USER INSTRUCTIONS

ORIGINAL INSTRUCTIONS GC0618 ISS 2

HOT AIR GUN

MODEL NO: CHG2000C

PART NO: 3400764

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

INTRODUCTION

Thank you for purchasing this CLARKE Hot Air Gun.

Before attempting to use this product, please read this manual thoroughly and

follow the instructions carefully. In doing so you will ensure the safety of yourself

and that of others around you, and you can look forward to your purchase

giving you long and satisfactory service.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt which will be

required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or

tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission. This guarantee does not effect your

statutory rights.

SPECIFICATION

Dimensions (D x W x H) 250 x 90 x 205 mm

Product Weight 0.74 kg

Operating Voltage/Frequency 230 V - 50 Hz

Input Power 2000 W

Electrical Insulation Class II

Duty Cycle Continuous

Temperature Settings:

Setting 1:

Setting 2:

350oC

550oC

Air Flow Settings:

Setting 1:

Setting 2:

250 litres/min

550 litres/min

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

IMPORTANT

Please read all of the safety and operating instructions carefully before using

this product. The following safety symbols may be found on the product.

GENERAL SAFETY RULES

GGENERAL SAFETY IN THE WORKPLACE

1. Always keep work area clean & tidy. Cluttered work areas and benches

invite accidents.

2. Never over-reach. Keep proper footing and balance at all times.

3. Never store equipment in a wet/damp environment or expose to rain.

4. Always ensure the workplace is well lit. Ensure that lighting is placed so that

you will not be working in your own shadow.

5. Keep other persons away. Do not let persons, especially children, not

involved in the work, touch the tool or extension cable and keep them

away from the work area.

6. Never operate a power tool when under the influence of alcohol, drugs or

medication.

7. Stay alert, watch what you are doing, use common sense and do not

operate the power tool when you are tired.

Read this instruction

booklet carefully

before use.

Wear protective gloves

Wear eye protection Wear dust mask.

WARNING: WHEN USING ELECTRIC TOOLS, BASIC SAFETY PRECAUTIONS

SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC

SHOCK AND PERSONAL INJURY INCLUDING THE FOLLOWING. READ ALL

THESE INSTRUCTIONS BEFORE ATTEMPTING TO OPERATE THIS PRODUCT

AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

CARE OF POWER TOOLS

1. Read this manual carefully. Learn the tool’s applications and limitations, as

well as the specific potential hazards peculiar to it.

2. Always disconnect the power tool from the power supply before carrying

out any repairs or changing of accessories.

3. Do not use a power tool if the switch does not turn it on and off.

4. Always check for any damage or any condition that could affect the

operation of the tool. Damaged parts should be properly repaired.

5. This tool complies with the relevant safety standards. Repairs should only be

carried out by qualified persons using original spare parts, otherwise this

may result in considerable danger to the user.

6. Never use this power tool for any other purpose than that described in

these instructions.

7. Never abuse the power cable by yanking the cable to disconnect it from

the socket. Keep the cable away from heat, oil or sharp edges.

8. Guard against electric shock. Avoid body contact with earthed or

grounded surfaces.

9. If the tool should be used outdoors, use only extension cables intended for

outdoor use and marked accordingly.

10. Avoid accidental starting by making sure the power switch is off before

plugging in the power cable.

ADDITIONAL SAFETY RULES FOR HOT AIR GUNS

1. Always keep the mains cable well away from the hot air gun, particularly if

laying it down temporarily during use.

2. Never leave the hot air gun unattended when it is switched on.

3. Always wear safety gloves and never touch the hot nozzle.

4. Never point the hot air gun at any person or animal.

5. Never use in an atmosphere where solvent vapours are present.

6. Never use the hot air gun as a hair dryer.

CAUTION: WITH ALL TOOLS, THERE ARE CERTAIN HAZARDS INVOLVED

WITH THEIR OPERATION AND USE. EXERCISING RESPECT AND CAUTION

WILL CONSIDERABLY LESSEN THE RISK OF PERSONAL INJURY. HOWEVER,

IF NORMAL SAFETY PRECAUTIONS ARE OVERLOOKED, OR IGNORED,

PERSONAL INJURY TO THE OPERATOR, OR DAMAGE TO PROPERTY MAY

RESULT.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

7. Be aware that heat generated by the hot air gun could cause nearby

materials to ignite - particularly in confined spaces. Take all necessary

precautions - have a fire extinguisher or means to extinguish a fire to hand.

8. Be aware that fumes given off by paint could be toxic. Take all necessary

precautions - consult paint manufacturer etc where necessary.

9. Do not stand on a soft surface. The air gun could topple over or the air

intakes become blocked.

10. Always ensure that air can circulate around the hot air gun and that the air

vents are unobstructed.

