USER INSTRUCTIONS

ORIGINAL INSTRUCTIONS GC0821 rev 1

ALUMINIUM AXLE STANDS (PAIR)

MODEL NO: CAX3TAB

PART NO: 7600035

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

SAFETY WARNINGS

•Read these instructions carefully before

use.

• Do not exceed the axle stands maximum

load (1.5 tonne each / 3 tonne per pair),

The vehicle weight will be stated in the

owners manual.

• Use only as specified in this manual.

• NEVER let children play in or around a

vehicle that is on axle stands.

• ALWAYS make sure that before you work

below the vehicle, a responsible person is

aware in case of injury or accident.

• Do not use more than one pair of axle

stands.

• Replace the warning label if it becomes

unreadable.

• Use only on a hard, flat surface, for

example concrete.

• Make sure that you chock all the wheels

that remain on the ground.

• Make sure that the supported vehicle

cannot move.

• Set each axle stand below an

appropriate strong point on the vehicle -

See your vehicle owners manual for

advice.

• Take care when using the axle stands on

a three-wheeled vehicle or trailer.

• Use stands as a matched pair to support

one end of a vehicle only.

• For your safety, never attempt to modify

these axle stands.

WARNING: NEVER WORK UNDER A VEHICLE SUPPORTED ONLY BY A JACK.

WARNING: AFTER LIFTING THE VEHICLE, SUPPORT IMMEDIATELY WITH

PROPERLY RATED AXLE STANDS.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

ASSEMBLY

1. Slide the lower column into the

base.

2. Secure in place using the spring

washer and bolt as shown on the

right.

USING THE AXLE STANDS

1. Refer to the vehicle handbook for the

correct jacking procedure and

location of support points.

2. Raise the vehicle using a suitable lifting

jack.

ADJUSTING THE AXLE STANDS

1. Remove the locking pin (if fitted).

2. Raise the upper column to the

required height and replace the

locking pin.

3. Position the axle stand under a

suitable supporting point. See your

vehicle manual for the location.

WARNING: BEFORE USE, MAKE SURE THAT THERE IS NO DAMAGE TO ANY

PART OF THE AXLE STAND, IF THERE IS, DO NOT USE.

WARNING: DO NOT EXCEED THE RATED LOAD OF 3 TONNE PER PAIR OR

1.5 TONNE PER STAND.

WARNING: IT MUST BE ENSURED THAT THE VEHICLE/LOAD IS CAREFULLY

LOCATED ONTO THE CENTRE OF THE AXLE STAND SADDLE. FAILURE TO DO

THIS CAN RESULT IN DAMAGE TO THE AXLE STANDS, LOSS OF SUPPORT TO

THE LOAD, SERIOUS PERSONAL INJURY OR LOSS OF LIFE.

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

LOWERING THE VEHICLE

1. Slowly lower the vehicle onto the centre of the saddle.

REMOVING THE AXLE STANDS

1. Raise vehicle clear of the axle stands.

2. Remove stands.

3. Ensure that all tools, equipment and personnel are clear before carefully

lowering the vehicle to the ground.

SPECIFICATION

WARNING: DO NOT LOAD THE STANDS OFF CENTRE. FAILURE TO HEED THIS

WARNING MAY CAUSE DAMAGE, INJURY OR LOSS OF LIFE.

Maximum Height 396 mm

Minimum Height 271 mm

Maximum Load 3 tonne (3000 kg) per pair or 1.5 tonne

(1500 kg) per stand

Product Weight 4.55 kg per pair
