CMA Dishmachines UC50E Manuale utente

High Temp Undercounter

Dishwasher And

Glasswasher

UC50e

CMA Di hmachine 12700 Knott Street Garden Grove, CA 92841• 800-854-6417 • 714-898-8781 • Fax: 714-895-2141 • www.cmadi hmachine .com

CMA reserves the right to modify specifications or discontinue models without prior notification.

FEATURES:

nEnergy Star Qualified.

n30 racks / 120 covers per hour.

nFully automatic cycle for easy operation

nBuilt-in detergent and rinse chemical pumps.

nPump drain allows for multiple installation

applications including elevated drains.

nSafety Temp feature assures 180°F sanitizing rinse

every cycle.

nBuilt-in 6 k booster heater

n2.7 k wash tank heater.

nDouble skin stainless steel provides consistent

heating and a quiet operation.

nLow 0.8 US gal. water usage per rack.

nDoor and water level safety switches, plus booster

safety thermostat.

nStainless steel safety filters protect wash pump.

nPolished stainless steel surface and tanks with

rounded corners for a total and easy cleaning.

nOperator friendly, removable wash and rinse arms

allows for easy cleaning.

nTriple filtering protection system, captures excess

soil and debris.

Top mounted controls are easy

to read and simple to operate.

Large 13-3/4" door clearance

accommodates oversized plates,

glasses and utensils.

Upper and lower w a s h a n d

rinse arms guarantee excellent

results.

Built-in detergent and rinse

chemical pumps.

UC50e Spec Sheet Front_G-LX Spec Sheet Front 4/21/11 10:33 AM Page 1

WATER CONSUMPTION

PER RACK .8 GAL (3L)

PER HOUR 24/16 GAL (90/60L)

OPERATING CYCLE

WASH TI E-SEC 100/160 100/160

RINSE TI E-SEC 15/15 15/15

DWELL-SEC 5/5 5/5

TOTAL CYCLE-SEC 120/180 120/180

OPERATING CAPACITY

RACKS PER HOUR 30/20 30/20

WASH TANK CAPCITY 6.87 GAL (26L)

WATER REQUIRMENTS 140°F (60°C)

WATER INLET 3/4"

DRAIN CONNECTION 1"

RINSE PRESSURE SET 24 PSI 1.7kg/cm2

CYCLE TEMPERATURES

WASH-°F 155°F-160°F (68°C/71°C)

RINSE-°F 180°F-195°F (82°C/90°C)

FRAME DIMENSIONS

DEPTH 24" (61 C )

WIDTH 23-7/16" (59.5 C )

HEIGHT 33-5/16" (84.5 C )

AXI U LOADING

HEIGHT 13" (33 C )

STANDARD DISHRACK 11

DI ENSIONS 19-3/4"X19-3/4" (50X50C )

SHIPPING WEIGHT 165# 75(KG)

WASH PUMP MOTORS HP 3/4HP

HEATERS

WASH TE P HEATER 2.7kW

BOOSTER HEATER 6kW

ELECTRICAL RATING VOLTS PHASE AMPS

220-240 +6% 1 30

TOLERENCE TESTED

MODEL UC50 USA METRIC USA METRIC

Specifications:

Summa y Specifications:

CMA Di hmachine 12700 Knott Street Garden Grove, CA 92841• 800-854-6417 • 714-898-8781 • Fax: 714-895-2141 • www.cmadi hmachine .com

CMA reserves the right to modify specifications or discontinue models without prior notification.

KROMO BRANDS

Dist ibuted exclusively by CMA Dishmachines

WARNING: Plumbing connections must be made by a qualified service company who will comply with all available Federal, State, and Local Health,

Plumbing and Safety codes.

TOP VIEW FRONT VIEW SIDE VIEW

237/16"237/16"397/16"

24"

1/4"

335/8"

MAXIMUM

HEIGHT

13"

TRAY TRACK LINE

The UC50e dishwasher and glasswasher is a front loading machine designed to produce spar ling clean glasses and

dishes. Constructed of double walled stainless steel s in providing constant heating and a quiet operation. Standard

features include upper and lower wash/rinse arms and wash and booster tan heater. Features include

13 " max im u m l o ad in g hei gh t, standard liquid detergent rinse-aid dispenser.

High Temp Undercounter

Dishwasher And

Glasswasher

UC50e
