Clearfield FieldSmart 24 Manuale utente
FieldSmart®Fiber Distribution Point (FDP)
24 & 48 Port Outdoor Wall Box
Installation Manual ____________________________________________________
Manual 020012 REV A - Aug 2018
Direct: 763.476.6866 • National: 800.422.2537 • www.SeeCleareld.com • [email protected]
2
FieldSmart®Fiber Distribution Point (FDP)
24 & 48 Port Outdoor Wall Box
Installation Manual ______________________________________________________
Manual 020012 REV A - Aug 2018
Table of Contents
Application 3
Description 3
Technical Specications 3
Outdoor Wall Box Components 4
Wall Box Installation 5
Wall Box Access 6
Cable Preparation and Installation 7
Grounding 9
Fiber Splicing 10
Jumper Installation 12
Connector Cleaning Procedure 14
Standard Warranty 17
Proprietary Notice 18
Technical Support 18
3
FieldSmart®Fiber Distribution Point (FDP)
24 & 48 Port Outdoor Wall Box
________________________________________________________Installation Manual
Direct: 763.476.6866 • National: 800.422.2537 • www.SeeCleareld.com • [email protected]
Manual 020012 REV A - Aug 2018
Technical Specications
Description
Application
24 Port Outdoor Wall Box 48 Port Outdoor Wall Box
Dimensions 12.52” H x 16.22” W x 5.75” D 12.52” H x 18.92” W x 7.26” D
Port Density Up to 24 ports Up to 48 ports
Cassette Types
Supported Clearview Blue
Connector Types SC/UPC, SC/APC, LC/UPC, LC/APC, FC/UPC, FC/APC, ST/UPC, MPO
Cable Types Indoor/Outdoor, Outdoor (Riser/Non-Rated), Outdoor Armored (Riser/Non-Rated)
Splice Capacity 12 or 24 splice congurations in each Clearview Cassette
Storage Capacity One meter of 900 μm ber and up to 20 feet buffer tube
Material 16 gauge cold rolled steel (zinc chromate with almond powder coating)
The FieldSmart FDP 24 and 48 Port Outdoor Wall Boxes are
ideal for both residential MDUs and business-class
environments. Congurable for either patch only, patch and
splice (Cleareld’s in-cassette splicing solution) or MPO
plug-and-play, Outdoor Wall Boxes support all cable scenarios
for the outside plant. The OSP platform is designed for the
harshest environments, supporting NEMA 4 performance
requirements, while providing conduit entry through eld-
deployed knock-outs on both the rear and bottom of the unit.
Additional applications include ber demarcations, entrance
facilities, and security systems (CCTV).
Designed from conception to provide fast and easy ber jumper routing with ease of access to all circuits, the FieldSmart
FDP Outdoor 24 and 48 Port Wall Boxes are craft-friendly, keeping the installer’s needs for quick deployment, intuitive use
and ease of maintenance as the top priorities. Utilizing the Clearview® Cassette, the box easily scale from 12 to 48 ports
with the industry standard adapter of choice. Ring cut or mid-span capabilities allow distribution cables to be daisy-chained
and for ber hand-off through the riser, while a swinging bulkhead provides rear-access to cassettes and protects sub-unit
slack storage. With lockable doors for added protection and a solid enclosure design to protect ber terminations from
damage, the FieldSmart Fiber Delivery Point (FDP) Wall Box product line provides superior ber management for outdoor
environments.
Direct: 763.476.6866 • National: 800.422.2537 • www.SeeCleareld.com • [email protected]
4
FieldSmart®Fiber Distribution Point (FDP)
24 & 48 Port Outdoor Wall Box
Installation Manual ______________________________________________________
Manual 020012 REV A - Aug 2018
Outdoor Wall Box Components
1. Can Wrench Accesible Security Doors
2. 2” Conduit Opening
3. Slack Storage for Incoming Jumpers
4. Port Designation Card
5. Weather Tight Seal
6. Clearview Blue Cassettes (Left Exit for
Patch and Splice)
7. Buffer Tube Slack Storage Area
8. Optional Padlock Location
45
6
2 3
1
7
8
5
FieldSmart®Fiber Distribution Point (FDP)
24 & 48 Port Outdoor Wall Box
________________________________________________________Installation Manual
Direct: 763.476.6866 • National: 800.422.2537 • www.SeeCleareld.com • [email protected]
Manual 020012 REV A - Aug 2018
Wall Box Installation
The wall box is installed via the 4 holes located on the tabs on
each corner of the rear of the enclosure.
Hold the wall box up to the mounting surface and mark the hole
locations with a marker.
Note: A level may be used to ensure that the wall box is
mounted straight.
