Clarus Technologies PCS-25 Manuale utente

PCS-25/WCS-25,

PCS-15

Cleaning Stations

Operators Manual

Manufactured by:

Clarus Technologies, LLC

2015 Alpine Way, Suite C

Bellingham, WA 98226

(360) 715-1356

Revision Date 2/12

Table of Contents

I. INTRODUCTION ............................................................................................................................. 4

II. SPECIFICATIONS .......................................................................................................................... 4

III. WARRANTY INFORMATION...................................................................................................... 5

IV. SAFETY ............................................................................................................................................ 6

A. SAFETY WARNINGS........................................................................................................................... 6

B. SAFETY EQUIPMENT.......................................................................................................................... 7

V. QUICK START GUIDE................................................................................................................... 7

A. UNCRATE UNIT................................................................................................................................. 7

B. INSTALL LIGHT BAR.......................................................................................................................... 7

C. ESTABLISH WORK AREA................................................................................................................... 7

D. FILL UNIT WITH SOLVENT ................................................................................................................. 8

VI. PARTS DESCRIPTION & OPERATION ...................................................................................... 8

A. ON-BUTTON...................................................................................................................................... 8

B. LIGHT SWITCH. ................................................................................................................................. 8

C. CLEANING BRUSH............................................................................................................................. 8

D. OPTIONAL EQUIPMENT...................................................................................................................... 8

E. FLUID NOZZLE –SHUTOFF................................................................................................................. 9

F. FILTER DIFFERENTIAL PRESSURE GAUGE.......................................................................................... 9

G. FUSIBLE LINK.................................................................................................................................... 9

J. LEVELING BOLTS............................................................................................................................. 10

VII. CARE AND MAINTENANCE...................................................................................................... 10

A. SUMP MAINTENANCE...................................................................................................................... 10

B. CANISTER LID O-RING MAINTENANCE............................................................................................ 10

C. CHANGING FILTERS......................................................................................................................... 10

D. REPLACEMENT PARTS..................................................................................................................... 11

VIII. DISPOSAL OF WASTE OIL AND BY-PRODUCTS................................................................. 12

A. SOLVENT AND SLUDGE................................................................................................................... 12

B. FILTER DISPOSAL............................................................................................................................ 13

IX. TROUBLE-SHOOTING................................................................................................................ 13

A. LIGHT DOESN’T WORK:.................................................................................................................... 13

B. FUSIBLE LINK DOESN’T LINE-UP WITH TAB ON LID:.......................................................................... 13

C. AIR GUN HAS LOW PRESSURE OR DOESN’T WORK: .......................................................................... 13

D. SOAK TANK PUMP DOESN’T WORK: ................................................................................................ 13

E. WAND/BRUSH LEAKING OR DRIPS:.................................................................................................. 13

F. CANISTER LIDS DIFFICULT TO REMOVE AND INSTALL:..................................................................... 14

G. SIGHT GLASS DIRTY OR CLOGGED:.................................................................................................. 14

H. MAIN PUMP NOT RUNNING:............................................................................................................. 14

I. PUMP RUNNING BUT NOT PUMPING FLUID: ....................................................................................... 14

J. MAIN PUMP LEAKING: ..................................................................................................................... 14

K. SLUDGE PUMP LEAKING:................................................................................................................. 14

L. PLUMBING LEAKING:....................................................................................................................... 14

M. NO POWER MAIN PUMP,LIGHT,SOAK TANK PUMP DO NOT WORK:................................................ 14

FOREWORD

1. This manual describes the procedures required to operate the Clarus PARTS

WASHER. Every effort has been made by Clarus Technologies, LLC to assure the

accuracy and reliability of the information contained in this document. Clarus

Technologies, LLC, however, makes no representation, warranty, or guarantee in

connection with this manual and hereby expressly disclaims any liability or

responsibility for loss or damage resulting from its use or for the violation of any

federal, state, provincial or municipal regulation with which this publication may

conflict.

