure of the voltage in

your home, consult your dealer or local power company

10 Do not place anything on the power cord Install the telephone where

no one will step or trip on the cord

11 Do not overload wall outlets or extension cords as this can increase

SAVE THESE INSTRUCTIONS

the risk of re or electrical shock

12 Never push any objects through the slots in the telephone They can

touch dangerous voltage points or short out parts that could result

in a risk of re or electrical shock Never spill liquid of any kind on

the telephone

13 To reduce the risk of electrical shock, do not take this phone apart

Opening or removing covers may expose you to dangerous voltages or

other risks Incorrect reassembly can cause electric shock when the

appliance is subsequently used

14 Unplug this product from the wall outlet and refer servicing to the

manufacturer under the following conditions: when the power supply

cord or plug is frayed or damaged; if liquid has been spilled into the

product; if the telephone has been exposed to rain or water; if the

telephone has been dropped or the case has been damaged; if the tele-

phone exhibits a distinct change in performance; if the telephone does

not operate normally by following the operating instructions Adjust

only those controls that are covered by the operating instructions Im-

proper adjustment may require extensive work by a qualied technician

to restore the telephone to normal operation

15 Never install telephone wiring during a lightning storm

16 Never install telephone jacks in wet locations unless the jack is speci-

cally designed for wet locations

17 Never touch uninsulated telephone wires or terminals unless the tele-

phone line has been disconnected at the network interface

18 Use caution when installing or modifying telephone lines

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

BATTERY SAFETY

IMPORTANT: Dispose of

used batteries according to the instructions.

1 Do not dispose of the battery in a re as it may explode Check with

local codes for possible special disposal instructions

2 Do not open or mutilate the battery Released electrolyte is corrosive

and may cause damage to the eyes and skin Additionally, it may be

toxic if swallowed

3 Exercise care in handling batteries in order not to short the battery

with conducting materials such as rings, bracelets and keys The battery

or conduction material may overheat and cause burns

SAVE THESE INSTRUCTIONS

PACKAGING CONTENTS

Your package includes all the items as shown below If there is anything

missing, please contact our Customer Care Department immediately

NOTE: Please retain a copy of proof of purchase for

your records.

User Guide and

Warranty/FCC Regulations

Mounting bracket

Telephone line cords

(one long cord and

one short cord)

Handset coil cord

Handset

DC adapter

Base unit

Basic Installation

Step 1: Install the backup batteries (optional) by removing the battery

cover as shown in Figure 1. Connect your telephone as shown

in Figure 2.

Step 2: Connect one end of the phone cord into the (square) LINE port

on the back of the phone; connect the other end of the phone

cord into your wall telephone outlet

Step 3: Connect one end of the (curly) handset cord into the handset jack

on the left side of your base; connect the other end of the handset

cord into the bottom of the handset Place handset in cradle

Step 4: Connect the DC adapter cord into the (round) DC 9V 500MA

port on the back of your phone; plug the adapter into your wall’s

electrical outlet

IMPORTANT: Use only with Class (Classe) 2 power source

Note: Remove battery cover using a thin object (like the tip of a

pen) to push down the tab shown by the arrow above.

When nished, lift handset to test If you hear a dial tone, your telephone is

ready for use If not, check all connections again

If there is a power outage, the XL40D will maintain its full amplication for

up to 48 hours with four AA alkaline backup batteries (not included)

Figure 1 Figure 2

XL40D INSTALLATION

The phone operates as a regular phone if there is no power or backup

batteries In this case, the indicator lights, the loud ringer, the lighted key-

pad and the amplication will be disabled; you will still be able to make and

receive phone calls, but the extra amplication will not be engaged

We recommend installing batteries if you live in an area with frequent

power outages

Wall Mount Installation

Step 1: Pull the handset hook out of the base and reverse its position so

that the hook points up and will hold the handset when you hang

up (See Figure 3)

Step 2: Plug one end of the short at telephone line cord into the jack

marked LINE located on the back of the telephone Then run the

cord through the groove on the back of the phone Insert the tabs

of the mounting bracket into the slots in the back of the phone

Push the mounting bracket in and down rmly until it snaps into

place (See Figure 4)

Step 3: Plug the at telephone line cord into the wall plate jack, then align

the mounting bracket’s keyhole slots with the wall plate studs and

slide the base of the phone downward to secure it on the wall

(See Figure 5)

Figure 3 Figure 4 Figure 5

1 Blue ClarityLogic Button: press the blue button for direct access to

a Customer Care Representative

2 Memory Buttons (M1-M10 and Emergency): for saved numbers

(see MEMORY STORAGE section for details)

3 SPKR (Speaker) Button: press SPKR to engage the speakerphone

function; press again to turn the feature off

4 FLASH Button: use this button to engage the Call Waiting Caller ID

functions (feature provided by local phone company)
