Clarke Contractor CON15 Manuale di installazione e funzionamento
OPERATING & MAINTENANCE
INSTRUCTIONS GC0309
15 DEGREE COIL NAILER
Model CON15
Part No: 3110295
2
INTRODUCTION
Thank you for purchasing this CLARKE Coil Nailer
Before attempting to operate the machine, it is essential that you read this
manual thoroughly and carefully follow all instructions given. In doing so you
will ensure the safety of yourself and that of others around you, and you can
also look forward to the product giving you long and satisfactory service.
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of
12 months from the date of purchase. Please keep your receipt as proof of
purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
ENVIRONMENTAL PROTECTION
Do not dispose of this product with general household waste. All tools,
accessories and packaging should be sorted, taken to a recycling
centre and disposed of appropriately.
PARTS & SERVICE
For parts & Servicing, please contact your nearest dealer, or
CLARKE International, on one of the following numbers.
PARTS & SERVICE TEL: 020 8988 7400
PARTS & SERVICE FAX: 020 8558 3622
or e-mail as follows:
PARTS: [email protected]
SERVICE: [email protected]
3
OVERVIEW
The CON15 Coil Nailer is suitable for use on softwood, hardwood, plywood,
hardboard, fibreboard or MDF, and will penetrate flexible plastics, leather,
fabrics, PVC & rubber sheet materials. It is not suitable for piercing hard
laminates, brittle plastics or metals (other than light foil).
Unpack and lay out the components, checking against the following list. Any
damage or deficiency should be reported to your Clarke dealer immediately.
• Coil Nailer
• Oil Bottle
• 4 x Hexagonal Keys (3 ,4, 5 & 6mm)
• 1 x Nail Roll
• Black Moulded Case
• Operators Manual (this document)
Your Coil Nailer has been designed to give long and trouble free service. If,
however, having followed the instructions in this booklet carefully, you
encounter problems, take the unit to your local Clarke dealer.
TECHNICAL SPECIFICATION
erutaeF noitacificepS
thgieWgk4
mm)hxwxl(snoisnemiD553x031x033
erusserPriAgnitarepO)rab9.6-8.4(isp001-07
erusserPriA
xaM)rab2.8(isp021
deepSevirDnim/slian003
noitpmusnoCriAdesserpmoCmfc5.6
noitcennoCenilriAelamPSB"4/1
yticapaC
enizagaMslian003
Please note that the details and specifications contained herein, are correct at the
time of going to print. However, CLARKE International reserve the right to change
specifications at any time without prior notice.
4
1. Nail Magazine
2. Drive Pawl
3. Protective Screen
4. Safety Yoke (muzzle)
5. Mode Switch (single/full contact sequential actuation)
6. Trigger
7. Pressure Adjuster
8. Compressed Air Hose Connector
9. Exhaust Deflector
1
2
3
4
9
8
76
5
5
GENERAL SAFETY PRECAUTIONS
WORK AREA
1. ALWAYS Keep the work area clean and well lit. Floors should always be
kept clear. Cluttered or dark areas invite accidents.
2. ALWAYS keep children and bystanders away while operating a power tool.
Distractions can cause loss of control.
PERSONAL SAFETY
1. ALWAYS stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power tool while you are tired
or under the influence of medication, drugs or alcohol. A moment of
inattention can result in personal injury.
2. ALWAYS use safety equipment when operating this tool. Always wear
suitable protective clothing and eye protection including industrial gloves,
ear defenders and approved impact resistant safety glasses. (Eye glasses
are NOT safety glasses)
3. NEVER over-reach. Keep your proper footing and balance at all times to
enable better control of the machine in unexpected situations.
4. NEVER point the tool at anyone or any part of your own body. Keep all
parts of your limbs behind the safety guard at all times.
5. ALWAYS keep a safe distance between yourself and others when using
the tool.
6. NEVER attempt any repairs yourself. If you have a problem with the
machine contact your local Clarke dealer.
7. ALWAYS store power tools out of reach of children.
8. ALWAYS dress properly. Never wear loose clothing or jewellery which could
be caught on moving parts.
GENERAL POWER TOOL USE AND CARE
1. NEVER force or misuse the tool. It will do a better and safer job at the rate
for which it was designed.