11. Be aware that heat may be conducted to combustible materials that are

out of sight. Do not apply heat to the same place for a long time.

12. Always switch the hot air gun OFF after use and stand it upright while it

cools. Place the gun where it cannot cause damage or be accidentally

touched by persons in the area.

ENVIRONMENTAL RECYCLING POLICY

Through purchase of this product, the customer is taking on the

obligation to deal with the WEEE in accordance with the WEEE

regulations in relation to the treatment, recycling & recovery and

environmentally sound disposal of the WEEE.

In effect, this means that this product must not be disposed of with general

household waste. It must be disposed of according to the laws governing

Waste Electrical and Electronic Equipment (WEEE) at a recognised disposal

facility.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

ELECTRICAL CONNECTIONS

Before switching the product on, make sure that the voltage of your electricity supply is

the same as that indicated on the rating plate. This product is designed to operate on

230VAC 50Hz. Connecting it to any other power source may cause damage.

This product may be fitted with a non-rewireable plug. If it is necessary to change the

fuse in the plug, the fuse cover must be refitted. If the fuse cover becomes lost or

damaged, the plug must not be used until a suitable replacement is obtained.

If the plug has to be changed because it is not suitable for your socket, or due to

damage, it should be cut off and a replacement fitted, following the wiring instructions

shown below. The old plug must be disposed of safely, as insertion into a mains socket

could cause an electrical hazard.

If the colours of the wires in the power cable of this product do not correspond with the

markings on the terminals of your plug, proceed as follows.

• The wire which is coloured Blue must be connected to the terminal which is

marked Nor coloured Black.

• The wire which is coloured Brown must be connected to the terminal which is

marked Lor coloured Red.

We strongly recommend that this machine is connected to the mains supply via a

Residual Current Device (RCD)

If in any doubt, consult a qualified electrician. DO NOT attempt any repairs yourself.

This symbol indicates that this is a Class II product, and does not require an earth

connection.

WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS

THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE

MAINS SUPPLY.

WARNING! THE WIRES IN THE POWER CABLE OF THIS PRODUCT

ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:

Blue = Neutral Brown = Live

Plug must be BS1363/A approved.

Always fit a 13 Amp fuse.

Ensure that the outer sheath of the cable is firmly held by the clamp

Neutral

(Blue)

Live

(Brown)

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

PRODUCT OVERVIEW

INVENTORY CHECK

Before starting work, please check contents against the list above and advise

your dealer immediately if any parts are missing.

NO DESCRIPTION NO DESCRIPTION

1 Handle for Triangular Shave Hook 5 Concentrator Nozzle

2 Moulded Plastic Carry Case 6 Glass Protection Nozzle

3 Hot Air Gun 7 Reflector Nozzle

4 Triangular Shavehook (scraper) 8 Diffuser Nozzle

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

OPERATION

Before starting work it is recommended that you heat a test piece to ensure

you have the correct heat setting. In addition you should always take steps to

protect sensitive or delicate areas where the effect of heat could cause

damage (i.e. glass and plastics). Do not apply heat to the same place for a

long time.

After the work has been completed, switch the gun off, disconnect from the

mains supply and allow to cool in a safe place.

Take care not to drop the gun as this could damage the heating element.

To prevent the gun from overheating, maintain a minimum distance of 3 cm

between the end of the nozzle and the work piece.

REMOVING PAINT AND DISSOLVING ADHESIVES

1. Fit the nozzle to the front of the gun.

2. With the switch in the ‘0’ (OFF) position plug the gun into the mains supply.

3. Set the switch to either position 1

or 2 according to how much heat

is required. (see Specification).

• Ensure the nozzle is pointing

away from you.

4. Bring the nozzle of the hot air gun

to the work piece approximately 3

cm from the surface.

• The exact distance between

the nozzle and the work piece

will be dependent on the material being worked on.

• Paint will rapidly become soft and blister, at which point it can be

removed with the triangular shave hook. Do not allow paint to burn

as this will make the removal process more difficult.

• Most adhesives dissolve when heated and these can then be

removed, taking care that any parts from which glue is removed are

heat resistant.

• Heating and paint removal are performed simultaneously, with the

shave hook following the hot air gun.

5. Clean the shavehook blade quickly if paint/glue becomes stuck to it.

• Profiled parts may be cleaned with a suitable wire brush once paint

is softened.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

• Normally only one pass is required to remove both thick and thin

layers of paint.

REMOVING PAINT FROM WINDOW FRAMES

DO NOT point the gun directly at

glass and always ensure it is

adequately protected. A glass

protection nozzle is provided for use

when stripping window frames etc.