2. The electrical components of the Clarus Parts Washer have been designed and

assembled with UL approved equipment where required.

WARNING! The operational techniques used with this equipment are more

important than the design of the equipment for the safety of the worker.

Therefore, each technician involved in the operation of the Clarus Parts

Washer Cleaning Station must have the proper hazardous materials training.

DANGER! This system can only be used with solvent that has a minimum

flashpoint of 140 Fahrenheit. Use of solvents with flashpoints lower than 140

Fahrenheit are likely to cause a fire, Injuries or death. If you are not sure of a

solvents flashpoint refer to the appropriate MSDS sheet.

3. Clarus is not undertaking to meet the duties of employers to warn and properly train

and equip their employees, and others exposed, concerning health and safety risks

and precautions, nor undertaking their obligations under local, state, provincial or

federal laws.

4. Information concerning safety and health risks and proper precautions with respect to

particular materials and conditions should be obtained from the employer, the

manufacturer or supplier of that material, or the Material Safety Data Sheet

(“MSDS”).

CLARUS PARTS WASHER

OPERATOR’S MANUAL

I. INTRODUCTION

Congratulations on your purchase of the Clarus PCS-25/WCS-25/PCS-15 Parts Cleaning

Stations! These Parts Washers are products of Clarus engineering and manufacturing.

They are made of the finest materials under a rigid quality control system. With proper

care they will give you long and satisfactory service.

To obtain the best use of your Parts Washers, please read this manual carefully. It will

help you become familiar with the operation of the equipment and contains many helpful

hints about Parts Washer maintenance.

The instructions and specifications contained in this manual were in effect as of

February 2000. Due to the policy of Clarus Technologies, LLC to continually improve

its products, however, modifications in these specifications may be made at any time.

This Operators Manual was compiled for your benefit. By reading and following the

safety, setup, operation, and trouble-shooting instructions described in the manual, you

should receive many years of trouble-free operation. Familiarize yourself with the

names of the Parts Washer components, which appear as capitalized terms throughout

this manual. Read this entire manual before attempting to start and operate the

Clarus Parts Washer.

II. SPECIFICATIONS

SPECIFICATIONS –PCS-25/WCS-25 –PCS-15



Large format tank that uses 27.5 gallons of solvent, half the amount used in typical systems



Height/width/depth (inches) - 44/51/31 (Height to top of light 73”)



150-watt halogen light



Single phase, 110V, 60 Hz, 5A



Dual canister high capacity filtration



Ultra fine 0.5-micron particulate filtration



Oven-baked polyester powder coat finish



High quality steel construction with stainless steel work surface



Two brushes on WCS-25, brush and flexible gooseneck nozzle on PCS-25



Bright stainless steel work surface for better visibility and no darkening from corrosion



Patent pending sump configuration for efficient sludge removal



On-board pump for easy removal of sludge and to minimize service requirements



Fluid level gauge with indicator for “Add 5 gallons” of make-up fluid



Leveling feet



Pressure gauge shows status of filter and when filter change out is needed



Instructions describing all operational procedures are provided on clearly marked decals



Constant flow system regardless of how clogged the filters are



Filter canisters inside tank provide spill containment during filter change-outs



Built-in automatic shut-off after four minutes of operation extends solvent/system life



UL approved fusible link for fire protection



Consistently clean solvent not reliant on service intervals



Optional pre-clean shelf



Optional air gun for blowing parts clean and dry



Optional tank with agitation pump for soaking parts



System can be moved with forklift or pallet jack even while full



Limited Lifetime Warranty

SPECIFICATIONS –PCS-15



Small format tank that uses 17.5 gallons of solvent, half the amount used in typical systems



Height/width/depth (inches) –43/38/26 (height to top of light 73”)



150-watt halogen light



Single phase, 110V, 60 Hz, 5A



Single canister high capacity filtration



0.5-micron particulate filtration



Oven-baked polyester powder coat finish



High quality steel construction



Brush and flexible gooseneck nozzle



Bright stainless steel work surface for better visibility and no darkening from corrosion