2. ALWAYS maintain the tool with care and keep it clean for best / safest
performance.
3. NEVER use this tool if any part is damaged. Have it inspected and repaired
by a competent technician.
4. NEVER modify this tool in any way. Use it ONLY for the purpose for which it
is designed.
5. NEVER carry the tool with your finger on the trigger. The nailer is fitted with
a safety yoke mechanism to prevent accidental firing.
6
6. ALWAYS disconnect the tool from the air supply when not in use, and
before carrying out any maintenance or re-loading with fresh nails.
7. ALWAYS Store the tool out of reach of children.
8. NEVER allow persons unfamiliar with these instructions to operate this tool.
SERVICING
1. ALWAYS have power tools serviced by your Clarke dealer, using only
identical replacement parts. This will ensure the safety of the power tool is
maintained.
COIL NAILER SAFETY INSTRUCTIONS
1. Although the Coil Nailer is water resistant and may be used outdoors, DO
NOT leave it exposed to the elements. Avoid direct sunlight, direct heat,
rain/moisture etc.
2. ALWAYS keep the air hose away from the nailer and ensure that the
operator is not restricted by the length of the hose.
3. ALWAYS take care when a long air hose is required in the work area as it
presents a trip hazard. Coil the hose away as soon as the job is finished.
4. NEVER abuse hoses or connectors. NEVER carry a tool by the hose, or yank
it to disconnect from the air supply. Keep hoses away from heat, oil and
sharp edges. Check hoses for leaks or worn condition before use, and
ensure that all connections are secure.
5. NEVER use with an air supply greater than 8.2 bar (120 PSI).
6. NEVER use any other type of gas such as bottled oxygen or other bottled
gas as a power source to operate this tool. Use compressed air ONLY.
7. NEVER load the tool with the trigger depressed in case of accidental firing.
8. NEVER fire tool at an incline. It must be perpendicular to the work surface.
9. NEVER drive in nails at the edge of a work surface, as the edge could fail
and fly off, endangering yourself or others in the vicinity.
10. ALWAYS take care not to fire a nail into an existing metal fastening in case
the nail should ricochet causing personal injury.
11. NEVER operate the tool unless the safety nose is in contact with the
workpiece, or without any nails or damage to the tool could result.
12. ALWAYS keep hands away from the nose of the tool when connecting to
the compressed air supply.
13. ALWAYS ensure only the correct nails are used, as specified for this tool.
7
THE COMPRESSED AIR SUPPLY
WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU
ARE THOROUGHLY FAMILIAR WITH SAFETY PROCEDURES RELATING TO
THE USE OF COMPRESSORS AND COMPRESSED AIR SUPPLIES.
A filtered, lubricated and regulated air supply will be required as shown in the
layout below.
Ensure the pressure available is within the range of 70-100 psi. Higher pressure
or contaminated air will shorten the tool’s life because of increased wear,
and could be a safety hazard. Higher pressure will also increase the noise
level.
The air inlet used for connecting the air supply has a standard ¼” BSP thread.
For best performance, a quick-fit connector can be used at each end of the
line.
Line pressure, or hose internal diameter should be increased to compensate
for unusually long air hoses (over 10m). Minimum hose diameter should be
6mm (¼”) ID, and fittings should have the same internal dimensions.
Check the quality of the compressed air supply before starting work. Water in
the air line will cause damage to the tool, and a dirty filter will reduce the
available air pressure.
Ensure there are no leaks in any of the connections.
8
LOADING THE COIL NAILER
WARNING: ENSURE THE COMPRESSED AIR SUPPLY IS DISCONNECTED
BEFORE ATTEMPTING TO LOAD THE COIL NAILER. DO NOT HOLD THE
TRIGGER WHILE LOADING THE NAILER.
The machine is loaded with nails as follows:
1. Press the latch (1) open
and pull the magazine
cover (2) back.
2. Knowing the nail size to be
used, raise and twist the
adjuster 90 degrees for the
chosen nail size as
required.
3. Insert a strip of nails into
the magazine, (pointed
end downwards), taking
care that the strip is wound evenly around the centre spigot (3) of the
height adjuster (4). Note that 3 different nail sizes can be used, as indi-
cated by the markings on
the inside of the maga-
zine. The sizes available
are listed on page 12.