1. Fit the glass protection nozzle to

the front of the hot air gun and

angle it so that the gun can be

placed up against the window,

with the cowl of the nozzle, flat

against the glass as shown.

2. It will be necessary to change the position of the protection nozzle as you

work around the window pane. Ensure you wear adequate hand

protection when doing so.

3. The protection nozzle must be kept in contact with the work at all times, but

do not spend too much time in one area.

FORMING AND WELDING PLASTIC PARTS

When bending or forming plastic parts, work slowly and with great care

observing the effects of heat on such materials.

NOTE: With plastics, the temperature range between solid, pliable and

liquid states is narrow, therefore great care should be taken.

WOOD STAINING

Wood can be stained giving a ‘rustic’ effect.

1. Fit the diffuser nozzle to the front of the hot air gun.

2. Do not hold the nozzle too close to the wood as this may cause the wood

to colour unevenly.

3. Use a fine sandpaper to remove any singed wood fibres when finished.

HEAT SHRINK SLEEVE FITTING

Fit the concentrating nozzle to the front of the hot air gun.

1. Select a suitable size heat shrink sleeve for the work piece.

2. Heat the sleeve evenly.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

THAWING WATER PIPES

Fit the reflector nozzle to the front of the hot air gun.

1. Always heat frozen areas inwards from the edge to the centre.

2. Take special care when defrosting plastic pipes.

3. Provide protection against heat damage to nearby paint and wall

coverings where necessary.

4. Be aware that copper gas pipes can be difficult to distinguish from copper

water pipes. Always check first.

5. Copper pipes are soldered together, therefore should not be heated

above 200oC.

MAINTENANCE

This hot air gun is maintenance free, except always ensure that the air intake

vents are kept clean. If used in a dusty environment clean the tool with low

pressure compressed air.

DECLARATION OF CONFORMITY

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Clarke Utensili elettrici

Clarke

Clarke cp185 Manuale di installazione e funzionamento

Clarke

Clarke Strong-Arm CSA15F Manuale di installazione e funzionamento

Clarke

Clarke CTC150LI Manuale di istruzioni

Clarke

Clarke CCIW160 Manuale di installazione e funzionamento

Clarke

Clarke Air TPG30PTC Manuale utente

Clarke

Clarke CDP152B Manuale di istruzioni

Clarke

Clarke CEW1000 Manuale

Clarke

Clarke Metalworker CDP101B Manuale di installazione e funzionamento

Clarke

Clarke CCRT266 Manuale di istruzioni

Clarke

Clarke Air CAT217 Manuale di installazione e funzionamento

Clarke

Clarke MetalWorker CDP151B Manuale di installazione e funzionamento

Clarke

Clarke CIR18Li Manuale di installazione e funzionamento

Clarke

Clarke Strong-Arm CSA30FPB Manuale di istruzioni

Clarke

Clarke X-Pro CAT202 Manuale di installazione e funzionamento

Clarke

Clarke Woodworker CPT600 Manuale di installazione e funzionamento

Clarke

Clarke CIR18LiC Manuale di installazione e funzionamento

Clarke

Clarke CMFT250 Manuale di installazione e funzionamento

Clarke

Clarke Air CAT120 Manuale di installazione e funzionamento

Clarke

Clarke Contractor CON750 Manuale di istruzioni

Clarke

Clarke CSB34 Manuale di istruzioni

Clarke

Clarke ZX-R Pro Series Manuale di istruzioni

Clarke

Clarke Strong-Arm AHP 26 Manuale di istruzioni

Clarke

Clarke CAT141 Manuale di installazione e funzionamento

Clarke

Clarke Air 25C Manuale di installazione e funzionamento

Manuali Utensili elettrici popolari di altre marche

AEG

AEG OMNI-JS Manuale utente

SIP

SIP 01533 Manuale utente

Ribimex

Ribimex PRS499 Manuale utente

3M Fiber Optic Connector Crimp Tool Manuale utente

Ryobi

Ryobi P524 Manuale utente

ROJEK

ROJEK FSN 300A Manuale utente

Kemper

Kemper 1740PRO Manuale utente

WABCO

WABCO OptiTire Manuale utente

EINHELL

EINHELL TE-MS 18/210 Li Manuale utente

Orgapack

Orgapack OR-T 85 Guida rapida

TOUGHCUT

TOUGHCUT Diamond 400 Manuale utente

Yaros

Yaros PB-3603 Manuale utente

Fein

Fein BSS 2.0 E Guida all'installazione

Baileigh Industrial

Baileigh Industrial SS-2725 Manuale utente

Milwaukee

Milwaukee 2674-20 Manuale utente

Fein

Fein BLs 1.6 Manuale utente

Princess

Princess Electric Multi Sharpener Manuale utente

FOREDOM

FOREDOM K.1050 Manuale