Patent pending sump configuration for efficient sludge removal



On-board pump for easy removal of sludge and to minimize service requirements



Leveling feet



Fluid level gauge with indicator for “Add 5 gallons” of make-up fluid



Instructions describing all operational procedures are provided on clearly marked decals



Pressure gauge shows status of filter and when filter change-out is needed



Constant flow system regardless of how clogged filter is



Filter canister inside tank provides spill containment during filter change-outs



Built-in automatic shut-off after four minutes of operation extends solvent/system life



System can be moved with forklift or pallet jack even while full



UL approved fusible link for fire protection



Consistently clean solvent not reliant on service intervals



Optional air gun with shop air regulator for blowing parts clean and dry



Optional tank with agitation pump for soaking parts



Optional pre-clean shelf



Limited Lifetime Warranty

III. WARRANTY INFORMATION

Clarus Technologies, LLC, will for the life of the unit, repair or replace without charge,

parts which our examination proves to be defective in material or workmanship. This

warranty is valid only if the unit has not been tampered with by unauthorized persons,

misused, abused, or improperly installed and has been used in accordance with the

instructions and/or ratings supplied. The foregoing is in lieu of any other warranty or

guarantee expressed or implied, and we are not responsible for any expense (including

installation and removal), inconvenience, or consequential damage, including injury to

any person, caused by items or our manufacture or sale. Some states do not allow

certain exclusion or limitations found in this warranty so that they may not apply to you.

In any event, Clarus Technologies, LLC total liability, under all circumstances, shall not

exceed the full replacement cost of this unit.

This Limited Lifetime Parts Warranty is limited to the following components:

Main chassis

Tank lid

Light bar assembly (excluding light fixture and light bulb)

Stainless steel work surface

Stainless steel baffle system

Soak Tank

Clarus Technologies, LLC, will for the period of 1 year from the date of purchase, repair

or replace without charge, the items listed below which our examination proves to be

defective in material or workmanship. This warranty is valid only if the unit has not been

tampered with by unauthorized persons, misused, abused, or improperly installed and

has been used in accordance with the instructions and/or ratings supplied.

This 1 year Mechanical/Electrical Component Warranty covers the following

components:

Electrical control systems

Main pump

Agitation pump

Hand pump

NOTE: Consumable items such as light bulbs, solvent brushes, O-Rings and

filters are excluded from any such warranty.

IV. SAFETY

To safely operate the Clarus Parts Washer, it is essential to know the proper safety

procedures and equipment.

A. Safety Warnings.

The definitions for the safety warnings used throughout this manual are as follows:

Warning Means that if the safety information is not followed, personnel,

equipment or the environment may be damaged or hurt.

Material Safety Data Sheets (MSDS)

The MSDS provides technical information regarding use, hazards, precautions and

emergency procedures related to specific fluids. The MSDS also contain toll-free phone

numbers that may be called to provide further safety and emergency treatment

information.

Operators of the Clarus Parts Washer must have on hand an MSDS for each type

of solvent that they will be using. The MSDS are available from the solvent supplier.

In some localities it is required by law that appropriate MSDS are on hand whenever

hazardous or flammable material is being processed.

B. Safety Equipment.

1. Safety Glasses. Operators should wear safety glasses during the operation of the

Parts Washer. The major hazard is the possibility of splashing petroleum-based

fluids into the eye. If petroleum-based fluid is splashed into the eye, severe

damage may occur. First Aid treatment should be initiated immediately. Refer

to MSDS.

2. Protective Gloves. Appropriate protective gloves should be worn whenever there

is a possibility that the fluids being used may come into contact with the hands.

Different types of gloves may be required for differently types of fluids. The

local safety supply source can recommend the appropriate protective gloves.

3. Flammable. For the safety of owners and operators NO SMOKING around or

near this equipment.

V. QUICK START GUIDE

Please read entire Quick Start Guide before beginning, this will avoid possible start up

problems.