4. Take care when handling
the nails, that they do not
become bound together.
1 2
3 4
9
5. Offer the end of the strip of
nails into the gun, taking
care that the nail heads lay
flat in the groove (5) closest
to the machine body and
that the first nail in the strip is
resting in the drive pawl (6).
6. Close the magazine cover
and close the latch.
• This will not be possible if the
nails are not positioned
correctly. The machine is
now ready to use.
6 5
OPERATION
1. Connect the nailer to the air
supply. With the air supply
turned OFF, connect the air
line to the ¼” BSP connector.
(A Whip Hose with quick-fit
coupling is available from
your Clarke dealer).
2. Turn ON the air supply.
• Check for air leaks. If any are
apparent, rectify before
proceeding.
3. Ensure the operating pressure
is set to between 70-100psi .
This may be adjusted,
dependant upon the density of the workpiece. The harder the target
material, the higher the air pressure required. e.g. When nailing into
softwoods, a pressure of only 70psi may be all that is required.
Quick release Airline Connection
NEVER OPERATE THE TOOL UNLESS THE SAFETY YOKE IS IN CONTACT
WITH THE WORKPIECE, OR WITHOUT ANY NAILS OR DAMAGE TO THE
TOOL COULD RESULT.
10
4. Before starting work, test the
nailer on a piece of scrap
wood to check that the driving
depth is correct. If the nails are
being driven too far or not
deep enough into the timber,
adjust the air pressure adjuster
located on the side of the nose
section accordingly.
(Remember; whatever pressure
adjustment is to be carried out
on the tool is dependant upon
the pressure received from the
airline).
5. Hold the tool so that it is at
right angles to the workpiece.
Lower it so that the yoke
contacts the work surface
and with a slight downwards
pressure, pull the trigger to
drive in the nail.
6. The machine is equipped with
a switch that can change the
operating mode from single
shot to sequential shots. When
the red switch is pointing
towards the operator, the coil
nailer will fire a single nail only.
To fire the next nail the trigger
must be released. When the
switch is pointing away from the
operator, the nailer can fire
sequentially.
7. An adjustable exhaust deflector
is fitted. Turn the deflector into
any chosen position to avoid
the blast from the exhaust.
CLEARING A JAM
Should the coil nailer jam; for example, with the last nail of a batch,
disconnect the air supply and pull the trigger to ensure the air line is not under
pressure. Open the magazine and latch and clear the jam before re-loading.
Deflector
Pressure adjuster
Trigger Mode Switch
Indice
Altri manuali Clarke Utensili elettrici
Clarke
Clarke X-Pro CAT205 Manuale di installazione e funzionamento
Clarke
Clarke Air CSG3KC Manuale di installazione e funzionamento
Clarke
Clarke Woodworker CBM1-C Manuale di installazione e funzionamento
Clarke
Clarke Air CAT149 Manuale di installazione e funzionamento
Clarke
Clarke Woodworker CPT600 Manuale di installazione e funzionamento
Clarke
Clarke CPSB100 Manuale di istruzioni
Clarke
Clarke CHG1500D Manuale utente
Clarke
Clarke CPSB200B Manuale di istruzioni
Clarke
Clarke CAT52 Manuale di installazione e funzionamento
Clarke
Clarke Metalworker CDP350V Manuale di installazione e funzionamento
Clarke
Clarke CSB34 Manuale di istruzioni
Clarke
Clarke CRT 40 Manuale utente
Clarke
Clarke Strong-Arm AP500B Manuale utente
Clarke
Clarke CAT209 Manuale di installazione e funzionamento
Clarke
Clarke CBM 2 Manuale di installazione e funzionamento
Clarke
Clarke STRONG-ARM CSA12F Manuale di istruzioni
Clarke
Clarke STRONG-ARM CSA10BB Manuale di istruzioni
Clarke
Clarke CTILG 5060287 Istruzioni per l'installazione
Clarke
Clarke cp185 Manuale di installazione e funzionamento
Clarke
Clarke CMFT250 Manuale di installazione e funzionamento
