Clarke CAX3TBC Manuale utente

INSTRUCTIONS

LS0216

3 TONNE AXLE STAND

MODEL NO: CAX3TBC

PART NO: 7600060

CAX3TBC 3 Tonne folding axle stand.fm Page 1 Thursday, February 11, 2016 11:22 AM

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

CAX3TBC 3 Tonne folding axle stand.fm Page 2 Thursday, February 11, 2016 11:22 AM

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt which will be

required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or

tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission.

This guarantee does not effect your statutory rights

WARNING LABELS

The following WARNING label is attached to each stand and should be

replaced if it becomes damaged

SPECIFICATION

Maximum Height 430 mm

Minimum Height 300 mm

Maximum Load 3000 kg per pair or 1500 kg per stand

Product Weight 6 kg per pair

CAX3TBC 3 Tonne folding axle stand.fm Page 3 Thursday, February 11, 2016 11:22 AM

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

SAFETY WARNINGS

• Read these instructions carefully before use.

• Do not exceed the axle stands maximum

load (1500 kg each / 3000 kg per pair), The

vehicle weight will be stated in the owners

manual.

• Use only as specified in this manual.

• NEVER let children play in or around a vehicle

that is on axle stands.

• ALWAYS make sure that before you work

below the vehicle, a responsible person is

aware in case of injury or accident.

• Do not use more than one pair of axle stands.

• Replace the warning label if it becomes

unreadable.

• Use only on a hard, flat surface, for example

concrete.

• Make sure that you chock all the wheels that

remain on the ground.

• Make sure that the supported vehicle cannot

move.

• Set each axle stand below an appropriate

point on the vehicle - See your vehicle

owners manual for advice.

• Take care when using the axle stands on a

three-wheeled vehicle or trailer.

• Use stands as a matched pair to support one

end of a vehicle only.

• For your safety, do not modify these axle stands.

WARNING: NEVER WORK UNDER A VEHICLE SUPPORTED ONLY BY A JACK.

WARNING: AFTER LIFTING THE VEHICLE, SUPPORT IMMEDIATELY WITH

PROPERLY RATED AXLE STANDS

CAX3TBC 3 Tonne folding axle stand.fm Page 4 Thursday, February 11, 2016 11:22 AM

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

ASSEMBLY

1. Insert the adjustable axle support

into the body of the stand as

shown. To do this, simply raise the

handle as far as possible and

slowly lower the support into the

body with the teeth facing away

from the handle.

2. To prevent the support from

coming out off the stand each

time the stand is picked up by the

support, the tab (Fig. 1 Inset)

requires reforming. This can be

carried out as follows.

• Lay the axle stand on a firm

surface with the tab facing

upwards.

• Insert a suitable flat bladed

screwdriver into the aperture as

shown in Fig.2. Carefully apply a

firm downwards pressure, bending

the tab inwards.

• Only bend the tab sufficiently to

act as a stop for the support.

3. If the tab requires further bending

use an open ended spanner

(13mm approx) as shown in Fig. 3.

4. Again push down on the spanner

until the tab is sufficiently formed.

5. The axle stand is now complete

and ready to be used.

NOTE: When forming the tab, DO

NOT OVERBEND it, bending

the tab too much could

cause it to foul the axle support and prevent it from functioning

correctly.

FIG. 1

FIG. 2

FIG. 3

CAX3TBC 3 Tonne folding axle stand.fm Page 5 Thursday, February 11, 2016 11:22 AM

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

USING THE AXLE STANDS

1. Refer to the vehicle handbook for the correct jacking procedure and

location of the support points.

2. Raise the vehicle using a suitable lifting jack.

ADJUST THE AXLE STAND

3. Raise the saddle on the axle stand to the required height.

•Make sure the ratchet mechanism is fully engaged.

4. Position the axle stand under a suitable supporting point. See your vehicle

manual for the location.

LOWERING THE VEHICLE

1. Slowly lower the vehicle onto the centre of the saddle.

TO REMOVE THE AXLE STANDS

1. Raise vehicle clear of the axle stands.

2. Remove stands.

3. Ensure that all tools, equipment and personnel are clear before carefully

lowering the vehicle to the ground.

WARNING: BEFORE USE, MAKE SURE THAT THERE IS NO DAMAGE TO ANY

PART OF THE AXLE STAND, IF THERE IS, DO NOT USE.

WARNING: DO NOT EXCEED THE RATED LOAD OF 3000 KG PER PAIR OR

1500 KG PER STAND.

WARNING: USE ONLY ON A HARD, FLAT SURFACE, E.G. CONCRETE.

WARNING: DO NOT LOAD THE STANDS OFF CENTRE. FAILURE TO HEED THIS

WARNING MAY CAUSE DAMAGE, INJURY OR LOSS OF LIFE.