A. Uncrate Unit

1. Remove outer wrap.

2. Unbolt legs from pallet.

3. Remove Light Bar from packaging.

4. Remove all loose packing.

B. Install Light Bar

To install the light bar, attach it to the “Light Bar Bracket” located on the

center/backside of the Parts Washer unit. Nuts and bolts have been provided. Before

tightening the bolts, open the tank lid and secure it to the light bar fusible link. Do not

bend the fusible link. Tighten all bolts. Once the light bar is secured, connect the male

plug of the light bar to the female plug labeled “light bar” out of the electrical box.

C. Establish Work Area

1. Create a properly sized area for the Parts Washer to be located in. This area

should be a level, solid working area with sufficient overhead room for the light

bar. A 110 volt 15 amp circuit should be within 6 feet of this area.

2. Place the Parts Washer in working area with a forklift or pallet jack with front of

unit facing out.

3. Use front leveling feet to reduce any rocking from an uneven floor. The leveling

feet should not be used to raise the unit off the floor. Use Bubble level to level

Front/Back and Left/Right.

D. Fill Unit with Solvent

1. Once the unit is set in place, leveled and plugged in, you can fill it with solvent.

PCS-15 Parts Cleaning Stations require 17.5 gallons of solvent. PCS-25 and

WCS-25 Parts Cleaning Stations require 27.5 gallons of solvent. (NOTE! Fill

Parts Washer until fluid level gauge located on front, left corner reads full.)

2. Make sure both the cleaning bush and fluid nozzle are inside the tank before

turning the system on. Turn system on by depressing green “ON” button.

3. When unit automatically shuts off (approximately 4 minutes) check fluid level

and fill to full line.

Congratulations –your unit is ready!

VI. PARTS DESCRIPTION & OPERATION

A. On-Button.

To turn the Parts Washer on, simply depress the green “ON” switch once. This will turn

the system on for a 4-minute cycle. When the cycle is over the system will shut off

automatically. If continued operation is needed, simply depress the green “ON” button

again.

B. Light Switch.

The light switch on the control panel operates the overhead 150-watt halogen light. The

light does not automatically switch off, so the operator must manually turn the light off.

C. Cleaning Brush.

This ergonomically designed Parts Cleaning brush self cleans during use.

D. Optional Equipment.

The PCS-25/WCS-25/PCS-15 Cleaning Stations come with various options. The

following describe the operation of these options, however, not all units are equipped

with the same option packages.

Air Tool with Air Pump:

If the optional Air Tool with Air Pump was purchased for your Parts Washer, you

will have an air nozzle/handle hanging on the inside of the Parts Washer lid and

an on/off switch labeled “Air Tool”. To activate the air tool first turn the switch

to “ON”, this will start the compressor. Next, take hold of the Air Tool, point it

down and away from your body and depress the trigger on the handle. This will

release the pressurized air for use with the Parts Washer.

Regulated Shop Air Operated Air Tool:

If the optional regulated “Shop Air” model was purchased, hook up the Shop Air

Hose to the air regulator located on the backside of the lower shelf. Manually

adjust the amount of air needed by pulling up the knob on the regulator and

turning it to the appropriate setting. When the proper amount of air is achieved,

push knob down to lock your setting. With this set-up, air will always be

available at the nozzle.

Agitation Tank/Pump Assembly:

The PCS-25 and PCS-15 come with an optional stainless steel soak tank (“Soak

Tank”) and a UL approved submersible agitation pump. The “on/off” switch for

the Soak Tank is located on the lower left hand corner of the lid.

Prior to turning the agitation tank on:

1) Place the stainless steel tank along the left hand side wall of the working surface,

2) Turn the PCS-25/PCS-15 on by depressing the green “on” switch.

3) As the solvent begins to flow, use the cleaning brush and/or nozzle to fill the

stainless steel soak tank until it covers the pump.

4) Once the soak tank is full you can turn on the pump. The agitation pump will

stay on until it is manually turned off.