Pilot holes can then be drilled at each mark. Using appropriate fasteners for the material, attach the wall box to the surface.
Direct: 763.476.6866 • National: 800.422.2537 • www.SeeCleareld.com • [email protected]
6
FieldSmart®Fiber Distribution Point (FDP)
24 & 48 Port Outdoor Wall Box
Installation Manual ______________________________________________________
Manual 020012 REV A - Aug 2018
Wall Box Access
The interior of the wall box can be accessed by loosening the security screws on each of the two doors using a 7/16” thin
wall socket or a telecommunications industry “can wrench”.
The cassette splicing area can then be accessed by loosening the security on the secondary internal door.
7
FieldSmart®Fiber Distribution Point (FDP)
24 & 48 Port Outdoor Wall Box
________________________________________________________Installation Manual
Direct: 763.476.6866 • National: 800.422.2537 • www.SeeCleareld.com • [email protected]
Manual 020012 REV A - Aug 2018
Cable Preparation and Installation
The slack storage compartment of the wall box is large
enough to accommodate more buffer tube than would
typically be used in this application. It is recommended,
however, that you only prep as much cable as you will
need to perform your work.
Included in each wall box are 2 liquid tight ttings (sealcons) and an assortment of rubber inserts (grommets). Choose
the insert that is close to, but larger than, the size of the cable.
Compression Fitting Grommet Cable Size (Inches)
Small Black Grommet 0.3 - 0.4
Medium Black Grommet 0.41 - 0.5
Gray Grommet 0.51 - 0.79
In order to swap grommets,
remove the dome nut from the
sealcon and pry the current
grommet out, being careful not
to damage the compression
tting. Push the new one in to
place. Ensure new grommets
are installed with the tapered
side up (see pictures).
Note: It is sometimes easier to
remove the grommet by using
a blunt ended tool to push at it
from the bottom, inside the seal-
con. Take care not to damage
the grommet.
21
654
3
Note: You will need approximately 3 feet of ber inside the
splice tray so add that to the total prep length.
1.
2.
3.
Direct: 763.476.6866 • National: 800.422.2537 • www.SeeCleareld.com • [email protected]
8
FieldSmart®Fiber Distribution Point (FDP)
24 & 48 Port Outdoor Wall Box
Installation Manual ______________________________________________________
Manual 020012 REV A - Aug 2018
Ensure the O-ring on the underside of the sealcon is present before
installation.
O-Ring
The sealcon can then be installed by inserting the thread through the bottom of the wall box and securing with the
included lock nut. (Figure 1)
Note: The optional strength member clamp is shown in this picture.
The stripped cable can then be inserted into the sealcon. (Figure 2)
Note: If utilizing the strength member clamp, leave enough strength member after prepping cable to trim to length and
tighten into the clamp securely.
4.
5.
6.
Figure 1 Figure 2
9
FieldSmart®Fiber Distribution Point (FDP)
24 & 48 Port Outdoor Wall Box
________________________________________________________Installation Manual
Direct: 763.476.6866 • National: 800.422.2537 • www.SeeCleareld.com • [email protected]
Manual 020012 REV A - Aug 2018
Tighten the dome nut on the sealcon to secure the
cable.
Note: Cleareld recommends the use of a set of
sealcon wrenches (P/N’s 013190 - 40mm, and 013191
- 42mm) to properly tighten the sealcon lock nut and
dome nut. These feature an open channel, which allows
the wrench to slide over cables and onto the sealcon.
7.
Grounding
The wall box and all associated cables can be grounded to
the provided lug in the splicing side of the wall box. Ground
per your local practices.
Direct: 763.476.6866 • National: 800.422.2537 • www.SeeCleareld.com • [email protected]
10
FieldSmart®Fiber Distribution Point (FDP)
24 & 48 Port Outdoor Wall Box
Installation Manual ______________________________________________________
Manual 020012 REV A - Aug 2018
Consult the Clearview Blue Cassette Installation Manual for splicing instructions, located under the Resources tab of
the Cleareld website, www.seecleareld.com.
Viewable here:
https://www.seecleareld.com/assets/documents/installation-manuals/clearview-blue-cassette-install-manual.pdf
4.
Remove all Clearview Blue Cassettes from the wall
box that need to be spliced. This can be done by
opening the bulkhead and loosening the captive
screws on each side of the cassette which hold the
cassette to the bulkhead.
3.
Fiber Splicing
Route the buffer tube to be spliced in the slack
storage area and up to the cassette to be spliced.
Mark the tie off point of the cassette with a marker.
Make sure to leave around 3 feet of extra buffer tube
after the mark to allow for slack in the cassette’s
splice tray.
1.
2.