E. Fluid Nozzle –shutoff.

The fluid nozzle flow can be adjusted or turned off by turning the yellow valve handle at

the nozzle’s base.

F. Filter Differential Pressure Gauge.

The PCS-25/WCS-25 model and the PCS-15 use a pressure gauge to indicate when the

filters need replacing. Replace filters when the gauge reads 40 PSI. Operating system

beyond 40 PSI will not damage the unit, however, the quality of the solvent will degrade

beyond 40 PSI.

G. Fusible Link.

The OSHA Regulated Fusible Link that holds the lid open will release the lid if the

ambient temperature reaches 165F. Never bend the Fusible Link, as it will weaken it.

WARNING! Do not coat or paint fusible link as this may prevent proper

operation. Inspect fusible link annually and replace if corrosion and/or stress is

evident.

J. Leveling Bolts.

The front two legs contain bolts, which are used to minimize any rocking from uneven

floors, and will aid in leveling the unit. The unit must be level to work properly.

VII. CARE AND MAINTENANCE

A. Sump Maintenance.

From time to time the sump of the Parts Washer needs to be pumped clean. The interval

depends on usage. For motor pools this interval is 3-6 months. For weapons cleaning

this interval is 6 months to 1 year. To dump the sump, first remove the hose on the front

right side of the unit, remove the cap and put it either in a bucket or barrel and turn the

hose end valve on. Second, open the yellow valve handle on the main shelf. Third,

move the handle back and forth on the sump pump located on the shelf. Pump the sump

out till the solvent changes color. This usually takes 2-5 gallons. Turn off hose end

valve, yellow handle valve, replace cap and return it to its hangar. Dispose of waste

properly.

B. Canister Lid O-Ring Maintenance

Every time the filters are changed, smear a small amount of petroleum jelly around the

o-ring to keep it lubricated.

WARNING! ALWAYS WEAR GLOVES AND EYE PROTECTION WHEN

HANDLING SOLVENT OR FILTERS.

WARNING! When changing filters, make sure to have something underneath the

used filter as you move it, such as a bucket or oilsorb, to capture any incidental

drips.

C. Changing Filters.

The PCS-25/WCS-25/PCS-15 comes equipped with one or two 5” X 18” filter canisters.

Inside these canisters are 4.5” X 17” filter cartridges. These filters need to be changed

when indicated by the filter status lights or by a 40 PSI reading on the pressure gauge

mounted on the filter canisters. When the gauge or lights indicate a filter change is

needed please follow these steps:

1. Turn all power to the system off.

2. Unplug the unit from wall receptacle.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Clarus Technologies Attrezzature per la pulizia

Clarus Technologies

Clarus Technologies PCS-35 Manuale utente

Manuali Attrezzature per la pulizia popolari di altre marche

Skov

Skov Farm AirClean Manuale

Nilfisk-Advance

Nilfisk-Advance CA 240 Manuale utente

ORBOT

ORBOT LiO Manuale utente

unGer

unGer OmniClean Manuale utente

CENTREGO

CENTREGO Toucan Eco Bio Carry Manuale utente

BANDELIN

BANDELIN SONOREX TECHNIK RM 110 UH Manuale utente

Sealey

Sealey VMA913 Manuale utente

Aztec

Aztec 520-00 Manuale utente

BÖWE

BÖWE P25 Manuale utente

Tunap

Tunap MF 929 Istruzioni per l'uso e l'installazione

RIDGID

RIDGID K-45AF-7 Manuale utente

Aircraft

Aircraft POWERGLIDE Manuale utente

Suevia

Suevia 130.5011 EASYCLEANER Manuale utente

Streamline

Streamline Filterplus MOBI SK Manuale utente

Thermax

Thermax AF2 Manuale utente

IPC

IPC CT15R Manuale utente

i-MO

i-MO Öko 2000 Manuale utente

unGer

unGer Hydro Power Ultra UNP01 Manuale utente
